Ceramic Disc Capacitors
GENERAL PURPOSE, HI-K
(DIELECTRIC CONSTANT Class II/III) TYPE
NCD Series Class II/III
FEATURES
• WIDE SELECTION OF TEMPERATURE CHARACTERISTICS
• HIGH INSULATION RESISTANCE
*See Part Number System for Details
• EXCELLENT HIGH FREQUENCY CHARACTERISTICS
• ECONOMICALLY PRICED
• AVAILABLE WITH FORMED LEADS AND ON TAPE FOR AUTOMATIC
..INSERTION
SPECIFICATIONS
Temperature
Characteristics
Operating
Temperature Range
Capacitance Range
Standard Tolerance
Capacitance Change Over
Temperature Range
Dissipation Factor
Insulation Resistance
Working Voltage Range
Dielectric Withstanding
Voltage (Test Voltage)
Cap. Change
Load Life
Test @ 85°C
D.F. (max.)
1,000 Hours
I.R. (min.)
Test Conditions
Y5F
-30°C ~ +85°C
100pF ~ 0.01μF
±10% (K)
±7.5%
2.5%*
Y5P
-30°C ~ +85°C
Z5U
+10°C ~ +85°C
Z5V
+10°C ~ +85°C
100pF ~ 0.022μF 0.001μF ~ 0.01μF 0.001μF ~ 0.1μF
±10% (K)
±20% (M)
+80%/-20% (Z)
±10%
-55% ~ +22
-82% ~ +22%
5%
2.5%*
5%
Minimum 10,000 Megohms
50Vdc ~ 1KVdc
2.5 Times Rated Voltage For Not Less Than 1 Second, 50mA Maximum
±10%
4%
±10%
±20%
±30%
4%
7.5%
7.5%
1,000 Megohms
1KHz, 1.0V ±02Vrms
1KHz, 0.5V ± 0.1Vrms
* Special low dissipation factor (1.0% max.) Y5F and Y5P dielectrics are also available.
Contact NIC for availability.
®
NIC COMPONENTS CORP.
www.niccomp.com
www.lowESR.com
www.RFpassives.com
www.SMTmagnetics.com
Specifications are subject to change
1
Ceramic Disc Capacitors
NCD 103 M 50
Z5U
J .100LS TR F
RoHS compliant
Optional Packaging
TR = Taped and Reel
TB = Tape and Box (Ammo)
Optional Lead Space (LS) and/or
Lead Length (LL) in inches
Optional Lead Style
C = Cut Lead
D = Inside Kink (Short Leads)
E = Outward Kink (Short Leads)
J = Inside Kink (Long Leads)
K = Outward Kink (Long Leads)
Temperature Coefficient
Working Voltage DC
Tolerance Code
C = ± 0.25pF K = ± 10%
D = ± 0.5pF
M = ± 20%
J = ± 5%
Z = + 80% / - 20%
Capacitance code, expressed in pfd,
First two digits are significant, third digit is no. of
zeros. “R” indicates decimal for under 10pfd.
Series
Body
Diameter
5 ~ 11
>12
Standard
Bulk
6.35 ± 0.8
6.35 ± 0.8
NCD Series Class II/III
Lead Spacing (mm) - S
Standard
Optional Bulk
T&R
mm (inches)
5.0 ± 0.8
5.0 ± 0.8 (0.200LS)
7.5 ± 0.8 (0.295LS)
5.0 ± 0.8
10.0 ± 0.8 (0.395LS)
Optional T&R
mm (inches)
2.5 ± 0.8 (0.100LS)
7.5 ± 0.8 (0.295LS)
10.0 ± 0.8 (0.395LS)
LEAD DIAMETER
0.6MM IS STANDARD
BODY THICKNESS
2 ~ 4MM DEPENDENT ON CV
Standard
500Vdc & Up
Low Voltage
100Vdc & Below
3 max.
23 min.
2 max.
23 min.
STANDARD PRODUCTS AND MAXIMUM DIAMETER (mm)
BY T.C. AND VOLTAGE
Y5F/Y5P*
Cap.
(pF/μF)
100~470pF
560
680
750
820
0.001μF
0.0015
0.0022
0.0027
0.0033
0.0047
0.0056
0.0068
0.0082
0.01
0.015
0.022
0.033
0.047
0.068
0.1
50
100
6
6
6
6
6
6
6
6
7
7
8
9
9
10
12
14
-
-
-
-
-
500
6
6
6
6
6
7
8
9
10
10
12
14
14
16
16
21
-
-
-
-
-
Z5U
Working Voltage (Vdc)
50
50
1K
500 1K
100
100
6
-
-
-
-
6
-
-
-
-
7
-
-
-
-
7
-
-
-
-
7
-
-
-
-
7
6
6
6
-
8
6
6
7
-
10
6
7
7
6
12
6
7
8
6
14
6
7
9
6
14
6
8
10
6
16
6
9
10
6
16
7
9
12
6
18
7
10
12
6
20
7
10
12
6
-
9
14
16
7
-
10
16
18
8
-
8
18
22
7
-
8
21
24
7
-
8/9
24
-
8
-
8/9
26
-
8/9
Z5V
500
-
-
-
-
-
6
6
6
6
7
8
8
8
9
9
10
14
16
16
16
17
1K
-
-
-
-
-
6
6
6
7
8
8
9
10
10
10
12
16
18
21
-
-
S
S
J Style
K Style
5 max.
1.5+0.2
23 min.
1.5+0.2
5 max.
23 min.
S
S
(BULK AND TAPED STYLES)
D Style
E Style
5 max.
1.5+0.2
S
4.7 + 1
1.5+0.2
S
5 max.
4.7 + 1
*.0047μF AND ABOVE NOT AVAILABLE IN Y5F, PLEASE USE Y5P.
NIC RESERVES THE RIGHT TO REQUEST MINIMUM QUANTITIES ON
CERTAIN VALUES.
(BULK ONLY)
®
2
NIC COMPONENTS CORP.
www.niccomp.com
www.lowESR.com
www.RFpassives.com
www.SMTmagnetics.com
Specifications are subject to change
Ceramic Disc Capacitors
AMMO PACK
REEL
Taping Specifications
H
H
≤
372 (14.64")
L
≤
377 (14.84")
W
≤
55 (2.16")
B
D
L
W
D
<
354 (13.93")
=
>
21 (.83") but
B=
<
30 (1.18")
=
W
<
55 (2.16")
=
W
Acceptable to
standard radial type cartridge.
Acceptable to standard radial type cartridge with a few
extra accessories.
PART NUMBER SUFFIX FOR OPTIONAL TAPE & REEL OR TAPE & BOX PACKAGING
Tape & Reel Straight Lead Options
TRF = Tape & Reel with 5mm lead-space
TR.100LSF = Tape & Reel with 2.0mm lead-space
TR.250LSF = Tape & Reel with 6.35mm lead-space
TR.300LSF = Tape & Reel with 7.5mm lead-space
TR.375LSF = Tape & Reel with 9.5mm lead-space
Tape & Reel Crimped Lead Options (J = Inward Crimp, K = Outward Crimp)
JTRF or KTRF = Tape & Reel with 5mm lead-space
JTR.250LSF or KTR.250LSF = Tape & Reel with 6.35mm lead-space
JTR.300LSF or KTR.300LSF = Tape & Reel with 7.5mm lead-space
JTR.375LSF or KTR.375LSF = Tape & Reel with 9.5mm lead-space
Tape & Box Straight Lead Options
TBF = Tape & Reel with 5mm lead-space
TB.100LSF = Tape & Reel with 2.0mm lead-space
TB.250LSF = Tape & Reel with 6.35mm lead-space
TB.300LSF = Tape & Reel with 7.5mm lead-space
TB.375LSF = Tape & Reel with 9.5mm lead-space
Tape & Box Crimped Lead Options (J = Inward Crimp, K = Outward Crimp)
JTBF or KTBF = Tape & Reel with 5mm lead-space
JTB.250LSF or KTBR.250LSF = Tape & Reel with 6.35mm lead-space
JTB.300LSF or KTB.300LSF = Tape & Reel with 7.5mm lead-space
JTB.375LSF or KTB.375LSF = Tape & Reel with 9.5mm lead-space
Notes:
1. The above lead-space options may not be available in all part diameters. Contact NIC for details.
2. Inward "J style" and outward "K style" may not be available in all part diameters and voltages. Contact NIC for details.
®
4
NIC COMPONENTS CORP.
www.niccomp.com
www.lowESR.com
www.RFpassives.com
www.SMTmagnetics.com
Specifications are subject to change
