BTB20-400CW

Description
400V, 20A, SNUBBERLESS TRIAC, TO-220AB, PLASTIC, TO-220AB, 3 PIN
CategoryAnalog mixed-signal IC    Trigger device
File Size68KB,5 Pages
ManufacturerSTMicroelectronics
Websitehttp://www.st.com/
Environmental Compliance
Download Datasheet Parametric Compare View All

BTB20-400CW Overview

400V, 20A, SNUBBERLESS TRIAC, TO-220AB, PLASTIC, TO-220AB, 3 PIN

BTB20-400CW Parametric

Parameter NameAttribute value
Is it lead-free?Lead free
Is it Rohs certified?conform to
MakerSTMicroelectronics
Parts packaging codeTO-220AB
package instructionPLASTIC, TO-220AB, 3 PIN
Contacts3
Reach Compliance Codenot_compliant
ConfigurationSINGLE
Critical rise rate of minimum off-state voltage250 V/us
Maximum DC gate trigger current35 mA
Maximum DC gate trigger voltage1.5 V
Maximum holding current50 mA
JEDEC-95 codeTO-220AB
JESD-30 codeR-PSFM-T3
JESD-609 codee3
Number of components1
Number of terminals3
Maximum operating temperature125 °C
Minimum operating temperature-40 °C
Package body materialPLASTIC/EPOXY
Package shapeRECTANGULAR
Package formFLANGE MOUNT
Peak Reflow Temperature (Celsius)NOT SPECIFIED
Certification statusNot Qualified
Maximum rms on-state current20 A
Maximum repetitive peak off-state leakage current10 µA
Off-state repetitive peak voltage400 V
surface mountNO
Terminal surfaceMatte Tin (Sn)
Terminal formTHROUGH-HOLE
Terminal locationSINGLE
Maximum time at peak reflow temperatureNOT SPECIFIED
Trigger device typeSNUBBERLESS TRIAC
BTA20 BW/CW
BTB20 BW/CW
SNUBBERLESS TRIACS
.
.
.
.
FEATURES
HIGH COMMUTATION : (dI/dt)c > 18A/ms
without snubber
HIGH SURGE CURRENT : I
TSM
= 200A
V
DRM
UP TO 800V
BTA Family :
INSULATING VOLTAGE = 2500V
(RMS)
(UL RECOGNIZED : E81734)
DESCRIPTION
The BTA/BTB20 BW/CW triac family are high per-
formance glass passivated chips technology.
The SNUBBERLESS™ concept offer suppression
of RC network and it is suitable for application
such as phase control and static switching on in-
ductive or resistive load.
ABSOLUTE RATINGS
(limiting values)
Symbol
IT(RMS)
RMS on-state current
(360° conduction angle)
Non repetitive surge peak on-state current
( Tj initial = 25°C )
I2t value
Critical rate of rise of on-state current
Gate supply : IG = 500mA diG/dt = 1A/µs
Parameter
BTA
BTB
ITSM
A1
A2
G
TO220AB
(Plastic)
Value
Tc = 70
°C
Tc = 90
°C
tp = 8.3 ms
tp = 10 ms
210
200
200
20
100
- 40 to + 150
- 40 to + 125
260
20
Unit
A
A
I2t
dI/dt
tp = 10 ms
Repetitive
F = 50 Hz
Non
Repetitive
A2s
A/µs
Tstg
Tj
Tl
Storage and operating junction temperature range
Maximum lead temperature for soldering during 10 s at 4.5 mm
from case
Parameter
400
°C
°C
°C
Symbol
BTA / BTB20-... BW/CW
600
600
700
700
800
800
Unit
VDRM
VRRM
Repetitive peak off-state voltage
Tj = 125
°C
400
V
March 1995
1/5
