F-211
TFM–105–01–L–D–RA
TFM–110–01–L–D–RE1–WT
™
(1,27mm) .050"
TFM, TFML SERIES
SYSTEM
TFM–110–01–L–S
TFML–150–01–L–D–LC
TFM–125–01–S–D–WT
THROUGH-HOLE HIGH REL HEADER
SPECIFICATIONS
For complete specifications and
recommended PCB layouts
see www.samtec.com?TFM or
www.samtec.com?TFML
Insulator Material:
Black Liquid
Crystal Polymer
Terminal Material:
Phosphor Bronze
Plating:
Au or Sn over 50µ" (1,27µm) Ni
Voltage Rating:
350 VAC mated with SFM
Operating Temp Range:
-55°C to +125°C
RoHS Compliant:
Yes
Lead-Free Solderable:
Yes
CURRENT RATING
AMBIENT
TFM/SFM
TEMP
5A
20°C
4.5A
40°C
3.9A
60°C
2.6A
95°C
6 POSITIONS (2x3) POWERED
TFM Mates with:
SFM, SFMC, SFSD
TFML Mates with:
SFML, SFSD (–XL option),
SFSDT (–XL option)
Shrouded body for
blind mating
(1,27mm)
.050" pitch
STACK HEIGHT
LEAD STYLE
TFM
SFM
MATED
HEIGHT
(5,97) .235
(5,97) .235
(7,75) .305
(7,75) .305
(9,53) .375
(11,43) .450
• Passes 10 Year MFG
• Locking option
• Locking clip option
• Weld tab option
–01
–03
–11
–13
–21
–31
–01
Locking feature
increases unmating
force (TFML)
Through-hole
Alignment pin or locking
clip options available
TM
COST-SAVING APPLICATIONS
See TFC Series for lower cost plating options.
EXTENDED LIFE PRODUCT
10 year Mixed Flowing Gas with 30µ" Gold
1,000 cycles when mated with SFM
TYPE
STRIP
1
NO. PINS
PER ROW
LEAD
STYLE
Specify
LEAD
STYLE
from
chart
PLATING
OPTION
ROW
OPTION
OPTION
–L
= 10µ"
(0,25µm)
Gold on
post,
Matte Tin
on tail
TFM
= Standard
TFML
= Locking
(Lead style
–01 only)
05, 07,
10, 15, 20,
25, 30, 35,
40, 45, 50
(Call Samtec for
other sizes)
–S
= Single Row
(TFM only)
= Right Angle
(Style –01 only)
–RA
–D
= Double Row
–S
= 30µ"
(0,76µm)
Gold on
post,
Matte Tin
on tail
(2,35)
.093
= Right Angle Elevated
for (1,58mm) .062" PCB
(Requires –WT)
(TFM lead style –01, –D and
5, 10, 15, 20, 25, 30 positions only)
–RE1
(1,27) .050 x
No. of Positions + (3,18) .125
–RE = (1,27) .050 x
No. of Positions + (6,68) .263
LEAD
STYLE
A
B
(4,45)
.175
(5,72)
.225
(1,27)
(1,27)
.050
.050
DOUBLE ROW
(1,91)
.075
(0,46)
.018 DIA
(0,64)
.025
–WT
–01
–03*
–11*
–13*
–21*
–31*
(5,59) .220 (1,97) .078
(5,59) .220 (2,77) .109
(7,37) .290 (1,97) .078
(7,37) .290 (2,77) .109
(9,14) .360 (1,97) .078
(11,05) .435 (1,97) .078
= Right Angle Elevated
for (2,36mm) .093" PCB
(Requires –WT)
(TFM lead style –01, –D and
5, 10, 15, 20, 25, 30 positions only)
–RE2
(6,48)
.255
SINGLE ROW
= Alignment Pin
(N/A with –RA or –LC)
–RE1 & –RE2
(5,72)
.225
–A
* N/A with 07 or -S row option
–RA
(0,51)
.020
(1,27)
.050
= Locking Clip
(Manual placement required)
(N/A with –RA or –A)
–LC
Note:
Other Gold plating
options available.
Contact Samtec.
Note:
Some sizes, styles and
options are non-standard,
non-returnable.
A
B
(0,36).014
(1,27)
.050
DIA
–A
(1,14)
.045
(1,42)
.056
(1,40)
.055
= Weld Tabs
lead style –01 and 05,
05 thru 50 positions only.
(N/A with –A, –LC, –RA or TFML Series)
Mates to SFSS/SFSD –SR & –DR option
–WT
–LC
