Pressure sensors
Pressure transmitters for PCB mounting (voltage output)
AC-T series
Description
The transmitters are based on piezoresistive silicon pressure sensors
from our own clean room.
The T-series electronic compensates nonlinearity and temperature
errors and supplies a precise calibrated output signal with a high
immunity against electromagnetic influences (EMI).
Features
Piezoresistive MEMS technology
Measured media (absolute pressure):
Air, non-aggressive gases (gas humidity 0 ... 85% r.h., without dew).
Unsuitable for substances, which react with glass, silicon, aluminum,
ceramics, polybutylene terephthalate, silicone glue or silicone gel.
Measured media (gauge pressure):
Air, non-aggressive gases (gas humidity 0 ... 100% r.h.)
and non-aggressive fluids.
Unsuitable for substances which react with glass, silicon, stainless
steel, silicone glue (p
r
≤
10 bar) or epoxy glue (p
r
> 10 bar).
Voltage output proportional to pressure: 0.5 ... 4.5 V
RoHS-compatible, halogen-free
Dual-in-line package for PCB mounting
Dimensional drawings
Type LN for absolute pressure
(4.8 mm tube fitting)
Type KD for gauge pressure
(4.8 mm tube fitting)
Type KC for gauge pressure
(M5 thread connection)
All dimensions in mm
AS SEN PD
Please read Cautions and warnings and
Important notes at the end of this document.
Page 2 of 8
2009-08-03
Pressure sensors
Pressure transmitters for PCB mounting (voltage output)
AC-T series
Technical data
Absolute maximum ratings
Parameter
Temperature ranges
Storage temperature range
Operating temperature range
Compensated temperature range
Soldering temperature
Pressure ranges
Overpressure
Supply voltage /-current
Supply voltage
Supply current
Signal output current
Output signal at sensor failure
DC break down voltage
Parameter
V
CC
I
CC
I
A
V
ERR
V
is
Symbol
Types KD, KC only
Conditions
8)
6)
Symbol
Conditions
Min.
Typ.
Max.
Unit
T
st
T
a
T
c
T
solder
1)
2)
3)
–40
–25
0
+105
+85
+70
+240
°
C
°
C
°
C
°
C
<5 s
(no reflow soldering)
p
ov
4), 5)
1.5
p
r
4.75
5.5
7
2
0.01
V
mA
mA
V
V
I
A
= 0
7)
500
Min.
Typ.
Max.
Unit
Output signal @ T
a
= 25° V
CC
= 5 V, I
A
< 0.1 mA
C,
Offset
V
A0
Simple output ACA, ACR
Symmetrical output ACS
Signal span (Full Scale)
Nonlinearity
V
FS
L
10)
9)
9)
0.485
2.485
3.985
0.5
2.5
4.0
±0.1
0.515
2.515
4.015
±0.25
±0.5
V
V
V
% FS
% FS
ms
Simple output
10), 11)
10), 11)
Symmetrical output
Response time
Supply voltage rejection
Parameter
t
10-90
SVR
Symbol
12)
10), 13)
±0.25
1
±0.01
Min.
Typ.
Max.
% FS/V
Unit
Conditions
Data in temperature range @ T
a
= –25 ... 85 ° V
CC
= 5 V, I
A
< 0.1 mA
C,
Temperature hysteresis
14)
±0.1
15)
15)
±0.5
% FS
Data in temperature range @ T
a
= 0 ... 70 ° V
CC
= 5 V, I
A
< 0.1 mA
C,
Temperature coefficient of offset
TCV
A0
p
r
< 0.25 bar
p
r
≥
0.25 bar
Temperature coefficient of span
TCV
FS
16)
±0.015
±0.015
±0.015
±0.05
±0.03
±0.03
% FS/K
% FS/K
% FS/K
AS SEN PD
Please read Cautions and warnings and
Important notes at the end of this document.
Page 3 of 8
2009-08-03
Pressure sensors
Pressure transmitters for PCB mounting (voltage output)
AC-T series
Characteristics
Simple output (ACA, ACR)
Symmetrical output (ACS)
V
A0
+ V
FS
V
A0
+ ½V
FS
V
A0
V
A0
0
p
r
V
A0
- ½V
FS
-p
r
0
+p
r
Connection diagram
V
cc
p
U
GND
V
A
Terminal assignment
Pin
1
2
3
4
5 ... 8
Symbol
V
CC
GND
V
A
-
-
Signal
Supply voltage
Ground
Output signal
do not connect!
n.c.
Suggested drilling plan (top view)
Ø0,
8
1
7,62
8
4
5
14,6
AS SEN PD
Please read Cautions and warnings and
Important notes at the end of this document.
Page 4 of 8
2009-08-03
AS SEN PD
Product type
Product type
Pressure
measurement
Pressure
measurement
Ordering code
Rated pressure p
r
bar
Rated pressure p
r
bar
0.100
B58620L1110A052
B58620L1110A053
B58621K1110A054
B58621K1110A055
B58621K1110A056
B58621K1110A057
B58623K1110A058
B58623K1110A059
B58623K1110A060
B58623K1110A061
ACR 0.250 KD V4 TN L D
ACR 0.400 KD V4 TN L D
ACR 1.000 KD V4 TN L D
ACS 0.100 KD V4 TN L D
ACS 0.250 KD V4 TN L D
ACS 0.400 KD V4 TN L D
ACS 1.000 KD V4 TN L D
ACR 0.100 KD V4 TN L D
ACA 2.500 LN V4 TN L D
2.500
0.100
0.250
0.400
1.000
0.100
0.250
0.400
1.000
ACA 1.000 LN V4 TN L D
1.000
0.250
0.400
1.000
2.500
6.000
10.00
25.00
0.100
0.250
0.400
1.000
Absolute
(type LN)
Gauge
(type KC)
Gauge
(type KD)
Please read Cautions and warnings and
Important notes at the end of this document.
Other rated pressures upon request.
B58621K1510A062
B58621K1510A063
Rated pressures and ordering codes
B58621K1510A064
B58621K1510A065
B58621K1510A066
B58621K1510A067
Pressure sensors
Pressure transmitters for PCB mounting (voltage output)
Page 5 of 8
Gauge, symmetr.
(type KC)
B58621K1510A068
B58621K1510A069
Gauge, symmetr.
(type KD)
B58623K1510A070
B58623K1510A071
B58623K1510A072
B58623K1510A073
Ordering code
ACR 0.100 KC V4 TN L D
ACR 0.250 KC V4 TN L D
ACR 0.400 KC V4 TN L D
ACR 1.000 KC V4 TN L D
ACR 2.500 KC V4 TN L D
ACR 6.000 KC V4 TN L D
ACR 10.00 KC V4 TN L D
ACR 25.00 KC V4 TN L D
ACS 0.100 KC V4 TN L D
ACS 0.250 KC V4 TN L D
ACS 0.400 KC V4 TN L D
ACS 1.000 KC V4 TN L D
AC-T series
2009-08-03
