REVISION CE
QTE-XXX-XX-XXX-D-XXX
No OF POSITIONS
-020, -040, -060,
*-080, *-100
(PER ROW)
* = (SEE NOTE 11 & 14)
LEAD STYLE
-01: .1680 [4.267]
-02: .2861 [7.267]
-03: .4042 [10.267]
-04: .6010 [15.265]
-05: .7190 [18.263]
-06: .8370 [21.260]
-07: .9540 [24.231]
-08: 1.1510 [29.260]
-09: .5220 [13.258]
.2350 5.969
-10: .5606 [14.239]
REF
PLATING SPECIFICATION
-F: 3µ" FLASH GOLD IN CONTACT AREA,
MATTE TIN ON TAIL
(USE T-1SXX-XX-F, T-1G1-XX-F) (SEE NOTE 07)
-L: 10µ" LIGHT GOLD IN CONTACT AREA,
MATTE TIN ON TAIL
(USE T-1SXX-XX-L, T-1G1-XX-L)
-H: 30µ" HEAVY GOLD IN CONTACT AREA,
3µ" GOLD ON TAIL
(USE T-1SXX-XX-H, T-1G1-XX-G)
-C: 50µ" ELECTRO-POLISHED SELECTIVE IN
CONTACT AREA, MATTE TIN ON TAIL
(USE T-1SXX-XX-C, T-1G1-XX-L)
-STL: 30µ" HEAVY SELECTIVE GOLD IN
CONTACT AREA, TIN LEAD ON TAIL
(USE T-1SXX-XX-STL, T-1G1-XX-STL)
-FTL: 3µ" FLASH SELECTIVE GOLD IN
CONTACT AREA, TIN LEAD ON TAIL
(USE T-1SXX-XX-FTL, T-1G1-XX-FTL)
DO NOT
SCALE FROM
THIS PRINT
* = (SEE NOTE 11 & 14)
* = (SEE NOTE 11 & 14)
.7875 20.003
(TYP)
"A" REF
01
.155 3.94 REF
(SEE NOTE 13)
02
.033 0.84
REF
19 EQ SPCS
@ .0315 [0.800]
=.599[15.20]
(TYP)
"A"
.6450 16.383
REF
.0080 0.203 REF
QTE-20-XX-D-XX-A
"C" REF
.7450 18.923
REF
"D" REF
T-1G1-XX-XXX
OPTION
-A: ALIGNMENT PINS
-LC: LOCKING CLIPS(SEE NOTE 12)
(USE LC-08-TM-01)
(SEE FIG 2, SHT 2)
-K: POLYIMIDE FILM
(USE K-DOT-.276-.375-.005, SEE FIG 3, SHT 2)
(N/A ON STYLE -07 & -08)
-TR: TAPE & REEL (SEE FIG 13, SHT 7)
(60 POS. MAX)
(40 POS. MAX FOR -GP OPTION)
(N/A ON STYLE -05, -06, -07, & -08)
-GP: GUIDE POSTS (SEE FIG 4, SHT 3)
(AVAILABLE ON -01 ONLY)
(USE QTE-20-01-D-XX-GP)
(T & R PACK: 40 POS. MAX.)
-SD: SCREW DOWN (SEE FIG 5, SHT 3)
(AVAILABLE ON -01 ONLY)
(USE QTE-20-01-D-XX-SD)
-FL: FRICTION LOCKS (SEE FIG 9, SHT 5)
(ONLY AVAILABLE ON -01 & -02)
(NOT AVAILABLE WITH -GP, -SD)
-RT1: RETENTION OPTION (SEE FIG 11, SHT 6)
(ONLY AVAILABLE ON -01 LEAD STYLE)
(MUST USE -A OPTION)
(USE QTE-20-01-D-XX-A-RT1 & T-1R36-01-F)
(NOT AVAILABLE WITH -LC, -GP, -SD, OR -FL)
(NOT AVAILABLE ON -100 POS)
-L: LATCHING OPTION (40 POS. MAX.)
(SEE FIG 12, SHT 6) (MUST USE -A OPTION)
(AVAILABLE ON -01 ONLY)
(NOT AVAILABLE WITH -LC, -GP, -SD, -FL,
OR -RT1)
.036 0.91
REF
"A"
ROW SPECIFICATION
-D: DOUBLE (USE QTE-20-XX-D-XX
& QTEH-20-XX-D-XX)
No OF BANKS
.080 2.03
REF
T-1SXX-XX-XXX
(SEE TABLE 1)
.155±.005 3.937±0.127
(SEE NOTE 13)
SEE TABLE 2
.280 7.11
FIG 1
1.
C
REPRESENTS A CRITICAL DIMENSION.
.015 0.38 REF
-A: ALIGNMENT PIN OPTION
2. MINIMUM TERMINAL RETENTION: 8 OZ.
(QTE-060-01-XXX-D-A SHOWN)
3. MINIMUM GROUND PLANE RETENTION: 1 LB.
SECTION "A"-"A"
(STYLE -01, -02 & -03 ONLY)
4. PARTS TO BE MOLDED TO POSITION.
5. MAXIMUM VARIANCE OF .002 [0.05].
6. DIMENSION APPLIES TO TERMINALS AND GROUND PLANE.
UNLESS OTHERWISE SPECIFIED,
PROPRIETARY NOTE
7. T-1SXX-XX-L CAN BE SUBSTITUTED FOR T-1SXX-XX-F.
THIS DOCUMENT CONTAINS INFORMATION
DIMENSIONS ARE IN INCHES.
8. NOTE DELETED.
CONFIDENTIAL AND PROPRIETARY TO
TOLERANCES ARE:
SAMTEC, INC. AND SHALL NOT BE REPRODUCED
9. GROUND PLANE PRESS HEIGHT MUST BE .003[0.08] LESS THAN THE MAX HEIGHT
DECIMALS
ANGLES
OR TRANSFERRED TO OTHER DOCUMENTS OR
OR .001[0.03] GREATER THAN THE MINIMUM HEIGHT OF THE TERMINALS.
DISCLOSED TO OTHERS OR USED FOR ANY
.XX: .01 [0.3]
2
520 PARK EAST BLVD, NEW ALBANY, IN 47150
PURPOSE OTHER THAN THAT WHICH IT WAS
.XXX: .005 [0.13]
10. T-1R36 RETENTION TO BODY TO BE 1.0 LBF.
PHONE: 812-944-6733
FAX: 812-948-5047
OBTAINED WITHOUT THE EXPRESSED WRITTEN
.XXXX: .0020 [0.051]
CONSENT OF SAMTEC, INC.
e-Mail info@SAMTEC.com
code 55322
11. FOR NEW APPLICATIONS REQUIRING THESE POSITIONS, PLEASE CONTACT
SAMTEC INTERCONNECT PROCESSING GROUP.
DO NOT SCALE DRAWING
SHEET SCALE: 1.5:1
MATERIAL:
DESCRIPTION:
12. DUE TO THE HIGH AMOUNT OF INSERTION FORCE NEEDED, THE –LC OPTION IS
.8mm DOUBLE ROW HS TERMINAL ASSEMBLY
INSULATOR: LCP, UL94V-0; COLOR: BLACK
NOT COMPATIBLE WITH AUTO PLACEMENT. SAMTEC RECOMMENDS MANUAL
TERMINAL: PHOS BRONZE
DWG. NO.
PLACEMENT FOR ALL ASSEMBLIES WITH THE –LC OPTION.
GROUND PLANE: PHOS BRONZE
13. PIN CAN EXTEND PAST WALL .003[0.08] MAX.
14. AVAILABLE FOR EXISTING CUSTOMERS ONLY.
09-14-2010
SHEET
1
OF
7
BY:
DEAN P
F:\DWG\MISC\MKTG\QTE-XXX-XX-XXX-D-XXX-MKT.SLDDRW
NOTES:
.035 0.89 REF
.035 0.90 REF
"B"
- .001 [0.03]
(SEE NOTE 9)
+.003 [0.08]
QTE-XXX-XX-XXX-D-XXX
REVISION CE
"E" REF
"F" REF
* = (SEE NOTE 11 & 14)
.3630 9.220
.300 7.62
REF
C
L
.2068 5.251 REF
QTE-20-01-D-XX-X-GP
.125[3.175] REF
-GP: GUIDE POST OPTION
(QTE-060-01-XXX-D-GP SHOWN)
(DIFFERENT AS SHOWN, OTHERWISE SAME AS FIG 1)
(AVAILABLE ON STYLE -01 ONLY)
FIG 4
.100 2.54 REF
C
L
QTE-20-01-D-XX-X-SD
-SD: SCREW DOWN OPTION
(QTE-060-01-XXX-D-A-SD SHOWN)
(DIFFERENT AS SHOWN, OTHERWISE SAME AS FIG 4)
(AVAILABLE ON STYLE -01 ONLY)
FIG 5
PROPRIETARY NOTE
THIS DOCUMENT CONTAINS INFORMATION
CONFIDENTIAL AND PROPRIETARY TO
SAMTEC, INC. AND SHALL NOT BE REPRODUCED
OR TRANSFERRED TO OTHER DOCUMENTS OR
DISCLOSED TO OTHERS OR USED FOR ANY
PURPOSE OTHER THAN THAT WHICH IT WAS
OBTAINED WITHOUT THE EXPRESSED WRITTEN
CONSENT OF SAMTEC, INC.
520 PARK EAST BLVD, NEW ALBANY, IN 47150
PHONE: 812-944-6733
FAX: 812-948-5047
e-Mail info@SAMTEC.com
code 55322
DESCRIPTION:
DWG. NO.
DO NOT SCALE DRAWING
SHEET SCALE: 2:1
.8mm DOUBLE ROW HS TERMINAL ASSEMBLY
QTE-XXX-XX-XXX-D-XXX
09-14-2010
SHEET
3
OF
7
F:\DWG\MISC\MKTG\QTE-XXX-XX-XXX-D-XXX-MKT.SLDDRW
BY:
DEAN P
REVISION CE
01
QTE-060-04-X-D-LC SHOWN
