UPD78012FYCW-XXX: DescriptionMicrocontroller, 8-Bit, MROM, MOS, PDIP64, 0.750 INCH, SHRINK, PLASTIC, DIP-64; CategoryThe embedded processor and controller Microcontrollers and processors; File Size384KB，72 Pages; ManufacturerNEC Electronics

Download Datasheet Parametric Compare View All

UPD78012FYCW-XXX Overview

Microcontroller, 8-Bit, MROM, MOS, PDIP64, 0.750 INCH, SHRINK, PLASTIC, DIP-64

UPD78012FYCW-XXX Parametric

Parameter Name	Attribute value
Is it Rohs certified?	incompatible
Maker	NEC Electronics
Parts packaging code	DIP
package instruction	0.750 INCH, SHRINK, PLASTIC, DIP-64
Contacts	64
Reach Compliance Code	compliant
Has ADC	YES
Address bus width	16
bit size	8
maximum clock frequency	10 MHz
DAC channel	NO
DMA channel	NO
External data bus width	8
JESD-30 code	R-PDIP-T64
JESD-609 code	e0
Number of I/O lines	53
Number of terminals	64
Maximum operating temperature	85 °C
Minimum operating temperature	-40 °C
PWM channel	YES
Package body material	PLASTIC/EPOXY
encapsulated code	SDIP
Package shape	RECTANGULAR
Package form	IN-LINE, SHRINK PITCH
Peak Reflow Temperature (Celsius)	NOT SPECIFIED
Certification status	Not Qualified
ROM programmability	MROM
Maximum seat height	5.08 mm
Maximum supply voltage	5.5 V
Minimum supply voltage	2.7 V
surface mount	NO
technology	MOS
Temperature level	INDUSTRIAL
Terminal surface	TIN LEAD
Terminal form	THROUGH-HOLE
Terminal pitch	1.778 mm
Terminal location	DUAL
Maximum time at peak reflow temperature	NOT SPECIFIED
width	19.05 mm
uPs/uCs/peripheral integrated circuit type	MICROCONTROLLER

UPD78012FYCW-XXX Preview

DATA SHEET

MOS INTEGRATED CIRCUIT

µ

PD78011FY, 78012FY, 78013FY, 78014FY, 78015FY, 78016FY, 78018FY

8-BIT SINGLE-CHIP MICROCONTROLLER

DESCRIPTION

The

µ

PD78011FY, 78012FY, 78013FY, 78014FY, 78015FY, 78016FY, and 78018FY are the products in the

µ

PD78018FY

subseries within the 78K/0 series, and the products which is added the I

2

C bus control function to the

µ

PD78018F subseries.

A one-time PROM or EPROM product

µ

PD78P018FY capable of operating in the same power supply voltage as of the

mask ROM product and other development tools are also provided.

Functions are described in detail in the following User's Manual, which should be read when carring out design

work.

µ

PD78018F, 78018FY Subseries User's Manual : U10659E

78K/0 Series Users Manual – Instruction

: U12326E

FEATURES

•

Serial interface : 2 channels (I

2

C bus mode : 1 channel)

•

Large on-chip ROM & RAM

Item

Product Name

Program

Memory

(ROM)

8K bytes

16K bytes

24K bytes

32K bytes

40K bytes

48K bytes

60K bytes

1024 bytes

Internal High-

Speed RAM

512 bytes

Data Memory

Internal

Expanded RAM

–

Buffer RAM

32 bytes

Package

•

64-pin plastic shrink DIP (750 mil)

•

64-pin plastic QFP (14

×

14 mm)

µ

PD78011FY

µ

PD78012FY

µ

PD78013FY

µ

PD78014FY

µ

PD78015FY

µ

PD78016FY

µ

PD78018FY

512 bytes

1024 bytes

•

•

•

•

•

•

External memory expansion space : 64K bytes

Minimum instruction execution time can be varied from high-speed (0.4

µ

s) to ultra-low-speed (122

µ

s)

I/O ports: 53 (N-ch open-drain : 4)

8-bit resolution A/D converter : 8 channels

Timer : 5 channels

Supply voltage : V

DD

= 1.8 to 5.5 V

APPLICATION FIELDS

Cellular phone, pager, VCR, audio, camera, home appliances, etc

The information in this document is subject to change without notice.

Document No. U10281EJ2V0DS00 (2nd edition)

Date Published August 1997 N

Printed in Japan

The mark

shows major revised points.

©

1994

µ

PD78011FY, 78012FY, 78013FY, 78014FY, 78015FY, 78016FY, 78018FY

ORDERING INFORMATION

Part Number

Package

64-pin plastic shrink DIP (750 mil)

64-pin plastic QFP (14

×

14 mm)

64-pin plastic shrink DIP (750 mil)

64-pin

64-pin

64-pin

64-pin

64-pin

64-pin

64-pin

64-pin

64-pin

64-pin

64-pin

plastic

plastic

plastic

plastic

plastic

plastic

plastic

plastic

plastic

plastic

plastic

QFP (14

×

shrink DIP

QFP (14

×

shrink DIP

QFP (14

×

shrink DIP

QFP (14

×

shrink DIP

QFP (14

×

shrink DIP

QFP (14

×

14 mm)

(750 mil)

14 mm)

(750 mil)

14 mm)

(750 mil)

14 mm)

(750 mil)

14 mm)

(750 mil)

14 mm)

µ

PD78011FYCW-×××

µ

PD78011FYGC-×××-AB8

µ

PD78012FYCW-×××

µ

PD78012FYGC-×××-AB8

µ

PD78013FYCW-×××

µ

PD78013FYGC-×××-AB8

µ

PD78014FYCW-×××

µ

PD78014FYGC-×××-AB8

µ

PD78015FYCW-×××

µ

PD78015FYGC-×××-AB8

µ

PD78016FYCW-×××

µ

PD78016FYGC-×××-AB8

µ

PD78018FYCW-×××

µ

PD78018FYGC-×××-AB8

Remark

×××

indicates a ROM code suffix.

2

µ

PD78011FY, 78012FY, 78013FY, 78014FY, 78015FY, 78016FY, 78018FY

78K/0 SERIES DEVELOPMENT

The following shows the products organized according to usage. The names in the parallelograms are subseries

names.

Products in mass production

Products under development

Y subseries products are compatible with I

2

C bus.

Control

100-pin

100-pin

100-pin

100-pin

80-pin

80-pin

80-pin

64-pin

64-pin

64-pin

64-pin

64-pin

64-pin

64-pin

42/44-pin

µ

PD78075B

µ

PD78078

µ

PD78070A

µ

PD780058

µ

PD78058F

µ

PD78054

µ

PD780034

µ

PD780024

µ

PD78014H

µ

PD78018F

µ

PD78014

µ

PD780001

µ

PD78002

µ

PD78083

Inverter control

µ

PD78075BY

µ

PD78078Y

µ

PD78070AY

µ

PD780018AY

µ

PD780058Y

Note

µ

PD78058FY

µ

PD78054Y

µ

PD780034Y

µ

PD780024Y

µ

PD78018FY

µ

PD78014Y

µ

PD78002Y

EMI-noise reduced version of

µ

PD78078

A timer was added to the

µ

PD78054 and external interface was enhanced

ROM-less version of the

µ

PD78078

Serial I/O of the

µ

PD78078Y was enhanced and the function is limited.

Serial I/O of the

µ

PD78054 was enhanced and EMI-noise was reduced.

EMI-noise reduced version of the

µ

PD78054

UART and D/A converter were enhanced to the

µ

PD78014 and I/O was enhanced

A/D converter of the

µ

PD780024 was enhanced

Serial I/O of the

µ

PD78018F was added and EMI-noise was reduced.

EMI-noise reduced version of

µ

PD78018F

Low-voltage (1.8 V) operation version of the

µ

PD78014, with larger selection of ROM and RAM capacities

An A/D converter and 16-bit timer were added to the

µ

PD78002

An A/D converter was added to the

µ

PD78002

Basic subseries for control

On-chip UART, capable of operating at low voltage (1.8 V)

64-pin

64-pin

µ

PD780964

µ

PD780924

FIP

TM

drive

A/D converter of the

µ

PD780924 was enhanced

On-chip inverter control circuit and UART. EMI-noise was reduced.

100-pin

100-pin

78K/0

Series

80-pin

80-pin

µ

PD780208

µ

PD780228

µ

PD78044H

µ

PD78044F

LCD drive

The I/O and FIP C/D of the

µ

PD78044F were enhanced, Display output total: 53

The I/O and FIP C/D of the

µ

PD78044H were enhanced, Display output total: 48

An N-ch open drain I/O was added to the

µ

PD78044F, Display output total: 34

Basic subseries for driving FIP, Display output total: 34

100-pin

100-pin

100-pin

µ

PD780308

µ

PD78064B

µ

PD78064

µ

PD780308Y

µ

PD78064Y

The SIO of the

µ

PD78064 was enhanced, and ROM, RAM capacity increased

EMI-noise reduced version of the

µ

PD78064

Basic subseries for driving LCDs, On-chip UART

IEBus

TM

supported

80-pin

80-pin

µ

PD78098B

µ

PD78098

Meter control

EMI-noise reduced version of the

µ

PD78098

An IEBus controller was added to the

µ

PD78054

80-pin

µ

PD780973

LV

On-chip controller/driver for automobile meters

64-pin

µ

PD78P0914

On-chip PWM output, LV digital code decoder, and Hsync counter

Note

Under planning

3

µ

PD78011FY, 78012FY, 78013FY, 78014FY, 78015FY, 78016FY, 78018FY

The following lists the main functional differences between Y subseries products.

Functions

Subseries Name

Control

µ

PD78075BY

V

DD

MIN.

Value

1.8 V

ROM Capacity

32 K to 40 K

48 K to 60 K

–

48 K to 60 K

Serial Interface Configuration

3-wire/2-wire/I

2

C

: 1 ch

With automatic transmit/receive function, 3-wire : 1 ch

3-wire/UART

: 1 ch

With automatic transmit/receive function, 3-wire : 1 ch

Time division, 3-wire

I

2

C bus (for multimaster)

: 1 ch

: 1 ch

I/O

88

µ

PD78078Y

µ

PD78070AY

µ

PD780018AY

61

88

2.7 V

µ

PD780058Y

24 K to 60 K

3-wire/2-wire/I

2

C

: 1 ch

With automatic transmit/receive function, 3-wire : 1 ch

3-wire/time division UART

: 1 ch

3-wire/2-wire/I

2

C

: 1 ch

With automatic transmit/receive function, 3-wire : 1 ch

3-wire/UART

: 1 ch

UART

3-wire

I

2

C bus (for multimaster)

: 1 ch

: 1 ch

: 1 ch

68

1.8 V

µ

PD78058FY

µ

PD78054Y

µ

PD780034Y

µ

PD780024Y

µ

PD78018FY

µ

PD78014Y

µ

PD78002Y

LCD

drive

48 K to 60 K

16 K to 60 K

8 K to 32 K

69

2.7 V

2.0 V

51

1.8 V

8 K to 60 K

3-wire/2-wire/I

2

C

: 1 ch

With automatic transmit/receive function, 3-wire : 1 ch

3-wire/2-wire/SBI/I

2

C

: 1 ch

With automatic transmit/receive function, 3-wire : 1 ch

3-wire/2-wire/SBI/I

2

C

3-wire/2-wire/I

2

C

3-wire/time division UART

3-wire

: 1 ch

: 1 ch

: 1 ch

: 1 ch

: 1 ch

: 1 ch

53

8 K to 32 K

2.7 V

8 K to 16 K

48 K to 60 K

µ

PD780308Y

57

2.0 V

µ

PD78064Y

16 K to 32 K

3-wire/2-wire/I

2

C

3-wire/UART

Remark

The functions other than the serial interface are the same as those of subseries products without the suffix Y.

4

µ

PD78011FY, 78012FY, 78013FY, 78014FY, 78015FY, 78016FY, 78018FY

OVERVIEW OF FUNCTION (1/2)

Item

Product Name

ROM

High-speed

RAM

Expanded

RAM

Buffer RAM

Memory space

General-purpose registers

32 bytes

64K bytes

8 bits

×

32 registers (8 bits

×

8 registers

×

4 banks)

µ

PD78011FY

µ

PD78012FY

µ

PD78013FY

µ

PD78014FY

µ

PD78015FY

µ

PD78016FY

µ

PD78018FY

8K bytes

16K bytes

24K bytes

32K bytes

40K bytes

1024 bytes

—

512 bytes

1024 bytes

48K bytes

60 K bytes

Internal

memory

512 bytes

Minimum instruction execution time On-chip minimum instruction execution time cycle modification function

When main system

clock selected

When subsystem

clock selected

Instruction set

0.4

µ

s/0.8

µ

s/1.6

µ

s/3.2

µ

s/6.4

µ

s (at 10.0 MHz operation)

122

µ

s (at 32.768 kHz operation)

•

•

•

•

16-bit operation

Multiplication/division (8 bits

×

8 bits,16 bits

÷

8 bits)

Bit manipulation (set, reset, test, boolean operation)

BCD correction, etc.

: 53

:

02

: 47

:

04

I/O ports

Total

• CMOS input

• CMOS I/O

• N-channel open-drain I/O

(15 V withstand voltage)

A/D converter

• 8-bit resolution

×

8 channels

• Operable over a wide power supply voltage range: V

DD

= 1.8 to 5.5 V

• 3-wire serial I/O/2-wire serial I/O/I

2

C bus mode selectable: 1 channel

• 3-wire mode (on-chip max. 32 bytes automatic data transmit/receive function): 1 channel

• 16-bit timer/event counter

• 8-bit timer/event counter

• Watch timer

• Watchdog timer

: 1 channel

: 2 channels

: 1 channel

: 1 channel

Serial interface

Timer

Timer output

Clock output

3 (14-bit PWM output

×

1)

39.1 kHz, 78.1 kHz, 156 kHz, 313 kHz, 625 kHz, 1.25 MHz (at main system clock: 10.0 MHz

operation), 32.768 kHz (at subsystem clock: 32.768 kHz operation)

Buzzer output

Vectored

interrupt

sources

Non-maskable

Software

Maskable

2.4 kHz, 4.9 kHz, 9.8 kHz (at main system clock: 10.0 MHz operation)

Internal : 8

External : 4

Internal : 1

1

5

More (Only the first 5 pages are displayed. Please Download Datasheet to view the full content.) >

UPD78012FYCW-XXX Related Products

	UPD78012FYCW-XXX	UPD78018FYCW-XXX	UPD78018FYGC-XXX-AB8	UPD78012FYGC-XXX-AB8	UPD78014FYCW-XXX	UPD78015FYGC-XXX-AB8
Description	Microcontroller, 8-Bit, MROM, MOS, PDIP64, 0.750 INCH, SHRINK, PLASTIC, DIP-64	Microcontroller, 8-Bit, MROM, MOS, PDIP64, 0.750 INCH, SHRINK, PLASTIC, DIP-64	Microcontroller, 8-Bit, MROM, MOS, PQFP64, 14 X 14 MM, PLASTIC, QFP-64	Microcontroller, 8-Bit, MROM, MOS, PQFP64, 14 X 14 MM, PLASTIC, QFP-64	Microcontroller, 8-Bit, MROM, MOS, PDIP64, 0.750 INCH, SHRINK, PLASTIC, DIP-64	Microcontroller, 8-Bit, MROM, MOS, PQFP64, 14 X 14 MM, PLASTIC, QFP-64
Maker	NEC Electronics	NEC Electronics	NEC Electronics	NEC Electronics	NEC Electronics	NEC Electronics
Parts packaging code	DIP	DIP	QFP	QFP	DIP	QFP
package instruction	0.750 INCH, SHRINK, PLASTIC, DIP-64	0.750 INCH, SHRINK, PLASTIC, DIP-64	14 X 14 MM, PLASTIC, QFP-64	14 X 14 MM, PLASTIC, QFP-64	0.750 INCH, SHRINK, PLASTIC, DIP-64	14 X 14 MM, PLASTIC, QFP-64
Contacts	64	64	64	64	64	64
Reach Compliance Code	compliant	unknown	compliant	unknown	compliant	compliant
Has ADC	YES	YES	YES	YES	YES	YES
Address bus width	16	16	16	16	16	16
bit size	8	8	8	8	8	8
maximum clock frequency	10 MHz	10 MHz	10 MHz	10 MHz	10 MHz	10 MHz
DAC channel	NO	NO	NO	NO	NO	NO
DMA channel	NO	NO	NO	NO	NO	NO
External data bus width	8	8	8	8	8	8
JESD-30 code	R-PDIP-T64	R-PDIP-T64	S-PQFP-G64	S-PQFP-G64	R-PDIP-T64	S-PQFP-G64
Number of I/O lines	53	53	53	53	53	53
Number of terminals	64	64	64	64	64	64
Maximum operating temperature	85 °C	85 °C	85 °C	85 °C	85 °C	85 °C
Minimum operating temperature	-40 °C	-40 °C	-40 °C	-40 °C	-40 °C	-40 °C
PWM channel	YES	YES	YES	YES	YES	YES
Package body material	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY
encapsulated code	SDIP	SDIP	QFP	QFP	SDIP	QFP
Package shape	RECTANGULAR	RECTANGULAR	SQUARE	SQUARE	RECTANGULAR	SQUARE
Package form	IN-LINE, SHRINK PITCH	IN-LINE, SHRINK PITCH	FLATPACK	FLATPACK	IN-LINE, SHRINK PITCH	FLATPACK
Certification status	Not Qualified	Not Qualified	Not Qualified	Not Qualified	Not Qualified	Not Qualified
ROM programmability	MROM	MROM	MROM	MROM	MROM	MROM
Maximum seat height	5.08 mm	5.08 mm	2.85 mm	2.85 mm	5.08 mm	2.85 mm
Maximum supply voltage	5.5 V	5.5 V	5.5 V	5.5 V	5.5 V	5.5 V
Minimum supply voltage	2.7 V	2.7 V	2.7 V	2.7 V	2.7 V	2.7 V
surface mount	NO	NO	YES	YES	NO	YES
technology	MOS	MOS	MOS	MOS	MOS	MOS
Temperature level	INDUSTRIAL	INDUSTRIAL	INDUSTRIAL	INDUSTRIAL	INDUSTRIAL	INDUSTRIAL
Terminal form	THROUGH-HOLE	THROUGH-HOLE	GULL WING	GULL WING	THROUGH-HOLE	GULL WING
Terminal pitch	1.778 mm	1.778 mm	0.8 mm	0.8 mm	1.778 mm	0.8 mm
Terminal location	DUAL	DUAL	QUAD	QUAD	DUAL	QUAD
width	19.05 mm	19.05 mm	14 mm	14 mm	19.05 mm	14 mm
uPs/uCs/peripheral integrated circuit type	MICROCONTROLLER	MICROCONTROLLER	MICROCONTROLLER	MICROCONTROLLER	MICROCONTROLLER	MICROCONTROLLER
Is it Rohs certified?	incompatible	-	incompatible	-	incompatible	incompatible
JESD-609 code	e0	-	e0	-	e0	e0
Peak Reflow Temperature (Celsius)	NOT SPECIFIED	-	NOT SPECIFIED	-	NOT SPECIFIED	NOT SPECIFIED
Terminal surface	TIN LEAD	-	TIN LEAD	-	TIN LEAD	TIN LEAD
Maximum time at peak reflow temperature	NOT SPECIFIED	-	NOT SPECIFIED	-	NOT SPECIFIED	NOT SPECIFIED

Recommended Resources

Output 85 to 145V adjustable regulated power supply circuit

DC-DC converter circuit diagram composed of CA3542

555 automatic temperature control timing ventilation circuit

Pulse stretching circuit using NAND gate

875p computer motherboard circuit diagram_053

(Classic) Motorola L7 mobile phone schematic 3/7

Newbies just started to learn 51 single chip microcomputer: I just started learning MCU. My classmates introduced me to this forum to learn knowledge. I hope you can give me some advice. We are now learning 51. I wonder if you have any suggestions for learning...; Learner_new 51mcu

Year-end summary - race against time: Another year is about to pass. If you race against time, you will always be a loser, because as you run, you will find out where the time has gone, and then you will quickly catch up with the time and...; lansebuluo Talking

Reposting someone else's question, which is also my question: CC2530 sleep and wake-up problem: I want to ask a question that I am reposting someone else's question. I recently developed an infrared repeater and infrared detector, powered by a battery. Usually, no one will touch it when it is pl...; 苹果654321 RF/Wirelessly

Is there a 4-channel 16-bit A/D conversion chip?: Are there any 4-channel 16-bit A/D conversion chips? Which one has better cost performance?...; susion Embedded System

[Transfer] STM32|4-20mA output circuit: [i=s]This post was last edited by littleshrimp on 2015-6-29 14:54[/i] [p=25, null, center][font=微软雅黑][size=15pt]STM32|4-20mA output circuit[/size][/font][/p][p=25, null, left][color=rgb(0, 0, 0)][font...; littleshrimp stm32/stm8

【Contribute to C2000】Design of DSP minimum system based on TMS320F2812: Abstract: In the course teaching, comprehensive experimental teaching, graduation design and electronic design competition of electronic information major, DSP experimental system is needed. This pape...; wanghongyang Microcontroller MCU

Analysis of the significance of using M430/OS on the MSP430 MCU

introduction 1 The significance of using RTOS on MSP430 It is understandable that it is meaningless to use RTOS on MSP430. Because the hardware resources of MSP430 are limited (for exampl...[Details]
How to use LCD in PIC16F946

From the PIC16F946 datasheet, we know that there are two ways to write values to the LCD for display: 1. Directly write the value to LCDDATA1~LCDDATA23 2. Use disconnect t...[Details]
Aromatic gas permeability test method

Aromatic gases are widely present in food, medicine, cosmetics and various daily chemical products, such as snacks, liquor, spices, Chinese herbal medicines, plasters, perfumes, soaps, shampoos, et...[Details]
High efficiency LED lighting design

General LED lighting has a current limiting resistor in the driving circuit, and the power consumed by the resistor has nothing to do with the LED light emission. In order to improve efficiency, a...[Details]
Several key input implementation methods on single chip microcomputer

As a simple and practical input device, buttons have been used in various microcontroller application systems and are ubiquitous. However, the buttons used in different practical occasions are also...[Details]
Failure protection method of automobile fuse

In today's body control module (BCM) designs, savvy engineers are moving away from electromechanical relays whenever possible. Their next step is to eliminate fuses. But is eliminating fuses a nece...[Details]
Design of 16-channel synchronous data acquisition circuit for acoustic emission based on DSP

Abstract: Aiming at the needs of coal-rock acoustic emission signal monitoring system, a data acquisition circuit with 24-bit resolution and 16-channel synchronous data acquisition function is desi...[Details]
Development of motorcycle engine electronic control unit ECU

Introduction As the country increases its efforts to control the atmospheric environment, motorcycle emission regulations will become stricter year by year, and motorcycles that do not meet the...[Details]
Fully automated scan test of EVM and ACPR of digital communication system based on LabVIEW

With the rapid development of wireless digital communication , more challenges have been raised for integrated circuit design and testing. In the product design stage, in order to ensure t...[Details]
Automatic test system for temperature compensated crystal oscillator compensation voltage

Temperature compensated quartz crystal oscillator (TCXO) is widely used as a high-precision frequency source in communication systems, radar navigation systems, precision measurement and control sy...[Details]
Interpretation of "HIT Technology" in Shenzhou-9 and Tiangong

The launch of Shenzhou IX is imminent, and Tiangong is welcoming visitors again. Yesterday, Professor Fu Qiang, Vice President of the Institute of Science and Industrial Technology of Harbin Instit...[Details]
LED lighting system design

This article discusses the six design steps of LED lighting system design in detail: (1) determine the lighting requirements; (2) determine the design goals and estimate the optics; (3) the efficie...[Details]
Is LED lighting a "lamp" or a "lamp fixture"?

1 Overview In the field of traditional lighting, the concepts and definitions of lamps and lamps are clear. Lamps and lamps have their own applicable product standards, supporting technical st...[Details]
Battery maintenance precautions

a. Keep the battery clean, wipe off the spilled electrolyte, contaminated dirt and dust in time; keep the poles and terminal clamps clean and in good contact, and apply vaseline or butter to preven...[Details]
The emergence of new circuit protection components

The automotive power electronics market has grown rapidly as comfort and active safety features become more common. As traditional mechanical functions shift to electronic applications, the demand ...[Details]

Shortcut: E0 E1 E2 E3 E4 E5 E6 E7 E8 E9 EA EB EC ED EE EF EG EH EI EJ EK EL EM EN EO EP EQ ER ES ET EU EV EW EX EY EZ F0 F1 F2 F3 F4 F5 F6 F7 F8 F9 FA FB FC FD FE FF FG FH FI FJ FK FL FM FN FO FP FQ FR FS FT FU FV FW FX FY FZ G0 G1 G2 G3 G4 G5 G6 G7 G8 G9 GA GB GC GD GE GF GG GH GI GJ GK GL GM GN GO GP GQ GR GS GT GU GV GW GX GZ H0 H1 H2 H3 H4 H5 H6 H7 H8 HA HB HC HD HE HF HG HH HI HJ HK HL HM HN HO HP HQ HR HS HT HU HV HW HX HY HZ I1 I2 I3 I4 I5 I6 I7 IA IB IC ID IE IF IG IH II IK IL IM IN IO IP IQ IR IS IT IU IV IW IX J0 J1 J2 J6 J7 JA JB JC JD JE JF JG JH JJ JK JL JM JN JP JQ JR JS JT JV JW JX JZ K0 K1 K2 K3 K4 K5 K6 K7 K8 K9 KA KB KC KD KE KF KG KH KI KJ KK KL KM KN KO KP KQ KR KS KT KU KV KW KX KY KZ

Popular Components

Popular Articles

Technical ResourceMore

EEWorld
subscription
account

EEWorld
service
account

Automotive
development
circle

Robot
development
community

About Us Customer Service Contact Information Datasheet Sitemap LatestNews

Index Files: 348 2386 1498 1318 1866 7 49 31 27 38

Datasheet 0 1 2 3 4 5 6 7 8 9 A B C D E F G H I J K L M N O P Q R S T U V W X Y Z

Room 1530, 15th Floor, Building B, No. 18 Zhongguancun Street, Haidian District, Beijing Telephone: (010) 82350740 Postal Code: 100190

Copyright © 2005-2026 EEWORLD.com.cn, Inc. All rights reserved 京ICP证060456号京ICP备10001474号-1 电信业务审批[2006]字第258号函

京公网安备 11010802033920号
