F-213 SUPPLEMENT
HFWS–06–02–T–S–RA
(5,08 mm) .200"
FWS, HFWS, SW SERIES
SW–10–04–T–S–350–150
FWS–06–01–T–S
POWER TERMINAL STRIP
Mates with:
PSS, HPF
TYPE
STRIP
NO.
PINS
LEAD
STYLE
PLATING
OPTION
S
TAIL
OPTION
OTHER
OPTION
SPECIFICATIONS
For complete specifications
see www.samtec.com?FWS
or www.samtec.com?HFWS
FWS
= Standard Header
FWS/HFWS
–T
= Matte Tin
–VS–P
= Surface
Mount with
Pick & Place Pad
(3 Pos. min.)
(6,98 mm) .275"
min. post height
Insulator Material:
Glass Filled
Polyester (FWS)
Liquid Crystal
Polymer (HFWS)
Terminal Material:
Phosphor Bronze
Plating:
Sn over 50µ" (1,27 µm) Ni
Operating Temp Range:
-55°C to +105°C
Voltage Rating:
500 VAC mated with PSS
RoHS Compliant:
Yes
HFWS
= High Temp
Header
Specify LEAD STYLE
from chart below.
B
(0,51)
.020
E
C
F
Leave blank for Through-Hole
Processing:
(HFWS–VS)
Lead–Free Solderable:
Yes
SMT Lead Coplanarity:
(0,20 mm) .008" max (02-15)
(0,25 mm) .010" max (16-20)
(1,14)
.045
SQ
01 thru 20
(5,08)
.200
TYP
A
(6,35)
.250
D
G
–RA
–VS
(2,54)
.100
–RA
= Right Angle
LEAD
STYLE
A
(4,57)
.180
(4,57)
.180
(4,09)
.161
(4,57)
.180
B
(11,94)
.470
(13,21)
.520
(21,06)
.829
(3,81)
.150
C
—
(2,54)
.100
(4,95)
.195
—
D
—
E
—
F
G
–VS
= Surface Mount
(2 pins/row minimum)
Requires HFWS
CURRENT RATING
(PER CONTACT)
AMBIENT
PSS/FWS
TEMP
20°C
16.3A
40°C
15.0A
60°C
13.0A
95°C
8.7A
4 POSITIONS POWERED
–01
–02
(2,54)
.100
No. of Positions X (5,08) .200
–04
–05
(10,72) (8,64)
.422
.340
(4,57) (8,08) (12,24) (8,38)
.482
.330
.180 .318
(3,96) (13,82)
—
—
.156 .544
—
—
—
—
Mates with:
PSS, HPF
TYPE
STRIP
NO.
PINS
04
PLATING
OPTION
S
STACK
HEIGHT
POST
HEIGHT
SPECIFICATIONS
For complete specifications
see www.samtec.com?SW
Insulator Material:
Glass Filled
Polyester (SW-TH)
Liquid Crystal
Polymer (SW-VS)
Terminal Material:
Phosphor Bronze
Plating:
Sn over 50µ" (1,27 µm) Ni
Operating Temp Range:
-55°C to + 105°C
RoHS Compliant:
Yes
TAIL
OPTION
Leave
blank for
Through-Hole
SW
= Standard
Stacker
–“XXX”
–T
= Matte Tin
= Stacker Height (in inches)
(0,13 mm) .005" increments
Example: –250 = (6,35 mm) .250"
–VS
=Surface
Mount
(2 pins/row
minimum)
–“XXX”
02 thru 20
(5,08)
.200
TYP
POST
HEIGHT
(0,00)
.000
MIN
STACKER
HEIGHT
(22,61) .890
MAX WITH
(0,00) .000
POST
(7,62) .300
MIN
(1,14)
.045
STACKER
HEIGHT
(2,54) (20,83) .820
.100
MAX WITH
(0,00) .000 POST
(5,08) .200
MIN
(2,29)
.090
= Post Height
(in inches)
Processing:
(SW–VS)
Lead-Free Solderable:
Yes
SMT Lead Coplanarity:
(0,20 mm) .008" max.
–VS–P
= Surface
Mount with
Pick &
Place Pad
(3 Pos. min.)
(6,98 mm)
.275" max.
post height
Note:
Some lengths,
styles and options
are non-standard,
non-returnable.
WWW.SAMTEC.COM
