MOTOROLA

SEMICONDUCTOR TECHNICAL DATA

Order Number: MC33099/D

Rev. 2, 06/2001

Advance Information

Alternator Voltage Regulator

The MC33099 is specifically designed for regulation of an automotive

system voltage using diode rectified alternator charging systems commonly

found in automotive applications. The MC33099 provides either an analog or

digital duty cycle control of an ON/OFF ratio of an alternator field current at a

fixed frequency. This provides for a Load Response Control (LRC) of the

alternator field current at low engine RPM to eliminate engine speed hunting

and vibration due to abrupt torque loading of the engine when a sudden

electrical load is applied to the system. Four LRC rates are selectable using

a combination of Pins 7 and 8 being connected to ground.

The MC33099 provides a regulated voltage feedback system to activate

the alternator field current in response to system load current. The system

voltage is monitored and level shifted using internal resistor voltage dividers,

to compared the level shifted system voltage to an internal voltage ramp

referenced to a bandgap reference voltage. The MC33099 regulates the

system voltage to 14.8 V by generating a Pulse Width Modulation (PWM)

voltage waveform at the gate of an external MOSFET to provide an average

alternator field coil current as a function of the internal voltage comparison.

MC33099

ALTERNATOR VOLTAGE

REGULATOR

SEMICONDUCTOR

TECHNICAL DATA

•

Provides High Side MOSFET Control of a Ground Referenced Field

Winding

Forced Load Response Control (LRC) at Low Engine RPM Due to

Abrupt System Load Currents

Four User Programmable LRC Rates From 1.8 Seconds to 7.4 Seconds

LRC Response During Initial Start

Regulation Voltage Range is

±0.1V

at a 14.8 V Regulation Voltage

@ 25°C

<0.1 V Variation Over Engine Speed Range From 2000 to 10,000 RPM

<0.2 V Variation Over 10% to 95% of Maximum Alternator Field Current

Minimum Duty Cycle of 3.1% for System Load Currents as Low as

1.0 A.

PWM Fixed Operating Frequency of 395 Hz

Internal Level Shifting of External System Voltages

Internal Lamp Driver with Short Circuit, Current Limit, Thermal Limit and

Load Dump Protection

Fault Protection for a Field Short to Ground

Load Dump Protection of Lamp Driver, Field Control Devices, and Loads

Fault Detection of Undervoltage, Overvoltage, Phase Loss (Lose or

Broken Belt) and High Remote Sense Resistance (lose or corroded

sense wire)

Controlled MOSFET and Field Flyback Diode Recovery Characteristics

for Minimum RFI

<1.5 mA Standby Current From Battery @ 25°C

<2.5 mA Standby Current From Battery @125°C

Gate

Battery

Gnd

Lamp Drain

Lamp Gate

Ignition

LRC2

LRC1

DW SUFFIX

PLASTIC PACKAGE

CASE 751G

(SO–16W)

PIN CONNECTIONS

(Top View)

16 Source

15 Phase

14 N.C.

13 Phase Filter

12 LRC Test

11 N.C.

10 Remote

9 AGnd

ORDERING INFORMATION

Device

PC33099DW

Operating

Temperature Range

= – 40°C to 125°C

Package

SO–16W

This document contains information on a new product. Specifications

and information herein are subject to change without notice.

MOTOROLA ANALOG

reserved.

MOTOROLA ANALOG IC DEVICE DATA

Motorola, Inc. 2001. All rights

IC DEVICE DATA

Simplified Block Diagram

Vrem

Remote

Vrs

CB1

VDD

Regulator

0.6 V

Local

Vls

Phase

CB2

Low

Pass

Vfb

Bandgap

Reference

Regulator

(OTC)

1.25 V

Vref

(2.0 V)

VDD

(5.0 V)

Min Duty

Cycle

Generator

Local

Sense

1.25 V

Vhvl

Over

Voltage

Detector

Vdac

OR1

Ign

Delay

Circuit

ign

1.25V

VTigm

Iign

Lamp

Drain

Battery

VTdsc

Phase

Filter

1.25 V

DAC

Battery

Charge

Pump

Regulator

Internal

V reg

and Bias

Current

Regulator

lpu

Gate

Polling

Circuit

Css

Battery

VTssc

lpd

MC33099

Source

IGN

101 kHz

Osc

Logic

4 LSB

4 MSB

Digital

Duty Cycle

Generator

Drain

Polling

Circuit

Lamp

Polling

Circuit

Lamp

Driver

Circuit

MOTOROLA ANALOG IC DEVICE DATA

8-Bit Counter

256

u/d

MUX

U/D

Counter

OR2

Lamp

Gate

A/D Duty Cycle

Comparator

& Tracking

Circuit

u/d

Up/Down

Control

Switch

Thermal

Limit

Detector

Current

Limit

Detector

Dtl

LCR Test

LCR1

LRC2

AGnd

Gnd

MC33099

MAXIMUM RATINGS

Rating

Power Supply Voltage

Load Dump Transient Voltage (Note 1)

Negative Voltage (Note 2)

Power Dissipation and Thermal Characteristics

Maximum Power Dissipation @ T

= 125°C

Thermal Resistance, Junction–to–Ambient

Operating Junction Temperature

Operating Ambient Temperature Range

Storage Temperature Range

ESD Voltage

Human Body Model

Machine Model (Note 1)

ESD1

ESD2

2000

200

Symbol

bat

max

–V

min

θJA

stg

Value

–2.5

640

150

–40 to 125

–45 to 150

Unit

°C/W

°C

NOTE:

1. ESD2 voltage capability of phase filter pin is greater than 150V; All other device pins are as

indicated.

ELECTRICAL CHARACTERISTICS (T

= 25

C unless otherwise noted)

Characteristic

DC CHARACTERISTICS

Regulation Voltage @ 50% Duty Cycle (V

rem

= V

set

, or V

rem

Trem

)

Regulation Voltage Range (10% < DC < 95%)

Regulation Voltage Temperature Coefficient (TC) (V

rem

= V

bat

or V

rem

< V

Trem

)

Power Up/Down IGN Threshold Voltage

Operating Drain Current (Ignition ON) (V

ign

> V

Tign

, V

rem

= V

set

)

= 25°C

–40°C < T

< 125°C

Standby Drain Current (Ignition OFF) (V

ign

< V

Tign

, V

0 V, V

rem

= V

bat

= 12.6 V)

= 25°C

–40°C < T

< 125°C

Remote Loss Voltage Threshold

Phase Detection Threshold Voltage

Undervoltage Threshold Voltage

Overvoltage Threshold Voltage (1.125 V

set

)

Overvoltage Threshold Voltage TC = 1.125 (TC

Vset

)

Load Dump Threshold Voltage = 1.3 V

set

Load Dump Threshold Voltage TC = 1.3 (TC(V

set

))

Secondary Regulation = 1.25 V

set

Trem

< V

rem

< (V

set

– 1.5

Secondary Regulation TC = 1.25 (TC(V

set

))

Secondary Load Dump Threshold Voltage = 1.3 V

set2

Secondary Load Dump Threshold Voltage TC = 1.625

(TC(V

set

))

Lamp Drain Short Circuit Threshold Voltage

Lamp Drain Short Circuit Current

Lamp Drain ON Voltage (I

lamp

= 0.4 A)

Lamp Drain–to–Gate Clamping Voltage

Lamp Gate Override Resistance

set

dVset

TC(V

set

)

Tign

14.55

–

–13

0.9

14.8

210

–11

1.25

15.05

300

–9.0

1.6

mV/°C

Q1(on)

Q2(on)

–

6.5

8.0

8.4

Q1(off)

Q2(off)

Trem

Tph

Tuv

Tov

TC(V

Tov

)

Tld

TC(V

Tld

)

set2

TC(V

set2

)

Tld2

TC(V

Tld2

)

Tdsc

dsc

d(sat)

–

4.2

3.75

10.9

16.15

–

18.9

–

18.0

–

23.5

–

1.8

2.0

–

0.6

1.0

4.5

4.0

11.35

16.65

–12.4

19.25

–14.3

18.5

–13.4

–17.9

2.25

2.5

0.3

48.48

4.6

1.5

3.2

4.8

4.25

11.6

17.15

–

19.8

–

18.8

–

2.85

3.0

2.5

–

mV/°C

Amps

kΩ

Symbol

Min

Typ

Max

Unit

MOTOROLA ANALOG IC DEVICE DATA

MC33099

ELECTRICAL CHARACTERISTICS (T

= 25

C unless otherwise noted)

Characteristic

Lamp Driver Thermal Shutdown Temperature Limit

Gate Drive Source Current

Gate Drive Sink Current

Gate Drive Gate–to–Source Clamping Voltage

Minimum Charge Pump Gate Drive Voltage (V

bat

= V

source

set

)

Source Short Circuit Threshold Voltage

Remote Input Resistance (V

rem

= V

set

)

Phase Input Resistance (V

= V

set

)

IGN Input Pull down Current (V

ign

= 1.25 V)

LRC Input Current (V

lrc

= 0 V)

AC AND SWITCHING CHARACTERISTICS

Duty Cycle Regulation Output Frequency (f

osc

/256)

Phase Rotation Detection Frequency

Low/High RPM Transition Phase Frequency

Gate Duty Cycle at Startup and WOT (f

> f2)

Minimum Gate LRC Duty Cycle (f

< f2)

Minimum Gate Duty Cycle (V

bat

> V

reg(max)

)

LRC Increasing Gate Duty Cycle Rate

Low RPM Mode (f

< f2)

LRC1 at Gnd, LRC2 at Gnd

LRC1 Open, LRC2 at Gnd

LRC1 at Gnd, LRC2 Open

LRC1 Open, LRC2 Open

High RPM Mode (f

> f2)

Ignition Turn OFF delay (Lamp ON)

Lamp Short Circuit ON Polling Frequency

Lamp Short Circuit ON Duty Cycle

Lamp OFF Polling Frequency

Lamp Polling OFF Duty Cycle

Field Short Circuit ON Polling Frequency

Field Short Circuit Polling ON Duty Cycle

NOTES:

1. 125 mS Wide Square Wave Pulse.

2. Maximum Time = 2 minutes

Symbol

Lim

g(min)

Tssc

rem

ign

lrc

Min

–

240

400

21.5

1.85

–

Typ

185

300

480

23.4

2.3

Max

–

340

.560

–

2.75

–

Unit

°C

µA

kΩ

µA

start

(LRC)min

min

357

44.28

267.5

2.4

395

296

31.25

3.1

434

53.8

325

34.5

33.5

3.3

%/sec

lrc1

lrc2

lrc3

lrc4

lrc(max)

id(off)

lsc

l(off)

fsc

–

9.31

12.45

18.71

37.42

616

10.2

98.6

1.56

98.6

1.56

98.6

1.56

–

MOTOROLA ANALOG IC DEVICE DATA

More (Only the first 5 pages are displayed. Please Download Datasheet to view the full content.) >

Recommended Resources

Video Game Fishing Circuit

KA2312 (toy) radio remote control transmission control and regulation circuit - typical application circuit

Fully automatic home appliance protector circuit

VSWR bridge

Delay alarm

uPC1278H power amplifier circuit

wince A beginner's confusion: I have always wanted to learn WinCE embedded development, but there is still a long way to go. I used to do WEB program development, but now I want to switch to learning Windows CE. I have a certain u...; betopelec Embedded System

C program for single chip microcomputer to generate positive and negative square wave signals: The chip used is AT89S52. The initial idea is 1: output 1-2MHz square wave signal through one of the output ports P1.1. 2: timer 1 is used as a timer, set the half cycle of the square wave signal to g...; q254947131 Embedded System

Share some information about multi-language fonts.: A few days ago, I saw someone discussing the issue of minority language fonts on the forum. I found that many TXs have encountered similar problems - some hired artists to make fonts, read or converte...; 小杜鹃 Analog electronics

[Nucleo-L432 review] + STM32Cube, Coremark performance test: [size=3]I. Brief introduction of STM32Cube and Coremark[/size][size=3] [/size] 1. STM32Cube is a comprehensive software platform that includes every series of ST products. The platform includes STM32C...; dianhang stm32/stm8

Show the process of WEBENCH design + Butterworth low-pass filter: 1. Select lowpass2. Set the cutoff frequency [img]https://12.eewimg.cn/bbs/data/attachment/forum/201408/17/141719u14424vsbkqs7qky.jpg.thumb.jpg[/img] 3. Select Butterworth filter4. Generate schemati...; nwx8899 Analogue and Mixed Signal

Please explain the principle of phase sensitive detection: I recently learned about synchronous detection and found a circuit (phase-sensitive detection) as shown in Figure 0. The simulation result is shown in Figure 2. I don't know how Figure 1 produced such...; wwwlizhencom Analog electronics

Shortcut: S0 S1 S2 S3 S4 S5 S6 S7 S8 S9 SA SB SC SD SE SF SG SH SI SJ SK SL SM SN SO SP SQ SR SS ST SU SV SW SX SY SZ T0 T1 T2 T3 T4 T5 T6 T7 T8 T9 TA TB TC TD TE TF TG TH TI TJ TK TL TM TN TO TP TQ TR TS TT TU TV TW TX TY TZ U0 U1 U2 U3 U4 U6 U7 U8 UA UB UC UD UE UF UG UH UI UJ UK UL UM UN UP UQ UR US UT UU UV UW UX UZ V0 V1 V2 V3 V4 V5 V6 V7 V8 V9 VA VB VC VD VE VF VG VH VI VJ VK VL VM VN VO VP VQ VR VS VT VU VV VW VX VY VZ W0 W1 W2 W3 W4 W5 W6 W7 W8 W9 WA WB WC WD WE WF WG WH WI WJ WK WL WM WN WO WP WR WS WT WU WV WW WY X0 X1 X2 X3 X4 X5 X7 X8 X9 XA XB XC XD XE XF XG XH XK XL XM XN XO XP XQ XR XS XT XU XV XW XX XY XZ Y0 Y1 Y2 Y4 Y5 Y6 Y9 YA YB YC YD YE YF YG YH YK YL YM YN YP YQ YR YS YT YX Z0 Z1 Z2 Z3 Z4 Z5 Z6 Z8 ZA ZB ZC ZD ZE ZF ZG ZH ZJ ZL ZM ZN ZP ZR ZS ZT ZU ZV ZW ZX ZY

Popular Components
