CPW5-1700-Z050B
Silicon Carbide Schottky Diode Chip
Z-R
ec
R
ectifieR
TM
V
RRM
I
F
= 1700 V
= 50 A
Features
•
•
•
•
•
•
•
1700-Volt Schottky Rectifier
Zero Reverse Recovery
Zero Forward Recovery
High-Frequency Operation
Temperature-Independent Switching Behavior
Extremely Fast Swtitching
Positive Temperature Coefficient on V
F
Chip Outline
Q
c
= 370 nC
Part Number
CPW5-1700-Z050B
Die Size
6.0 x 6.0 mm
2
Anode
Al
Cathode
Ni/Ag
Maximum Ratings
Symbol
V
RRM
V
RSM
V
R
I
F
T
J
, T
stg
T
Proc
Parameter
Repetitive Peak Reverse Voltage
Surge Peak Reverse Voltage
DC Peak Blocking Voltage
Maximum DC Current
Operating Junction and Storage Temperature
Maximum Procesing Temperature
Value Unit
1700
1700
1700
50
-55 to
+175
325
V
V
V
A
˚C
˚C
T
J
=150˚C
Test Conditions
Note
1
10 min Maximum
Note:
1.
Assumes θJC Thermal Resistance < 0.29˚C/W and T
C
= 110˚C
1
CPW5-1700-Z050B Rev. -
Typical Performance
100
T
J
= -55 °C
T
J
= 25 °C
T
J
= 75 °C
T
J
= 125 °C
1.00
75
Reverse Leakage Current, I
RR
(mA)
0.80
T
J
= 175 °C
T
J
= 125 °C
Foward Current, I
F
(A)
0.60
T
J
= 75 °C
50
T
J
= 175 °C
0.40
T
J
= 25 °C
T
J
= -55 °C
25
0.20
0
0
0.5
1
1.5
2
2.5
3
3.5
4
0.00
0
200
400
600
800
1000
1200
1400
1600
1800
Foward Voltage, V
F
(V)
Reverse Voltage, V
R
(V)
Figure 1. Typical Forward Characteristics
4500
4000
3500
Conditions:
T
J
= 25 °C
F
test
= 1 MHz
V
test
= 25 mV
Figure 2. Typical Reverse Characteristics
400
350
Conditions:
T
J
= 25 °
C
Capacitance (pF)
3000
2500
2000
1500
1000
500
0
0.1
1
10
100
1000
Capacitive Charge, Q
C
(nC)
300
250
200
150
100
50
0
0
200
400
600
800
1000
1200
Reverse Voltage, V
R
(V)
Reverse Voltage, V
R
(V)
Figure 3. Typical Capacitance vs. Reverse Voltage
Figure 4. Typical Recovery Charge vs.
Reverse Voltage
3
CPW5-1700-Z050B Rev. -
Chip Dimensions
B
D
C
A
symbol
A
B
C
D
dimension
mm
6.0
6.0
4.4
4.4
inch
0.236
0.236
0.173
0.173
Notes
• RoHS Compliance
The levels of RoHS restricted materials in this product are below the maximum concentration values (also referred
to as the threshold limits) permitted for such substances, or are used in an exempted application, in accordance
with EU Directive 2011/65/EC (RoHS2), as implemented January 2, 2013. RoHS Declarations for this product can
be obtained from your Cree representative or from the Product Documentation sections of www.cree.com.
• REACh Compliance
REACh substances of high concern (SVHCs) information is available for this product. Since the European Chemi-
cal Agency (ECHA) has published notice of their intent to frequently revise the SVHC listing for the foreseeable
future,please contact a Cree representative to insure you get the most up-to-date REACh SVHC Declaration.
REACh banned substance information (REACh Article 67) is also available upon request.
•
This product has not been designed or tested for use in, and is not intended for use in, applications implanted into
the human body nor in applications in which failure of the product could lead to death, personal injury or property
damage, including but not limited to equipment used in the operation of nuclear facilities, life-support machines,
cardiac defibrillators or similar emergency medical equipment, aircraft navigation or communication or control
systems, air traffic control systems, or weapons systems.
Copyright © 2013 Cree, Inc. All rights reserved.
The information in this document is subject to change without notice.
Cree, the Cree logo, and Zero Recovery are registered trademarks of Cree, Inc.
4
CPW5-1700-Z050B Rev. -
Cree, Inc.
4600 Silicon Drive
Durham, NC 27703
USA Tel: +1.919.313.5300
Fax: +1.919.313.5451
www.cree.com/power
