26,55
6,5
Ansaughaube
5,5
4,15
hood
Verpackt in Gurtverpackung
-
Tape on Reel Packaging
Verpackungseinheit: 400 Stück -
Packaging unit: 400 pcs
5,4
0,5
26
0,8
b1
26,55
0,7
0,6
4,5
3,8
b25
150
330
Abspulrichtung -
Reel off Direction
a1
16
44,5
3,85
a1
1
24 x 1 = 24
25,3
a25
Leiterplatten-Layout Vorschlag /
PCB-Layout Proposal
26
0,85
1.)
0,7
±0,03
3
0,65
8 x 3 = 24
0,8
44
1.)
0,9
±0,03
1,5
0,7
1
1
0,5
24 x 1 = 24
Copyright by ERNI GmbH
Proprietary notice pursuant to ISO 16016 to be observed.
0,85
Anforderungsstufe 1
4,45
1,5
Information:
Tolerances
All Dimensions
in mm
Scale
5:1
Performance Level 1
Kontaktbereich vergoldet
Mating Area gold plating
1.) Durchmesser des Bohrers /
Drill tool
Anschlussbereich verzinnt 4-6µm
Terminal Area 4-6µm tin plating
Koplanarität der Anschlüsse
≤
0,1mm
All rights reserved.
Only for Information.
To ensure that this is the latest
version of this drawing, please
contact one of the ERNI companies
before using.
h
Index
10.11.2011
Date
Designation
Subject to modification without
prior notice.
Drawing will not be updated.
Federleiste 4mm SMD, 50 polig
Female 4mm SMD, 50 contacts
Coplanarity Area of Termination
≤
0,1mm
www.ERNI.com
Class
100102250001
MSPEED
K
A3
Embedded System
