Eurostyle Electronic Connectors
One Piece
D
ESCRIPTION
/A
PPLICATION
Designed to European specifications,
these one piece blocks facilitate wire
to PC board connections. While all
blocks are modular and can be
interlocked together to extend the
number of terminals to any length,
molded-to-length versions are also
available.
ONE PIECE CONNECTORS
D
ESIGN
A
DVANTAGES
• Pitches Available
• 2,5mm (0.098”)
• 3,5mm (0.138")
• 5,0mm (0.197")
• 5,08mm (0.200")
• 0.250" (6,35mm)
• 7,0mm (0.276”)
• 10mm (0.394”)
• 10,16mm (0.400”)
• Effective 2,5mm for Double Decker
Design.
• Vertical and horizontal solder pins
available for most lines.
• Available in four connection styles:
• Cage clamp for superior
connection.
• Wire protection for economical
designs.
• Tunnel connection for most
economical designs.
• Screwless clamp for quick
connections.
• Special “interlocking” feature allows
any length connector to be
assembled in modular fashion —
Also available molded to length.
• Thermoplastic insulator housing —
UL94V-0 rated.
• Gold and silver plated terminals
available in addition to standard tin
plating.
• Hot stamped terminal marking
available.
• Test points for direct reading built
into many connectors.
Thomas & Betts Electronics/OEM Division Tel: 901-252-7766 Fax: 901-252-1312
CONNECTOR INDEX
2,5mm Surface Mount with Screwless Clamp ..........................8
3,5mm Standard with Wire Protector ........................................9
3,5mm Standard with Tunnel Connection ..............................10
5mm Standard with Cage Clamp ......................................11, 14
5mm Standard with Wire Protector ..................................12, 15
5mm Standard with Tunnel Connection ..................................13
5mm High Profile with Cage Clamp ........................................16
5mm High Profile with Wire Protector ....................................17
5mm High Profile with Tunnel Connection ..............................18
5mm Angular with Cage Clamp ........................................19, 20
5mm Double Decker with Cage Clamp ............................21, 22
5,08mm Standard with Cage Clamp ......................................23
5,08mm Standard with Wire Protector ....................................24
5,08mm Angular with Cage Clamp..........................................25
5,08mm Angular with Wire Protector ......................................26
5,08mm Double Decker with Cage Clamp..............................27
5,08mm Standard with Screwless Clamp ..............................28
0.250" Standard with Cage Clamp..........................................29
7
Eurostyle Electronic Connectors
One Piece
0.250" STANDARD CONNECTORS
WITH CAGE CLAMP
SERIES 25EV
P
HYSICAL
P
ROPERTIES
Housing:
H
OUSING
M
ATERIAL
:Thermoplastic,
polyester
F
LAMMABILITY
: UL94V-0
C
OLOR
:
Green or Black
Terminal:
C
ONTACTS
:
Bright acid-tin plated copper alloy
S
OLDERABILITY
:
MIL STD 202, Method 208
C
AGE
C
LAMP
:
Zinc plated steel with yellow chro-
mate coating
S
CREWS
:
Zinc plated steel with yellow chromate
coating, M3 rating
.250" Pitch
Terminal:
P
ITCH
(
TERMINAL SPACING
):
0.250"
R
ECOMMENDED
PCB H
OLE
D
IA
.:
0.062" Dia.
R
ECOMMENDED
T
IGHTENING
T
ORQUE
:
5.0 lb. inch
25EV (vertical solder pins)
E
LECTRICAL
P
ROPERTIES
R
ATING
:
10 Amps, 300 volts/15 amps, 150 volts
(limited ratings)
W
IRE
R
ANGE
:
10-22 AWG (solid or stranded)
6,35
(.250)
Typ.
E
NVIRONMENTAL
P
ROPERTIES
M
AX
. O
PERATING
T
EMPERATURE
:
120° C .
3,18
(.125)
Typ.
A
12,44
(.49)
Ordering Information
# OF
.250" VERTICAL
TERMINALS
GREEN
2
25EV-02
3
25EV-03
4
25EV-04
5
25EV-05
6
25EV-06
7
25EV-07
8
25EV-08
9
25EV-09
10
25EV-10
11
25EV-11
12
25EV-12
13
25EV-13
14
25EV-14
15
25EV-15
16
25EV-16
17
25EV-17
18
25EV-18
19
25EV-19
20
25EV-20
21
25EV-21
22
25EV-22
23
25EV-23
24
25EV-24
®
.250" VERTICAL
BLACK
25EV-02-1
25EV-03-1
25EV-04-1
25EV-05-1
25EV-06-1
25EV-07-1
25EV-08-1
25EV-09-1
25EV-10-1
25EV-11-1
25EV-12-1
25EV-13-1
25EV-14-1
25EV-15-1
25EV-16-1
25EV-17-1
25EV-18-1
25EV-19-1
25EV-20-1
25EV-21-1
25EV-22-1
25EV-23-1
25EV-24-1
21,33
(.84)
1,57
(.062)
Typ.
4,57
(.18)
5,08
(.20)
A
0,85 x 0,787
Typ.
(.034 x .031)
4,57
(.18)
Section A-A
6,35
(.250)
LR30811
E54800
Thomas & Betts Electronics/OEM Division Tel: 901-252-7766 Fax: 901-252-1312
Dimensions shown are for reference only. Dimensions are in millimeters.
29
