AD1891JP datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Other integrated circuit (IC)> Consumption circuit> AD1891JP

AD1891JP: DescriptionSPECIALTY CONSUMER CIRCUIT, PQCC28, PLASTIC, LCC-28; CategoryOther integrated circuit (IC) Consumption circuit; File Size1MB，11 Pages; ManufacturerRochester Electronics; Websitehttps://www.rocelec.com/

Download Datasheet Parametric Compare View All

AD1891JP Overview

SPECIALTY CONSUMER CIRCUIT, PQCC28, PLASTIC, LCC-28

AD1891JP Parametric

Parameter Name	Attribute value
Is it lead-free?	Contains lead
Is it Rohs certified?	incompatible
Maker	Rochester Electronics
Parts packaging code	QLCC
package instruction	PLASTIC, LCC-28
Contacts	28
Reach Compliance Code	unknown
Commercial integrated circuit types	CONSUMER CIRCUIT
JESD-30 code	S-PQCC-J28
JESD-609 code	e0
length	11.5062 mm
Humidity sensitivity level	NOT SPECIFIED
Number of terminals	28
Maximum operating temperature	85 °C
Minimum operating temperature	-40 °C
Package body material	PLASTIC/EPOXY
encapsulated code	QCCJ
Package shape	SQUARE
Package form	CHIP CARRIER
Peak Reflow Temperature (Celsius)	220
Certification status	COMMERCIAL
Maximum seat height	4.57 mm
Maximum supply voltage (Vsup)	5.5 V
Minimum supply voltage (Vsup)	2.7 V
surface mount	YES
Temperature level	INDUSTRIAL
Terminal surface	TIN LEAD
Terminal form	J BEND
Terminal pitch	1.27 mm
Terminal location	QUAD
Maximum time at peak reflow temperature	30
width	11.5062 mm
