KS5803A datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Other integrated circuit (IC)> Consumption circuit> KS5803A

KS5803A: DescriptionTransmitter IC, PDIP16, 0.300 INCH, DIP-16; CategoryOther integrated circuit (IC) Consumption circuit; File Size37KB，1 Pages; ManufacturerSAMSUNG; Websitehttp://www.samsung.com/Products/Semiconductor/

Download Datasheet Parametric Compare View All

KS5803A Overview

Transmitter IC, PDIP16, 0.300 INCH, DIP-16

KS5803A Parametric

Parameter Name	Attribute value
Maker	SAMSUNG
Parts packaging code	DIP
package instruction	DIP,
Contacts	16
Reach Compliance Code	compliant
Commercial integrated circuit types	TRANSMITTER IC
JESD-30 code	R-PDIP-T16
length	19.4 mm
Number of functions	1
Number of terminals	16
Package body material	PLASTIC/EPOXY
encapsulated code	DIP
Package shape	RECTANGULAR
Package form	IN-LINE
Certification status	Not Qualified
Maximum seat height	5.08 mm
surface mount	NO
Terminal form	THROUGH-HOLE
Terminal pitch	2.54 mm
Terminal location	DUAL
width	7.62 mm

Preview

Download Datasheet

View All

KS5803A Related Products

	KS5803A	KA2194D	KA2193	KA2196D	KA2185	KS5513	KS5803B	KS5410
Description	Transmitter IC, PDIP16, 0.300 INCH, DIP-16	Color Signal Encoder, PDSO24, 0.375 INCH, SOP-24	Support Circuit, PDSO8, 0.225 INCH, SOP-8	Color Signal Encoder, PDSO24, 0.375 INCH, SOP-24	Prescaler, KA21 Series, 1-Func, PDIP20, 0.300 INCH, DIP-20	Consumer Circuit, PDIP32, 0.400 INCH, SDIP-32	Transmitter IC, PDSO20, 0.375 INCH, SOP-20	Transmitter IC, Bipolar, PDSO20, 0.375 INCH, SOP-20
Maker	SAMSUNG	SAMSUNG	SAMSUNG	SAMSUNG	SAMSUNG	SAMSUNG	SAMSUNG	SAMSUNG
Parts packaging code	DIP	SOIC	SOIC	SOIC	DIP	DIP	SOIC	SOIC
package instruction	DIP,	SOP,	SOP,	SOP,	DIP,	DIP,	SOP,	SOP, SOP20,.4
Contacts	16	24	8	24	20	32	20	20
Reach Compliance Code	compliant	unknown	unknown	unknown	unknown	unknown	unknown	unknown
JESD-30 code	R-PDIP-T16	R-PDSO-G24	R-PDSO-G8	R-PDSO-G24	R-PDIP-T20	R-PDIP-T32	R-PDSO-G20	R-PDSO-G20
Number of functions	1	1	1	1	1	1	1	1
Number of terminals	16	24	8	24	20	32	20	20
Package body material	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY
encapsulated code	DIP	SOP	SOP	SOP	DIP	DIP	SOP	SOP
Package shape	RECTANGULAR	RECTANGULAR	RECTANGULAR	RECTANGULAR	RECTANGULAR	RECTANGULAR	RECTANGULAR	RECTANGULAR
Package form	IN-LINE	SMALL OUTLINE	SMALL OUTLINE	SMALL OUTLINE	IN-LINE	IN-LINE	SMALL OUTLINE	SMALL OUTLINE
Certification status	Not Qualified	Not Qualified	Not Qualified	Not Qualified	Not Qualified	Not Qualified	Not Qualified	Not Qualified
surface mount	NO	YES	YES	YES	NO	NO	YES	YES
Terminal form	THROUGH-HOLE	GULL WING	GULL WING	GULL WING	THROUGH-HOLE	THROUGH-HOLE	GULL WING	GULL WING
Terminal location	DUAL	DUAL	DUAL	DUAL	DUAL	DUAL	DUAL	DUAL
Commercial integrated circuit types	TRANSMITTER IC	COLOR SIGNAL ENCODER	SUPPORT CIRCUIT	COLOR SIGNAL ENCODER	-	CONSUMER CIRCUIT	TRANSMITTER IC	TRANSMITTER IC
length	19.4 mm	15.34 mm	4.9 mm	15.34 mm	26.4 mm	-	12.8 mm	12.8 mm
Maximum seat height	5.08 mm	2.7 mm	1.95 mm	2.7 mm	5.08 mm	-	2.65 mm	2.65 mm
Terminal pitch	2.54 mm	1.27 mm	1.27 mm	1.27 mm	2.54 mm	-	1.27 mm	1.27 mm
width	7.62 mm	7.5 mm	3.9 mm	7.5 mm	7.62 mm	-	7.5 mm	7.5 mm
