FS3A........FS3M
3.0 Amp. Surface Mount Glass Passivated Rectifier
Voltage
50 V to 1000 V
DO-214AB / SMC
Current
3.0 A
R
FEATURES
Low profile package
Ideal for automated placement
Low forward voltage drop
High forward surge current capability
Solder dip 260ºC, 10s
Component in accordance to RoHS 2002/95/EC
and WEEE 2002/96/EC
Meets MSL level 1, per J-STD-020, LF maximum
peak of 260º C
Low leakage current
MECHANICAL DATA
Case
:
DO-214AB (SMC). Epoxy meets UL 94V-0
flammability rating.
Polarity
:
Color band denotes cathode end.
Terminals
:
Matte tin plated leads, solderable per
MIL-STD-750 Method 2026, J-STD-002 and JESD22-B102.
Consumer grade, meets JESD 201 class 1A whisker test.
HE3 suffix for high reliability grade (AEC Q101 qualified),
meets JESD 201 class 2 whisker test.
TYPICAL APPLICATIONS
Used in general purpose rectification of power supplies,
inverters, converters and freewheeling diodes for consumer,
automotive and telecommunication.
Maximun Ratings and Electrical Characteristics at 25°C
FS3A FS3B FS3D FS3G FS3J
FS3K FS3M
T6
800
560
800
T7
1000
700
1000
Marking Code
V
RRM
V
RMS
V
DC
I
F(AV)
I
FSM
V
F
I
R
C
j
R
th (j-l)
R
th (j-a)
T
j
- T
stg
Maximum Recurrent Peak Reverse Voltage (V)
Maximum RMS Voltage (V)
Maximum DC Blocking Voltage (V)
Forward current at T
C
= 75 °C
8.3 ms. peak forward surge current
(Jedec Method)
T1
50
35
50
T2
100
70
100
T3
200
140
200
T4
400
280
400
3.0 A
100 A
1.15 V
10 µA
250 µA
60 pF
T5
600
420
600
Maximum Instantaneous Forward
Voltage at 3.0A
Maximum DC Reverse Current
at Rated DC Blocking Voltage
Typical Thermal Resistance
(5x5 mm
2
x 130 µ Copper Area)
Operating Junction and Storage
Temperature Range
Tc = 25 °C
Tc = 125 °C
Typical Junction Capacitance (1MHz; -4V)
13 °C/W
47 °C/W
-55 to + 150 °C
www.fagorelectronica.com
Document Name: fs3
Version: Jan-12
Page Number: 1/4
FS3A........FS3M
3.0 Amp. Surface Mount Glass Passivated Rectifier
Ratings and Characteristics
(Ta 25 ºC unless otherwise noted)
FORWARD CURRENT DERATING CURVE
I
F(AV)
, average forward rectified current (A)
3.0
2.5
2.0
1.5
1.0
0.5
0
0
25
50
75 100 125 150 175
P.C.B. MOUNTED on
8.0 x 8.0 mm.
COPPER PAD AREAS
TYPICAL FORWARD CHARACTERISTIC
I
F
, instantaneous forward current (A)
100
3.5
10
1
Tc = 25 ºC
0.1
0.6 0.7 0.8 0.9
1
1.1 1.2 1.3
Lead temperature (ºC)
MAXIMUM NON REPETITIVE
PEAK FORWARD SURGE CURRENT
I
FSM
, peak forward surge current (A)
200
100
90
80
70
60
V
F
, instantaneous forward
voltage (V)
I
R
, Instantaneous reverse current (mA)
TYPICAL REVERSE CHARACTERISTIC
100
10
Tc = 125 ºC
1
Tc = 25 ºC
0.1
1
2 4
6
10
20
40
100
20 40
60 80 100 120 140
Number of cycles at 60 Hz
TYPICAL JUNCTION
CAPACITANCE
Tc = 25 ºC
f = 1 MHz
Percent of rated peak
reverse Voltage, %
100
C
j
, junction capacitance (pF)
10
0.1
0.4 1.0
4
10
40 100
V
R
, reverse voltage (V)
www.fagorelectronica.com
Document Name: fs3
Version: Jan-12
Page Number: 3/4
FS3A........FS3M
3.0 Amp. Surface Mount Glass Passivated Rectifier
