SHEET 1 OF 1
X
20.80
[.819 in]
9.61
[.378 in]
13.00 +0.1
RECOMMENDED PANEL MOUNTING
PANEL THICKNESS
0.75-1.25
1.25-2.00
2.00-3.00
X
19.2-19.3
19.3-19.4
19.5-19.6
B
14.80
[.583 in]
14.3
[.561 in]
SWITCH FUNCTION
POS. 1
(ON)
(1-1b)
POS. 2
NONE
NONE
POS. 3
ON
1-1a
B
3
2.00
[.079 in]
1
ACTUATOR COLOR
BLACK
( ) = MOMENTARY
1B
1A
ACTUATOR COLOR
BLACK
14.00
[.551 in]
B
3.00
[.118 in]
1
CURCUIT: SPDT
NOTES:
1. ALL DIMENSIONS IN MM [INCH]
2. GENERAL TOLERANCE: X.X=±0.4
X.XX=±0.25
3. TERM. NOS. FOR REF. ONLY
4. RATING: 15A @125VAC;
8A @250VAC.
5. LAMP VOLTAGE: NO LAMP
6. MATERIAL:
CONTACT SURFACE: COIN SILVER, SILVER PLATED.
TERMINAL: COPPER ALLOY W/SILVER PLATE
7. ELECTRICAL LIFE: 10,000 CYCLES
8. CONTACT RESISTANCE: <20 MILLI-OHMS INITIAL
9. DIELECTRIC STRENGTH: >1,500V AC 1 MIN
10. DENOTES CRITICAL PARAMETER.
11. 2002/95/EC (RoHS) COMPLIANT.
.50
[.020 in]
.60
[.024 in]
6.95
[.274 in]
1a
1 1b
1.60
[.063 in]
6.95
[.274 in]
17.45
[.687 in]
18.60
[.732 in]
12.50
[.492 in]
B
A
REV
19359
16231
PCR NO
HOUSING & PANEL THICKNESS UPDATES
REVISED AND REDRAWN
DESCRIPTION
11/02/10
7/14/06
DATE
BMA
RC
BY
TITLE
R1966GBLKBLKES
DATE
DR
THE INFORMATION CONTAINED IN THIS DOCUMENT IS PROPRIETARY
TO E-SWITCH AND IS NOT TO BE COPIED OR TRANSFERRED
SCALE
1.5:1
DWG
REV
7/14/2006
RC
M301254
B
