LMS1585ACT-ADJ datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Power/power management> The power supply circuit> LMS1585ACT-ADJ

LMS1585ACT-ADJ: Description1.225 V-1.275V ADJUSTABLE POSITIVE LDO REGULATOR, 1.4V DROPOUT, PSFM3, TO-220, 3 PIN; CategoryPower/power management The power supply circuit; File Size1MB，9 Pages; ManufacturerRochester Electronics; Websitehttps://www.rocelec.com/; Environmental Compliance

Download Datasheet Parametric Compare View All

LMS1585ACT-ADJ Overview

1.225 V-1.275V ADJUSTABLE POSITIVE LDO REGULATOR, 1.4V DROPOUT, PSFM3, TO-220, 3 PIN

LMS1585ACT-ADJ Parametric

Parameter Name	Attribute value
Is it lead-free?	Lead free
Is it Rohs certified?	incompatible
Maker	Rochester Electronics
Parts packaging code	SFM
package instruction	TO-220,
Contacts	3
Reach Compliance Code	unknown
Maximum drop-back voltage 1	1.4 V
Maximum Differential Input-Output Voltage	5.75 V
Minimum Differential Input-Output Voltage	1.5 V
JESD-30 code	R-PSFM-T3
JESD-609 code	e0
Humidity sensitivity level	1
Number of functions	1
Number of terminals	3
Working temperatureTJ-Max	125 °C
Working temperature TJ-Min
Maximum output current 1	5 A
Maximum output voltage 1	1.275 V
Minimum output voltage 1	1.225 V
Package body material	PLASTIC/EPOXY
encapsulated code	TO-220
Package shape	RECTANGULAR
Package form	FLANGE MOUNT
Peak Reflow Temperature (Celsius)	260
Certification status	COMMERCIAL
Regulator type	ADJUSTABLE POSITIVE SINGLE OUTPUT LDO REGULATOR
surface mount	NO
technology	BIPOLAR
Terminal surface	TIN LEAD
Terminal form	THROUGH-HOLE
Terminal location	SINGLE
Maximum time at peak reflow temperature	40
