ZM
CONNECTOR
T
JS
Crimp style
ZH connector
ST
1.5mm pitch/Crimp style Wire-to-wire connectors Matable with ZH and ZR receptacles
Insulation displacement
ZR connector
1.5mm pitch connectors allow higher
densities.
• Compact design
• Housing-to-terminal locks
• Both crimp style and insulation
displacement receptacles can be used
• Fully shrouded header resists "rocking"
during mating
3
Assembly layout
ZM/ZH connector
（9.2）
3.6
Plug / ZM connector
Contact
1.05
Housing
B
3.6
2.8
1.0
φ0.5
2.2
3
2
1
1.5
A
1.5
2.85
Applicable wire
Model No.
SMM-003T-P0.5
mm
2
0.05∼0.08
AWG #
30∼28
Insulation O.D.
(mm)
0.7∼0.9
Q´ty /
reel
16,000
Circuits
2
3
9
13
Model No.
ZMR-02
ZMR-03
ZMR-09
ZMR-13
Dimensions (mm)
A
1.5
3.0
12.0
18.0
0.3
8.1
7.0
4.1
3.6
Material and Finish
Phosphor bronze, tin-plated (reflow treatment)
RoHS compliance
Glass-filled PA 66, UL94V-0
Contact
Crimping
machine Crimp applicator
MKS-LS・MKS-L
*MKS-SC
Applicator
Dies
Crimp applicator with dies
SMM-003T-P0.5
AP-K2N
MK/SMM-003-05 APLMK SMM003-05
SC/SMM-003-05 APLSC SMM003-05
Note: *Strip-crimp applicator
330
3
2
1
ZM connector
Specifications –––––––––––––––––––
• Current rating: 0.7A AC, DC max. (AWG #28)
• Voltage rating: 50V AC, DC max. (See Note below.)
• Temperature range: -25˚C to +85˚C
(including temperature rise in applying
electrical current)
• Contact resistance: Initial value/20m
Ω
max.
After environmental testing/30m
Ω
max.
• Insulation resistance:
500M
Ω
min.
• Withstanding voltage: 500V AC/minute
• Applicable wire: AWG #30 to #28
Note: Contacts are exposed at the housing lances.
Care should be taken so that these parts do not touch the
metal section of the chasis.
* Compliant with RoHS.
* Refer to "General Instruction and Notice when using
Terminals and Connectors" at the end of this catalog.
* Contact JST for details.
JS
T
Standards–––––––––––––––––––––––
1
Certified LR20812
0
Recognized E60389
ZM/ZR connector
（9.1）
B
5.5
7.0
16.0
22.0
Q´ty /
bag
2,000
2,000
1,000
1,000
Material
RoHS compliance
ZM CONNECTOR
Receptacle / ZH connector (Crimp style)
Contact
4.0
2.2
0.5
1.0
1.4
1.1
Housing
1.5
1.5
B
A
3.4
0.3
0.3
1.5
Dimensions (mm)
Model No.
SZH-003T-P0.5
mm
2
0.032∼0.08
AWG #
32∼28
Insulation
(mm)
0.5∼0.9
Q´ty /
reel
16,000
Circuits
2
3
9
13
Model No.
ZHR-2
ZHR-3
ZHR-9
ZHR-13
Dimensions (mm)
A
1.5
3.0
12.0
18.0
0.3
4.2
Material and Finish
Phosphor bronze, tin-plated (reflow treatment)
RoHS compliance
PA 66, UL94V-0
Contact
Crimping
machine Crimp applicator
MKS-L
*MKS-SC
Applicator
Dies
MK/SZH-003-05
SC/SZH-003-05
RoHS compliance
Crimp applicator with dies
APLMK SZH003-05
APLSC SZH003-05
SZH-003T-P0.5
AP-K2N
Note: *Strip-crimp applicator
Receptacle / ZR connector (IDC)
Receptacle
A
1.5
1.5
4.4
Circuits
2
3
9
3.1
2.7
Model No.
AWG #30
02ZR-3H-P
03ZR-3H-P
09ZR-3H-P
13ZR-3H-P
AWG #28
02ZR-8M-P
03ZR-8M-P
09ZR-8M-P
13ZR-8M-P
Material
13
JST
B
4.1
Contact: Phosphor bronze, tin-plated (reflow treatment)
Housing: Glass-filled PA 66, UL94V-0
RoHS compliance
3
2
1
B
4.5
6.0
15.0
21.0
Q´ty /
bag
1,000
1,000
1,000
1,000
Material
Dimensions (mm)
A
1.5
3.0
12.0
18.0
B
4.5
6.0
15.0
21.0
Q´ty /
bag
2,000
2,000
2,000
2,000
331
