NON ISOLATED
2 0 W AT T
k e y
•
•
•
•
SIP SERIES
f e a t u r e s
•
•
•
•
non-isolated buck converter
high efficiency topology
excellent transient response
optional sense and POK pins
open frame construction
voltage trim pin
vertical or horizontal mounting
water washable
IPD’s SIP series of non-isolated converters deliver high efficiency and excellent
transient response in the industry standard SIP package. The SIP series has 12
models with output voltages from 1.2 to 3.3V, and up to 6A of output current. The SIE
model SIP has power OK and remote sense pins, for added flexibility and improved
point of load regulation. The SIP and SIE family are available for vertical or horizontal
mounting. The series features over 7 Million hours MTBF, and use 100% surface
mount construction for maximum reliability.
t e c h n i c a l
i n p u t
voltage range
5 VDC nominal
s p e c i f i c a t i o n s
e f f .
4.5 - 5.5 VDC
v s
l o a d
o u t p u t
setpoint accuracy
±1%
line regulation V
IN
min. - V
IN
max., I
OUT
rated
1.0% Vo
load regulation I
OUT
min. - I
OUT
max., V
IN
nom.
1.0% Vo
ripple and noise, DC - 200MHz
50mV pk-pk
remote sense headroom
0.25V
current limit protection type
hiccup
current limit threshold range, %Io rated
150%
shortcircuit protection type
latching
power good signal (SIE model only), asserts “hi” when Vout is between following thresholds
lower sense threshold, % Vsetpoint
-16% to -10%
upper sense threshold, % Vsetpoint
+10% to +16%
power good signal reference
common ground
Vout ramp up rate, minimum
0.5V/mS
g e n e r a l
remote shutdown
switching frequency
temperature coefficient
ambient operating temperature
minimum required airflow
storage range
humidity max, non-condensing
vibration, 3 axes, 5 min each
MTBF
†
(Bellcore TR-NWT-000332)
safety
weight (approx.)
negative logic
330 KHz
50ppm/°C
0 to
+
55°C
200LFM
-25 to
+
120°C
95%
5 g, 10 - 55Hz
7.1 x 10
6
Hrs.
UL, CSA, EN60950
0.25 oz.
n o t e s
†
MTBF predictions may vary slightly from model to model.
Specifications typically at 25°C, normal line, and full load -
unless otherwise stated.
Specifications subject to change without notice.
118
8 8 8 - I P D
4
7
3
C O N V
e r t e r
2
6
6
8
w w w . i p d c o n v e r t e r s . c o m
NON ISOLATED
2 0 W AT T
m o d e l s
V
IN
(volts)
5
5
5
5
5
5
5
5
5
5
5
5
V
IN
r a n g e
(volts)
4.5
4.5
4.5
4.5
4.5
4.5
4.5
4.5
4.5
4.5
4.5
4.5
-
-
-
-
-
-
-
-
-
-
-
-
5.5
5.5
5.5
5.5
5.5
5.5
5.5
5.5
5.5
5.5
5.5
5.5
I
I N
m ax.
*
(amps)
2.3
2.7
3.1
3.5
4.0
5.1
2.3
2.7
3.1
3.5
4.0
5.1
V
OUT
(volts)
1.2
1.5
1.8
2.1
2.5
3.3
1.2
1.5
1.8
2.1
2.5
3.3
I
OUT
r a t e d
(amps)
6
6
6
6
6
6
6
6
6
6
6
6
efficiency
typ.**
70%
75%
77%
81%
83%
87%
70%
75%
77%
81%
83%
87%
model
SIP501.2E
SIP501.5E
SIP501.8E
SIP502.1E
SIP502.5E
SIP503.3E
SIE501.2
SIE501.5
SIE501.8
SIE502.1
SIE502.5
SIE503.3
* Iin max. at Vin min., Iout rated
** at nominal V
IN
, rated output
specifications are subject to change without notice.
note: For right angle pins, add suffix “R” to model number.
For optional 0.160” pin, add suffix “7” to model number.
m e c h a n i c a l
d r a w i n g
SIP MODEL
.55
(14.0)
1 2 3 4 5
6 7 8 9 10 11
SIE MODEL
.025 SQ.
(.64)
.09
(2.3)
.27 .12
(6.9) (3.0)
.28
(7.1)
.55
(14.0)
1 2 3 4 5
6 7 8 9 10 11
.025 SQ.
(.64)
.09
(2.3)
.27 .12
(6.9) (3.0)
.28
(7.1)
.100
(2.54)
1.900
(48.26)
2.50
(63.5)
.100
(2.54)
1.900
(48.26)
2.50
(63.5)
.55
(14.0)
1 2 3 4 5
6 7 8 9 10 11
1 2 3 4 5
6 7 8 9 10 11
.55
(14.0)
.15(3.8)
.11
(2.8)
.100
(2.54)
.25
(6.4)
.28
(7.1)
.025 SQ.
(.64)
1.900
(48.26)
2.50
(63.5)
.11
(2.8)
.15(3.8)
.100
(2.54)
.28
(7.1)
.025 SQ.
(.64)
1.900
(48.26)
2.50
(63.5)
.25
(6.4)
t h e r m a l
i m p e d a n c e
natural convection
100 LFM
200 LFM
300 LFM
400 LFM
24.4 °C/W
18.3 °C/W
15.0 °C/W
11.1 °C/W
7.9 °C/W
p i n
1
2
3
4
5
6
7
8
9
10
11
f u n c t i o n
+ Vout
+ Vout
sense (SIE)
+V
OUT
ground
ground
+ Vin
+ Vin
Pwr OK (SIE)
trim
enable
t o l e r a n c e s
(unless otherwise speci-
fied)
Inches
.XX
±
.020
.XXX
±
.010
Pin:
±
.002
(Millimeters)
.X
±
0.5
.XX
±
.25
±
.05
Thermal impedance data is dependant
on many environmental factors. The
exact thermal performance should be
validated for specific application.
8 8 8 - I P D
4
7
3
C O N V
e r t e r
2
6
6
8
w w w . i p d c o n v e r t e r s . c o m
119
