XH
CONNECTOR
1
High box type
2.5mm pitch/Disconnectable Crimp style connectors
Specifications–––––––––––––––––––
• Current rating: 3A AC, DC (AWG #22)
• Voltage rating: 250V AC, DC
• Temperature range: -25˚C to +85˚C
(including temperature rise in applying
electrical current)
• Contact resistance: Initial value/ 10m
Ω
max.
After environmental testing/ 20m
Ω
max.
• Insulation resistance: 1,000M
Ω
min.
• Withstanding voltage: 1,000V AC/minute
• Applicable wire: AWG #30 to #22
• Applicable PC board thickness: 1.6mm
* Compliant with RoHS.
* Refer to "General Instruction and Notice when using
Terminals and Connectors" at the end of this catalog.
* Contact JST for details.
5
JS
T
XH connector high box type, with
17.0mm mounting height and with 5.8mm
thickness.
• Header for 2.5mm pitch XH connector for
use specifically with resin coated ("potted")
PC boards
• Interchangeability
Standards ––––––––––––––––––––––
1
Certified LR20812
5.75
＋0.1
0
0
Recognized E60389
2.5
±0.05
φ0.9
＋0.1
0
φ1.2
3.4 min
1.6
±0.05
2
±0.05
6.75
Note: 1. The above figure is the figure viewed from the connector mounting side.
2. Tolerances are non-cumulative:
±
0.05mm for all centers.
3. Hole dimensions differ according to the kind of PC board and piercing method. If PC boards made of hard material are used, the hole dimensions should
be larger. The dimensions above should serve as a guideline. Contact JST for details.
Contact
Model No.
SXH-001T-P0.6
SXH-002T-P0.6
Applicable wire
mm
2
AWG#
0.08∼0.33
0.05∼0.13
28∼22
30∼26
14.2
（17）
Insulation O.D. (mm)
0.9∼1.9
0.9∼1.3
Q'ty /
reel
8,000
1.95
2
Material and Finish
2.4
Phosphor bronze, tin-plated (reflow treatment)
6.5
RoHS compliance
Note: 1. Contact JST if you requier gold-plated contacts or contacts made of
brass.
2. Contact JST also if you require shielded wires, thin wires or other
special wires.
Applicator
Dies
Contact
Crimping
machine Crimp applicator
MKS-L
*MKS-SC
Contact
SXH-001T-P0.6
Crimping
machine
AP-K2N
Crimp applicator
MKS-L
*MKS-SC
Crimp applicator with dies
APLMK SXH001-06
APLSC SXH001-06
Applicator
Dies
MK/SXH-002-06
SC/SXH-002-06
Crimp applicator with dies
APLMK SXH002-06
APLSC SXH002-06
MK/SXH-001-06
SC/SXH-001-06
SXH-002T-P0.6
AP-K2N
Note: *Strip-crimp applicator
1
XH CONNECTOR High box type
Housing
Circuits
2
3
4
7.75
Model No.
XHP-2
XHP-3
XHP-4
XHP-5
XHP-6
XHP-7
XHP-8
XHP-9
XHP-10
A
2.5
5.0
7.5
10.0
12.5
15.0
17.5
20.0
22.5
Dimensions (mm)
B
5.7
8.2
10.7
13.2
15.7
18.2
20.7
23.2
25.7
C
7.3
9.8
12.3
14.8
17.3
19.8
22.3
24.8
27.3
Q'ty /
bag
1,000
1,000
1,000
1,000
1,000
1,000
1,000
1,000
1,000
5
6
7
4.1
5.7
8
9
10
Material
Circuit No.1 mark
2.5
A
B
C
PA 6, UL94V-0, natural (white)
RoHS compliance
<For reference>
As the color identification,
the following alphabet shall be put in the underlined part.
For availability, delivery and minimum order quantity, contact JST.
ex.
XHP-2-oo-
(blank)…natural (white)
BK…black R…red E…blue Y…yellow M…green
Shrouded header
Circuits
2.45 2.5
5.75
Model No.
BH2B-XH-2
BH3B-XH-2
BH4B-XH-2
BH5B-XH-2
BH6B-XH-2
BH7B-XH-2
BH8B-XH-2
BH9B-XH-2
BH10B-XH-2
Dimensions (mm)
A
B
2.5
5.0
7.5
10.0
12.5
15.0
17.5
20.0
22.5
7.4
9.9
12.4
14.9
17.4
19.9
22.4
24.9
27.4
Q'ty / box
700
500
300
300
250
200
150
150
150
2
3
4
5
6
14.2
H JST
7
8
9
10
1.5
3.4
Material and Finish
Post: Copper alloy, copper-undercoated, tin-plated (reflow treatment)
Wafer: Glass-filled PA 66, UL94V-0, natural (ivory)
0.64
2
6.75
5.75
φ1
1.6
7.4
RoHS compliance
This product displays (LF)(SN) on a label.
<For reference>
As the color identification,
the following alphabet shall be put in the underlined part.
For availability, delivery and minimum order quantity, contact JST.
ex.
BH2B-XH-2-oo-
(blank)…natural (ivory)
R…red C…black E…blue Y…yellow M…green
6
H JST
14.2
1.5
φ1
2.5
2.45
A
B
0.64
1.6
3.4
2
6.75
2
