Continental Device India Limited
An ISO/TS 16949, ISO 9001 and ISO 14001 Certified Company
NPN SILICON PLANAR EPITAXIAL TRANSISTORS
CLD667, CLD667A
TO-92
Plastic Package
E
CB
Low Frequency Power Amplifier
Complementary CLB647/CLB647A
ABSOLUTE MAXIMUM RATINGS (T
a
=25ºC unless specified otherwise)
DESCRIPTION
Collector Base Voltage
Collector Emitter Voltage
Emitter Base Voltage
Collector Current
Collector Current Peak
Collector Power Dissipation
Junction Temperature
Storage Temperature
SYMBOL
V
CBO
V
CEO
V
EBO
I
C
I
CP
P
C
T
j
T
stg
CLD667
120
80
5.0
1.0
2.0
0.9
150
- 55 to +150
CLD667A
120
100
UNITS
V
V
V
A
A
W
ºC
ºC
ABSOLUTE MAXIMUM RATINGS(T
a
=25ºC unless specified otherwise)
DESCRIPTION
Collector Base Voltage
Collector Emitter Voltage
Emitter Base Voltage
Collector Cut Off Current
DC Current Gain
Collector Emitter Saturation Voltage
Base Emitter on Voltage
Transition Frequency
Collector Output Capacitance
*h
FE
Classifications
SYMBOL
V
CBO
V
CEO
V
EBO
I
CBO
*h
FE
TEST CONDITION
I
C
=10µA, I
E
=0
I
C
=1mA, I
B
=0
I
E
=10µA, I
C
=0
V
CB
=100V, I
E
= 0
**V
CE
=5V, I
C
=150mA
**V
CE
=5V, I
C
=500mA
V
CE (sat)
V
BE (on)
f
T
C
Ob
**I
C
=500mA, I
B
=50mA
**V
CE
=5V, I
C
=150mA
**V
CE
=5V, I
C
=150mA
V
CB
=10V, I
E
=0, f=1MHz
CLD667
>120
>80
>5.0
<10
60 - 320
>30
<1.0
<1.5
Typ 140
Typ 12
CLD667A
>120
>100
>5.0
<10
60 - 200
>30
<1.0
<1.5
Typ 140
Typ 12
V
V
MHz
pF
UNITS
V
V
V
µA
CLD667
CLD667A
B : 60 - 120
B : 60 - 120
C : 100 - 200
C : 100 - 200
D : 160 - 320
**Pulse Test
CLD667_667A Rev111209E
Continental Device India Limited
Data Sheet
Page 1 of 4
Customer Notes
CLD667, CLD667A
TO-92
Plastic Package
Component Disposal Instructions
1. CDIL Semiconductor Devices are RoHS compliant, customers are requested to please
dispose as per prevailing Environmental Legislation of their Country.
2.
In Europe, please dispose as per EU Directive 2002/96/EC on Waste Electrical and
Electronic Equipment (WEEE).
Disclaimer
The product information and the selection guides facilitate selection of the CDIL's Semiconductor Device(s) best suited for
application in your product(s) as per your requirement. It is recommended that you completely review our Data Sheet(s) so as to
confirm that the Device(s) meet functionality parameters for your application. The information furnished in the Data Sheet and on
the CDIL Web Site/CD are believed to be accurate and reliable. CDIL however, does not assume responsibility for inaccuracies
or incomplete information. Furthermore, CDIL does not assume liability whatsoever, arising out of the application or use of any
CDIL product; neither does it convey any license under its patent rights nor rights of others. These products are not designed for
use in life saving/support appliances or systems. CDIL customers selling these products (either as individual Semiconductor
Devices or incorporated in their end products), in any life saving/support appliances or systems or applications do so at their own
risk and CDIL will not be responsible for any damages resulting from such sale(s).
CDIL strives for continuous improvement and reserves the right to change the specifications of its products without prior notice.
CDIL is a registered Trademark of
Continental Device India Limited
C-120 Naraina Industrial Area, New Delhi 110 028, India.
Telephone + 91-11-2579 6150, 4141 1112 Fax + 91-11-2579 5290, 4141 1119
email@cdil.com,
www.cdilsemi.com
e-mail: email@cdil.com
www.cdilsemi.com
CLD667_667A Rev111209E
Continental Device India Limited
Data Sheet
Page 4 of 4
