OmniSmart 1000VA Tower Line-Interactive 120V
UPS with built-in Isolation Transformer and USB
port
MODEL NUMBER:
OMNI1000ISO
Highlights
1000VA / 1kVA tower 120V line
interactive UPS with isolation
transformer
Corrects brownouts and
overvoltages from 81V to 143V
USB port, Normal & common
mode EMI/RFI line noise immunity
NEMA 5-15P input plug and 6
5-15R outlets
Package Includes
OMNI1000ISO UPS System
USB cable
Instruction manual
Description
Tripp Lite's OMNI1000ISO offers complete UPS protection with built-in line-interactive voltage regulation, intelligent monitoring and unattended shutdown
capability. Built-in isolation transformer with Faraday shield offers full isolation and complete common mode noise rejection. 1000VA power-handling capacity
supports point-of-sale applications, computers, internetworking equipment and home theater systems during commercial power failures. Line-interactive
voltage regulation corrects brownouts as low as 81V and overvoltages as high as 143V back to normal 120V levels, reserving battery power for use during
complete power failures. Built-in USB communications port works with PowerAlert Software and cabling to provide automatic unattended shutdown of
connected network and PC applications.
Features
1000VA line-interactive UPS with Faraday-shielded, low-impedance isolation transformer delivers full isolation from potential damage and performance
problems
Provides immunity from EMI/RFI line noise in both normal and common modes. Delivers clean signal-reference ground, reducing data errors and
audio/video distortion
Automatic voltage regulation (AVR) automatically corrects incoming voltage to keep equipment working through low voltage (brownouts) as low as 81V
and overvoltages as high as 143V without consuming battery power
Supports loads up to 1000VA/700W
Half-load runtime of 24 min. (500VA/350W); full load runtime of 8 min. (1000VA/700W)
5 diagnostic LEDs indicate AC present, on battery, voltage correction status, overload and battery low/replace
Electrostatic discharge (ESD) resistance reduces potential static damage to connected electronics
Built-in USB port and PowerAlert Software (free via web download) provide safe, unattended system shutdown during extended blackouts
Built-in surge suppression (backed by $200,000 Ultimate Lifetime Insurance) safeguards connected equipment against damage
SURGE VOLTAGE WITHSTAND CAPABILITY: ANSI/IEEE C62.41 Catagories A & B 6KV/200/500 amp 100Khz Ringwave and category B BiWave
SURGE VOLTAGE ATTENUATION: N-G 2000:1, L-G 240:1, L-N 100:1
INSERTION LOSS: 65 db N-G from 10Khz to 100Khz, 45 to 60 db L-G from 10Khz to 100Khz, 18 to 54 db L-N from 50Khz to 500 Khz
6 UPS-supported AC outlets; 6-ft. cord
1/5
Optional PDUB15 bypass PDU enables hot-swappable UPS replacement with no disruption to connected equipment
Specifications
OUTPUT
Output Volt Amp Capacity (VA)
Output kVA capacity (kVA)
Output Watt Capacity (watts)
Output power factor
Nominal Output Voltage(s)
Supported
Frequency compatibility
Output voltage regulation (line mode)
Output voltage regulation (Battery
mode)
Built-in UPS output receptacles
Hot-Swap PDU options
Output AC waveform (AC mode)
Output AC waveform (battery mode)
1000
1
700
0.7
115V; 120V
60 Hz
-18%, +8%
115V (+/- 5%)
6 5-15R outlet(s)
PDUB15 (2U / 8 5-15R outlets)
Sine wave
PWM sine wave
INPUT
Rated input current (at maximum
load)
Nominal Input Voltage(s) Supported
UPS input connection type
UPS Input cord length (ft.)
UPS Input cord length (m)
Recommended Electrical Service
Phase
7.6A
120V AC
5-15P
6
1.8
15A 120V
Single-Phase
BATTERY
Full load runtime (minutes)
Half load runtime (minutes)
DC system voltage (VDC)
Battery recharge rate (included
batteries)
Replacement battery cartridge
(internal UPS battery replacement)
8 min. (700w)
24 min. (350w)
36
Less than 4.5 hours from 10% to 90%
RBC53
2/5
Battery Access
Battery replacement description
Battery access door
Hot-swappable, user replaceable batteries
VOLTAGE REGULATION
Voltage regulation description
Overvoltage correction
Undervoltage correction
Severe undervoltage correction
Automatic voltage regulation (AVR) maintains line power operation with an input voltage range of 85 to 143
Input voltages between 128 and 143V are reduced by 9%
Input voltages between 96 and 107V are boosted by 10%
Input voltages between 85 and 95V are boosted by 20%
LEDS ALARMS & SWITCHES
LED Indicators
Alarms
Alarm cancel operation
Switches
5 LEDs indicate line power, battery power, overload, voltage regulation and battery low/replace status
Audible alarm indicates power-failure and low-battery conditions
Power-fail alarm can be silenced using alarm-cancel switch; once silenced, alarm will re-sound to indicate
low-battery status
2 Switches control off/on power status and alarm-cancel/self-test operation
SURGE / NOISE SUPPRESSION
UPS AC suppression joule rating
UPS AC suppression response time
EMI / RFI AC noise suppression
510
Instantaneous
Yes
ISOLATION
Output isolation transformer
Surge voltage withstand capability
Surge voltage attenuation
Insertion loss
Professional grade load isolation transformer
ANSI/IEEE C62.41 Categories A & B 6KV/200/500 amp 100Khz Ringwave and category B BiWave
N-G 2000:1, L-G 240:1, L-N 100:1
65 db N-G from 10Khz to 100Khz, 45 to 60 db L-G from 10Khz to 100Khz, 18 to 54 db L-N from 50Khz to 500 Khz
PHYSICAL
Installation form factors supported
with included accessories
Installation form factors supported
with optional accessories
Primary form factor
UPS / Power Module dimensions in
primary form factor (height x width x
depth / inches)
UPS / Power Module dimensions in
primary form factor (height x width x
depth / cm)
UPS / Power Module weight (lbs)
Tower
Wallmount (UPSWM - tower mounting kit)
Tower
12.8 x 7.5 x 9.2
32.4 x 19 x 23.5
36.4
3/5
UPS / Power Module weight (kg)
UPS Shipping dimensions (height x
width x depth / inches)
UPS Shipping dimensions (height x
width x depth / cm)
Shipping weight (lbs)
Shipping weight (kg)
Cooling method
UPS housing material
16.5
18.2 x 13.8 x 12
46.4 x 34.9 x 30.5
40
18.2
Fan
PVC
ENVIRONMENTAL
Operating Temperature Range
Storage Temperature Range
Relative Humidity
AC mode BTU / hr. (full load)
Battery mode BTU / hr. (full load)
AC mode efficiency rating (100%
load)
+32 to +104 degrees Fahrenheit / 0 to +40 degrees Celsius
+5 to +122 degrees Fahrenheit / -15 to +50 degrees Celsius
0 to 95%, non-condensing
235.4
324.5
91%
COMMUNICATIONS
Communications interface
PowerAlert software
Communications cable
WatchDog compatibility
USB
Free download from www.tripplite.com
USB cable included
Supports Watchdog application, OS and hard-reboot restart options for remote applications
LINE / BATTERY TRANSFER
Transfer time
Low voltage transfer to battery
power (setpoint)
High voltage transfer to battery
power (setpoint)
2-4 milliseconds
81
143
SPECIAL FEATURES
Cold Start (startup in battery mode
during a power failure)
High availability UPS features
Cold-start operation supported
Hot swappable batteries
CERTIFICATIONS
UPS Certifications
Tested to UL1778 (USA); Tested to CSA (Canada); Tested to NOM (Mexico); Meets FCC Part 15 Category A (EMI)
4/5
WARRANTY
Product Warranty Period (Worldwide)
Connected Equipment Insurance
(U.S., Canada & Puerto Rico)
2-year limited warranty
$200,000
Ultimate Lifetime Insurance
Related Items
Optional Products
Model Number
WEXT3-OMNI
WEXT5-OMNI
PDUB15
UPSWM
Description
3-Year Extended Warranty - For OmniSmart, OmniPro, OmniVS
5-Year Extended Warranty - For OmniSmart, OmniPro, OmniVS
Single-Phase Hot-Swap PDU, 1.4kW 15A 120V, 2U Horizontal Rackmount, 8 NEMA 5-15R outlets,
set of 2 NEMA 5-15P input plugs
Wallmount Bracket and installation accessories (4 washers, 4 screws, 1 Velcro safety strap)
Qty.
1
1
1
1
More information, including related products, owner's manuals, and additional technical specifications, can be found online at:
http://www.tripplite.com/sku/OMNI1000ISO.
© 2014 Tripp Lite. All rights reserved. All trademarks are the sole property of their respective owners. Tripp Lite has a policy of continuous improvement.
Specifications are subject to change without notice. Photos may differ slightly from final products.
5/5
