ICM-624-1-TT datasheet, PDF - EEWORLD Datasheet

ICM-624-1-TT: DescriptionIC Socket, DIP24, 24 Contact(s), 2.54mm Term Pitch, 0.6inch Row Spacing, Solder; CategoryThe connector socket; File Size82KB，1 Pages; ManufacturerAdam Tech

Download Datasheet Parametric Compare View All

ICM-624-1-TT Overview

IC Socket, DIP24, 24 Contact(s), 2.54mm Term Pitch, 0.6inch Row Spacing, Solder

Parameter Name	Attribute value
Maker	Adam Tech
Reach Compliance Code	compliant
subject depth	0.177 inch
body length	1.2 inch
Contact to complete cooperation	SN ON NI
Contact completed and terminated	TIN OVER COPPER
Contact material	P-CUSN
Contact style	RND PIN-SKT
current rating	1 A
Device slot type	IC SOCKET
Type of equipment used	DIP24
Dielectric withstand voltage	500VAC V
Shell material	GLASS FILLED POLYBUTYLENE TEREPHTHALATE
Insulation resistance	1000000000 Ω
Manufacturer's serial number	ICM-6
Plug contact pitch	0.1 inch
Installation method	STRAIGHT
Number of contacts	24
Maximum operating temperature	105 °C
Minimum operating temperature	-55 °C
PCB contact pattern	RECTANGULAR
PCB contact row spacing	0.6 mm
Terminal pitch	2.54 mm
Termination type	SOLDER

	ICM-624-1-TT	ICM-640-1-TT
Description	IC Socket, DIP24, 24 Contact(s), 2.54mm Term Pitch, 0.6inch Row Spacing, Solder	IC Socket, DIP40, 40 Contact(s), 2.54mm Term Pitch, 0.6inch Row Spacing, Solder
Maker	Adam Tech	Adam Tech
Reach Compliance Code	compliant	compliant
subject depth	0.177 inch	0.177 inch
body length	1.2 inch	2 inch
Contact to complete cooperation	SN ON NI	SN ON NI
Contact completed and terminated	TIN OVER COPPER	TIN OVER COPPER
Contact material	P-CUSN	P-CUSN
Contact style	RND PIN-SKT	RND PIN-SKT
current rating	1 A	1 A
Device slot type	IC SOCKET	IC SOCKET
Type of equipment used	DIP24	DIP40
Dielectric withstand voltage	500VAC V	500VAC V
Shell material	GLASS FILLED POLYBUTYLENE TEREPHTHALATE	GLASS FILLED POLYBUTYLENE TEREPHTHALATE
Insulation resistance	1000000000 Ω	1000000000 Ω
Manufacturer's serial number	ICM-6	ICM-6
Plug contact pitch	0.1 inch	0.1 inch
Installation method	STRAIGHT	STRAIGHT
Number of contacts	24	40
Maximum operating temperature	105 °C	105 °C
Minimum operating temperature	-55 °C	-55 °C
PCB contact pattern	RECTANGULAR	RECTANGULAR
PCB contact row spacing	0.6 mm	0.6 mm
Terminal pitch	2.54 mm	2.54 mm
Termination type	SOLDER	SOLDER
