F-213-1
T2SDT–05–24–L–03.00–D–NUX
Choice of
PVC or
Teflon
®
cable
™
(2,00 mm) .0787"
T2SD, T2SDT, ITD2, T1M82 SERIES
Single or
Double ended
Transfer option
available
DISCRETE WIRE JUMPER CABLE
Mates with:
T2M (Requires –T or –TR),
S2M
TYPE
PINS PER
ROW
WIRE
GAUGE
PLATING
OPTION
ASSEMBLED
LENGTH
END
OPTION
END 2
OPTION
SPECIFICATIONS
For complete specifications
see www.samtec.com?T2SD or
www.samtec.com?T2SDT
Insulator Material:
Black LCP
Terminal Material:
FILE NO. E111534
Phosphor Bronze
Plating:
Au over 50µ" (1,27 µm) Ni
Wire:
24, 26, 28 or 30 AWG
Current Rating:
1.9A per contact
(6 contacts powered)
Operating Temp Range:
-35°C to +105°C (PVC)
-55°C to +125°C (*Teflon
®
)
Voltage Rating:
350 VAC
RoHS Compliant:
Yes
T2SD
= Double Row
PVC Cable
T2SDT
= Double Row
*Teflon
®
Cable
(24, 28, 30 Wire
Gauge only)
–05,
–07,
–10,
–15,
–20,
–25,
–30
(Call Samtec
for other
sizes)
–24
–24C
= Color
Coded
Cable
(T2SD
only)
–L
= 10µ"
(0,25 µm)
Gold on
contact
–“XX.XX”
= Wire Length
in Inches
–S = (76,3 mm)
03.00" min.
–D = (82,55 mm)
03.25" min.
No. of positions x
= Single
End
–S
(Only available
with –D, –T
& –TR)
= Double
End
–D
–T
–NUS
= Notch up,
straight
(Pin 1 to Pin N-1)
–26
–28
–30
02
(2,00) .0787 + (4,75) .187
(7,50)
.295
01
(7,00)
.276
(2,00) .0787
= Transfer
End
(Socket on
end 2)
–NDS
= Notch down,
straight
(Pin 1 to Pin 2)
(2,11) .083
(2,64)
.104
–TR
= Transfer
End with
Retention
Latch
on Socket
–NUX
= Notch up,
crossed
(Pin 1 to Pin N)
ALSO
AVAILABLE
Bodies, terminals and
assembly tooling.
Call Samtec.
Assembly
Length
± (3,18)
.125
(15,40)
.606
–NDX
= Notch down,
crossed
(Pin 1 to Pin 1)
(1,30)
.051
–TR
–D–NUS
• Transfer
end
• Retention
latches
APPLICATION
–24C CABLE
COLOR CODING
PIN
1
2
3
4
5
6
7
8
9
10
ETC
TYPE
POSITIONS
PER ROW
ROW
OPTION
TYPE
WIRE
GAUGE
01
PLATING
OPTION
COLOR
BROWN
RED
ORANGE
YELLOW
GREEN
VIOLET
GRAY
WHITE
BLACK
BLUE
REPEAT
ITD2
= Body,
Loose
–05,
–07, –10,
–15, –20,
–25, –30
(Call Samtec
for other sizes)
–D
= Double
Row
T1M82-L
= Contact,
Loose
–2426
= 24 to 26 AWG
–L
= 10µ" (0,25 µm)
Gold on contact
T1M82-R
= Contact,
Full Reel
(17,000 Parts
per Reel)
(16,04)
.631
–2830
= 28 to 30 AWG
*DuPont
™
Teflon
®
is a
registered trademark of the
E.I. du Pont de Nemours
and Company or its affiliates.
Note:
For wiring option
information refer to drawing
on web.
Note:
Some lengths, styles
and options are non-standard,
non-returnable.
(15,40)
.606
(1,30)
.051
(3,17)
.125
(1,27)
.050
DIA
(6.00)
.236
