Multilayer Chip Low Pass Filters
FEATURES
• LOW INSERTION LOSS
• HIGH ATTENTUATION
• INTERNAL SHIELDING
• SMALL SIZE & LOW PROFILE LTCC CONSTRUCTION
• TAPED AND REELED FOR AUTOMATIC INSERTION
includes all homogeneous materials
NGFL Series
RoHS
Compliant
*See Part Number System for Details
CHARACTERISTICS
Case Code
Center Frequency Ranges
Operating Temperature Range
Bandwidth
Resistance to Solder Heat
0402
1710 MHz ~
2450 MHz
0603
870 MHz ~
2450 MHz
0805
902.5 MHz ~
5787.5 MHz
1206
560 MHz ~
2441.5 MHz
-40°C ~ +85°C
±12.5MHz
~ ±200Mhz (Refer to Individual Part Numbers for Specific Values)
+260°C for 10 seconds
DIMENSIONS (mm)
Case Code
NGFL0402
NGFL0603
NGFL0805
NGFL1206
DIMENSIONS (mm)
A
1.0 ± 0.05
1.6 ± 0.10
2.0 ± 0.15
3.2 ± 0.15
B
0.5 ± 0.05
0.8 ± 0.10
1.2 ± 0.15
1.6 ± 0.15
C
0.38 ± 0.05
0.6 ± 0.10
0.95 ± 0.10
0.95 ± 0.10
Refer to Individual Part Number Table
Pin Layout and Dimensions
PART NUMBER SYSTEM
NGFL 0805AB 2R450G
050 TR F
RoHS Compliant
Packaging: TR = Tape & Reel
Bandwidth Code
Frequency Code (Ghz): “R” indicates decimal
Style & Performance Codes (see dimensions and part number tables for details)
Series
®
NIC COMPONENTS CORP.
www.niccomp.com
www.lowESR.com
www.RFpassives.com
www.SMTmagnetics.com
Specifications are subject to change
1
Multilayer Chip Low Pass Filters
NGFL0402 Size
Standard Values - Case Size 0402 (1.0 x 0.5 x 0.38mm)
Part Number
Center
Frequency
(MHz)
1710
2450
Bandwidth
(MHz)
f0 ± 100
f0 ± 50
Max. IL in BW @ 25°C (dB)
0.4dB Min. at 820~920MHz
0.9dB Min. at 1710~2050MHz
0.45
NGFL Series
Attenuation (dB)
Component
Thickness
NGFL0402AG1R710G100TRF
NGFL0402BG2R450G050TRF
10.0dB Min. at 3420~3820MHz
21.0dB Min. at 2×(f0±50) MHz
21.0dB Min. at 3×(f0±50) MHz
0.38 ± 0.05
(Customization Available. Please contact NIC for any center frequency and response customizations)
COMPONENT LAYOUT (in mm)
Style "A"
0.18 ± 0.1
0.25 ± 0.1
LAND PATTERNS (in mm)
Style "A"
0.25
1.0 ± 0.05
0.5 ± 0.05
(4)
(3)
(2)
0.38 ± 0.05
(1)
0.60
0.25
0.60
Style "B"
1.0 ± 0.05
0.5 ± 0.05
0.3 ± 0.1
0.15 ± 0.05
0.3 ± 0.1
0.625
0.38 ± 0.05
(4)
(1)
(3)
(2)
Style "B"
0.2
0.3
0.45
0.2
0.3
0.15 ± 0.05
NGFL0402 Style Code
Style "A"
Style "B"
(1)
Ground
Ground
(2)
Out
Out/In
(3)
Ground
Ground
(4)
In
In/Out
0.45
0.7
®
2
NIC COMPONENTS CORP.
www.niccomp.com
www.lowESR.com
www.RFpassives.com
www.SMTmagnetics.com
Specifications are subject to change
1.45
Multilayer Chip Low Pass Filters
NGFL0603 Size
Standard Values - Case Size 0603 (1.6 x 0.8 x 0.6mm)
Part Number
Center
Frequency
(MHz)
2450
2450
Bandwidth
(MHz)
f0 ± 50.0
f0 ± 200.0
Max. IL in BW
25°C (dB)
0.6
0.4
Attenuation (dB)
NGFL Series
Component
Thickness
NGFL0603AG2R450G050TRF
NGFL0603BG2R450G200TRF
35.0dB min. at 4800 ~ 5000MHz
30.0dB min. at 7200 ~ 7500MHz
27.0dB min. at 4600 ~ 5400MHz
25.0dB min. at 6900 ~ 8100MHz
0.60 ± 0.10
(Customization Available. Please contact NIC for any center frequency and response customizations)
COMPONENT LAYOUT (in mm)
1.6 ± 0.1
0.6 ± 0.1
0.2 ± 0.1
0.8 ± 0.1
0.3 ± 0.1
LAND PATTERNS (in mm)
0.25
0.55
0.2 ± 0.1
0.5 ± 0.1
0.25
(1)
0.15 ± 0.1
(2)
(5)
(3)
(4)
NGFL0603 Style Code
Style A
Style B
(1)
Ground
In
(2)
In
Ground
(3)
Ground
Out
(4)
Ground
NC
(5)
Out
Ground
(6)
Ground
NC
0.3
(6)
0.5
®
NIC COMPONENTS CORP.
www.niccomp.com
www.lowESR.com
www.RFpassives.com
www.SMTmagnetics.com
Specifications are subject to change
3
Multilayer Chip Low Pass Filters
NGFL0805 Size
Standard Values - Case Size 0805 (2.0 x 1.2mm)
Part Number
Center
Frequency
(MHz)
902.5
Bandwidth
(MHz)
f0 ± 12.5
Max. IL in BW
@ 25°C (dB)
0.6
Attenuation (dB)
NGFL Series
Component
Thickness
NGFL0805AG0R902G012TRF
30.0dB Min. at 2×(f0±50)MHz
30.0dB Min. at 3×(f0±50)MHz
27.0dB Min. at 2×(f0±50)MHz
30.0dB Min. at 3×(f0±50)MHz
30.0dB Min. at 4×(f0±50)MHz
27.0dB min. at 2×f0 MHz
0.95 ± 0.10
NGFL0805AG2R450G050TRF
2450
f0 ± 50.0
0.5
NGFL0805BG2R450G050TRF
2450
f0 ± 50.0
0.5
25.0dB min. at 3×f0 MHz
25.0dB min. at 4×f0 MHz
0.95 ± 0.10
(Customization Available. Please contact NIC for any center frequency and response customizations)
COMPONENT LAYOUT (in mm)
Style "A"
0.25 ± 0.1
2.0 ± 0.15
0.95 ± 0.1
0.35 ± 0.15
0.32 ± 0.15
0.33 ± 0.15
LAND PATTERNS (in mm)
Style "A"
0.65
0.5
0.35
(1)
(8)
(7)
0.3 ± 0.1
1.2 ± 0.1
(2)
(6)
(3)
(4)
(5)
0.75
1.5
0.68 ± 0.1
0.15 ± 0.1
0.5
Style "B"
0.22 ± 0.15
2.0 ± 0.15
1.2 ± 0.15
0.95 ± 0.1
1.7 ± 0.15
1.2 ± 0.15
Style "B"
1.65
0.75
0.75
(1)
(4)
(3)
(2)
0.35
0.35
1.5
0.25 ± 0.15
0.95
NGFL0805 Style Code
Style "A"
Style "B"
(1)
Ground
Ground
(2)
NC
Out
(3)
Ground
Ground
(4)
Out
In
(5)
Ground
-
(6)
NC
-
(7)
Ground
-
(8)
In
-
®
4
NIC COMPONENTS CORP.
www.niccomp.com
www.lowESR.com
www.RFpassives.com
www.SMTmagnetics.com
Specifications are subject to change
Multilayer Chip Low Pass Filters
NGFL1206 Size
Standard Values - Case Size 1206 (3.2 x 1.6 x 0.95mm)
Part Number
Center
Frequency
(MHz)
560
Bandwidth
(MHz)
Max. IL in BW
@ 25°C (dB)
1.0dB Min. at 0~400MHz
NGFL1206AG0R560G050TRF
f0 ± 50.0
3.0dB Min. at 560MHz
0.6
NGFL Series
Attenuation (dB)
20.0dB Min. at 660MHz
40.0dB Min. at 680~3000MHz
20.0dB Min. at 660~5500MHz
30.0dB Min. at 2×(f0±41.5)MHz
18.0dB Min. at 3×(f0±41.5)MHz
Component
Thickness
0.95 ± 0.10
NGFL1206BG2R450G041TRF
2441.5
f0 ± 41.5
(Customization Available. Please contact NIC for any center frequency and response customizations)
COMPONENT LAYOUT (in mm)
All Styles
3.2 ± 0.2
0.95 ± 0.2
0.7 ± 0.15
LAND PATTERNS (in mm)
Style "A"
0.6
1.8
(2)
0.5 ± 0.15
2.2
4.3
NGFL1206 Style Code
All Styles
(1)
In
(2)
Ground
(3)
Out
(4)
Ground
Style "B"
2.6
3.4
0.6
0.3
0.8
1.6
3.2
5.5
3.1
1.1
(1)
(3)
®
NIC COMPONENTS CORP.
www.niccomp.com
1.6 ± 0.2
(4)
www.lowESR.com
www.RFpassives.com
www.SMTmagnetics.com
Specifications are subject to change
5
