SUH
CONNECTOR
Emboss Tape
0.8mm pitch/Disconnectable Crimp style connectors
• SUR header in common use
• Current rating 1.0 A
• Miniaturization
Specifications –––––––––––––––––––
• Current rating: 1.0 A AC, DC (AWG #28)
• Voltage rating: 30 V AC, DC
• Temperature range: -25˚C to +85˚C
(including temperature rise in applying
electrical current)
• Contact resistance: Initial value/ 30 mΩ max.
After environmental tests/ 50 mΩ max.
• Insulation resistance: 100 MΩ min.
• Withstanding voltage: 200 VAC/minute
• Applicable wire: Conductor size/ AWG #32 to #28
Insulation O.D./ 0.5 to 0.6 mm
* Refer to "General Instruction and Notice when using
Terminals and Connectors" at the end of this catalog.
* Contact JST for details.
* Compliant with RoHS.
This SUH connector is developed for
crimping type SUR connector that has
been designed for 0.8 mm pitch wire-to-
board insulation displacement connector.
This connector adopted the first crimping
method in a minimum 0.8 mm pitch of the
wire-to-board type connector. Housing
lance method provides the good workability
and a constriction contact method
provides the excellent contact reliability.
PC board layout and Assembly layout
Top entry type
0.7
Connector outline
±0.1
Standards ––––––––––––––––––––––
1
Certified LR20812
Side entry type
0
Recognized E60389
1.95
1.65
1.2
±0.1
±0.1
0.8
±0.05
0.5
±0.05
4.1
±0.1
0.3
1
±0.1
1.7
2.7
2.75
4.15
2.3
±0.1
1.1
0.5
±0.05
±0.1
0.8
±0.05
2.2
Connector outline
0.7
±0.1
1.2
±0.1
Note: 1. The above figure is the figure viewed from the connector mounting side.
2. Tolerances are non-cumulative:
±
0.03 mm for all centers.
The dimensions above should serve as a guideline. Contact JST for details.
Contact
Model No.
2.52
1.45
0.39
0.7
0.75
0.35
±0.1
1.7
±0.1
mm
2
Applicable wire
AWG#
Insulation O.D. (mm)
32∼28
0.5∼0.6
1.65
Q'ty/
reel
45,000
SSUH-003T-P0.15
0.032∼0.08
Material and Finish
Phosphor bronze, tin-plated (reflow treatment)
RoHS compliance
0.83
Contact
Crimping
machine Crimp applicator
MKS-L-10-4
−
Applicator
Dies
−
Crimp applicator with dies
−
SSUH-003T-P0.15
AP-K2N
MK/SSUH-003-015 APLMK SSUH003-015
1
1.75
SUH CONNECTOR
Housing
With protrusions
C
A
Circuit No.1
0.8
1.65
1.4
Circuits
2
3
4
5
6
10
1.7
Model No.
With protrusions Without protrusions
SUHR-02V-S-B
SUHR-03V-S-B
SUHR-04V-S-B
SUHR-05V-S-B
SUHR-06V-S-B
SUHR-10V-S-B
SUHR-12V-S-B
SUHR-14V-S-B
SUHR-16V-S-B
SUHR-20V-S-B
SUHR-02V-S
SUHR-03V-S
SUHR-04V-S
SUHR-05V-S
SUHR-06V-S
SUHR-10V-S
SUHR-12V-S
SUHR-14V-S
SUHR-16V-S
SUHR-20V-S
Material
Dimensions (mm)
A
2.4
3.2
4.0
4.8
5.6
8.8
10.4
12.0
13.6
16.8
B
0.8
1.6
2.4
3.2
4.0
7.2
8.8
10.4
12.0
15.2
C
4.4
5.2
6.0
6.8
7.6
10.8
12.4
14.0
15.6
18.8
Q'ty/
box
2,000
2,000
2,000
2,000
2,000
1,000
1,000
1,000
1,000
1,000
3.1
12
14
0.8
B
1.25
16
20
Without protrusions
A
Circuit No.1
1.65
LCP, UL94V-0, natural
RoHS compliance
3.1
0.8
B
1.7
1.25
Shrouded header
Top entry type
B
2
Circuits
2
3
4
5
2.7
Model No.
Dimensions (mm)
Q'ty/reel
Side entry type
Top entry type
A
B Top type Side type
0.8
3.8
2,500 3,500
BM02B-SURS-TF SM02B-SURS-TF
BM03B-SURS-TF
BM04B-SURS-TF
―
―
SM03B-SURS-TF
SM04B-SURS-TF
SM05B-SURS-TF
SM06B-SURS-TF
SM10B-SURS-TF
SM12B-SURS-TF
SM14B-SURS-TF
SM16B-SURS-TF
SM20B-SURS-TF
Material and Finish
1.6
2.4
3.2
4.0
7.2
8.8
10.4
12.0
15.2
4.6
5.4
6.2
7.0
10.2
11.8
13.4
15.0
18.2
2,500
2,500
―
―
2,500
2,500
―
―
2,500
3,500
3,500
3,500
3,500
3,500
3,500
3,500
3,500
3,500
6
10
12
BM10B-SURS-TF
BM12B-SURS-TF
―
―
A
0.6
1
14
16
Side entry type
B
A
Circuit No.1
0.8
2.7
20
BM20B-SURS-TF
Contact: Copper alloy, copper-undercoated, tin-plated (reflow treatment)
Wafer: PA, UL94V-0, natural
Solder tab: Brass, copper-undercoated, tin-plated (reflow treatment)
RoHS compliance
This product displays (LF)(SN) on a label.
Note: The products listed above are supplied on embossed-tape.
1.75
1
0.2
1
0.45
2
