7,6
Ansaughaube
4,2
hood
5,2
Verpackt im Gurt nach DIN IEC 60286-3
9,35
9,05
Tape on Reel Packaging according to DIN IEC 60286-3
Verpackungseinheit: 280 Stück
Packaging unit: 280 pcs
1,5
-0,03
15,85
±0,03
17,78
a8
13,45
a1
1,27
0,75
-0,05
330
3,05
1,55
7,2
1,27
9 x 1,27 = 11,43
14,45
Abspulrichtung -
Reel off Direction
Anforderungsstufe 1
32
Performance Level 1
Kontaktbereich vergoldet
Mating Area gold plating
Anschlussbereich verzinnt 4-6 µm
Terminal Area 4-6 µm tin plating
Koplanarität der Anschlüsse
Leiterplatten-Layout Vorschlag für SMT
PCB-Layout Proposal for SMT
15,85
±0,03
9 x 1,27 = 11,43
2,21
±0,03
1,27
a1
Coplanarity Area of Termination
≤
0,1 mm
a1
≤
0,1 mm
16
BA 7-03 - Standard Bauhöhe
type 7-03 - standard assembly height
Copyright by ERNI GmbH
Proprietary notice pursuant to ISO 16016 to be observed.
Information:
Tolerances
All Dimensions
in mm
Scale
3:1
7,6
2,2
5,5
1,1
0,3
1,2
0,8
1,6
-0,03
All rights reserved.
Only for Information.
To ensure that this is the latest
version of this drawing, please
contact one of the ERNI companies
before using.
b
Index
07.01.2014
Date
Designation
Subject to modification without
prior notice.
Drawing will not be updated.
Federl. SMC-B 20-SMD-BA7-03
Female SMC-B 20-SMD-type7-03
www.ERNI.com
Class
354063
SMCB
I
A3
