74ACT1016DC datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > logic> logic> 74ACT1016DC

74ACT1016DC: DescriptionMultiplier, ACT Series, 16-Bit, CMOS, CDIP64, SIDE BRAZED, CERAMIC, DIP-64; Categorylogic logic; File Size297KB，11 Pages; ManufacturerFairchild; Websitehttp://www.fairchildsemi.com/

Download Datasheet Parametric Compare View All

74ACT1016DC Overview

Multiplier, ACT Series, 16-Bit, CMOS, CDIP64, SIDE BRAZED, CERAMIC, DIP-64

74ACT1016DC Parametric

Parameter Name	Attribute value
Maker	Fairchild
Parts packaging code	DIP
package instruction	DIP,
Contacts	64
Reach Compliance Code	unknown
series	ACT
JESD-30 code	R-CDIP-T64
Logic integrated circuit type	MULTIPLIER
Number of digits	16
Number of functions	1
Number of terminals	64
Maximum operating temperature	85 °C
Minimum operating temperature	-40 °C
Output characteristics	3-STATE
Package body material	CERAMIC, METAL-SEALED COFIRED
encapsulated code	DIP
Package shape	RECTANGULAR
Package form	IN-LINE
propagation delay (tpd)	65 ns
Certification status	Not Qualified
Maximum seat height	4.064 mm
Maximum supply voltage (Vsup)	6 V
Minimum supply voltage (Vsup)	2 V
surface mount	NO
technology	CMOS
Temperature level	INDUSTRIAL
Terminal form	THROUGH-HOLE
Terminal pitch	2.54 mm
Terminal location	DUAL
width	22.86 mm

Preview

Download Datasheet

View All

74ACT1016DC Related Products

	74ACT1016DC	54AC1016DM	54ACT1016DM	54ACT1016QMQB	74ACT1016QC	74AC1016DC	54AC1016QM	54AC1016QMQB	74AC1016QC	54ACT1016QM
Description	Multiplier, ACT Series, 16-Bit, CMOS, CDIP64, SIDE BRAZED, CERAMIC, DIP-64	Multiplier, AC Series, 16-Bit, CMOS, CDIP64, SIDE BRAZED, CERAMIC, DIP-64	Multiplier, ACT Series, 16-Bit, CMOS, CDIP64, SIDE BRAZED, CERAMIC, DIP-64	Multiplier, ACT Series, 16-Bit, CMOS, PQCC68, PLASTIC, CC-68	Multiplier, ACT Series, 16-Bit, CMOS, PQCC68, PLASTIC, CC-68	Multiplier, AC Series, 16-Bit, CMOS, CDIP64, SIDE BRAZED, CERAMIC, DIP-64	Multiplier, AC Series, 16-Bit, CMOS, PQCC68, PLASTIC, CC-68	Multiplier, AC Series, 16-Bit, CMOS, PQCC68, PLASTIC, CC-68	Multiplier, AC Series, 16-Bit, CMOS, PQCC68, PLASTIC, CC-68	Multiplier, ACT Series, 16-Bit, CMOS, PQCC68, PLASTIC, CC-68
Parts packaging code	DIP	DIP	DIP	QFN	QFN	DIP	QFN	QFN	QFN	QFN
package instruction	DIP,	DIP,	DIP,	QCCJ,	QCCJ,	DIP,	QCCJ,	QCCJ,	QCCJ,	QCCJ,
Contacts	64	64	64	68	68	64	68	68	68	68
Reach Compliance Code	unknown	unknown	unknown	unknown	unknown	unknown	unknown	unknown	unknown	unknown
series	ACT	AC	ACT	ACT	ACT	AC	AC	AC	AC	ACT
JESD-30 code	R-CDIP-T64	R-CDIP-T64	R-CDIP-T64	S-PQCC-J68	S-PQCC-J68	R-CDIP-T64	S-PQCC-J68	S-PQCC-J68	S-PQCC-J68	S-PQCC-J68
Logic integrated circuit type	MULTIPLIER	MULTIPLIER	MULTIPLIER	MULTIPLIER	MULTIPLIER	MULTIPLIER	MULTIPLIER	MULTIPLIER	MULTIPLIER	MULTIPLIER
Number of digits	16	16	16	16	16	16	16	16	16	16
Number of functions	1	1	1	1	1	1	1	1	1	1
Number of terminals	64	64	64	68	68	64	68	68	68	68
Maximum operating temperature	85 °C	125 °C	125 °C	125 °C	85 °C	85 °C	125 °C	125 °C	85 °C	125 °C
Minimum operating temperature	-40 °C	-55 °C	-55 °C	-55 °C	-40 °C	-40 °C	-55 °C	-55 °C	-40 °C	-55 °C
Output characteristics	3-STATE	3-STATE	3-STATE	3-STATE	3-STATE	3-STATE	3-STATE	3-STATE	3-STATE	3-STATE
Package body material	CERAMIC, METAL-SEALED COFIRED	CERAMIC, METAL-SEALED COFIRED	CERAMIC, METAL-SEALED COFIRED	PLASTIC/EPOXY	PLASTIC/EPOXY	CERAMIC, METAL-SEALED COFIRED	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY
encapsulated code	DIP	DIP	DIP	QCCJ	QCCJ	DIP	QCCJ	QCCJ	QCCJ	QCCJ
Package shape	RECTANGULAR	RECTANGULAR	RECTANGULAR	SQUARE	SQUARE	RECTANGULAR	SQUARE	SQUARE	SQUARE	SQUARE
Package form	IN-LINE	IN-LINE	IN-LINE	CHIP CARRIER	CHIP CARRIER	IN-LINE	CHIP CARRIER	CHIP CARRIER	CHIP CARRIER	CHIP CARRIER
Certification status	Not Qualified	Not Qualified	Not Qualified	Not Qualified	Not Qualified	Not Qualified	Not Qualified	Not Qualified	Not Qualified	Not Qualified
Maximum seat height	4.064 mm	4.064 mm	4.064 mm	5.08 mm	5.08 mm	4.064 mm	5.08 mm	5.08 mm	5.08 mm	5.08 mm
Maximum supply voltage (Vsup)	6 V	6 V	6 V	6 V	6 V	6 V	6 V	6 V	6 V	6 V
Minimum supply voltage (Vsup)	2 V	2 V	2 V	2 V	2 V	2 V	2 V	2 V	2 V	2 V
surface mount	NO	NO	NO	YES	YES	NO	YES	YES	YES	YES
technology	CMOS	CMOS	CMOS	CMOS	CMOS	CMOS	CMOS	CMOS	CMOS	CMOS
Temperature level	INDUSTRIAL	MILITARY	MILITARY	MILITARY	INDUSTRIAL	INDUSTRIAL	MILITARY	MILITARY	INDUSTRIAL	MILITARY
Terminal form	THROUGH-HOLE	THROUGH-HOLE	THROUGH-HOLE	J BEND	J BEND	THROUGH-HOLE	J BEND	J BEND	J BEND	J BEND
Terminal pitch	2.54 mm	2.54 mm	2.54 mm	1.27 mm	1.27 mm	2.54 mm	1.27 mm	1.27 mm	1.27 mm	1.27 mm
Terminal location	DUAL	DUAL	DUAL	QUAD	QUAD	DUAL	QUAD	QUAD	QUAD	QUAD
width	22.86 mm	22.86 mm	22.86 mm	24.2062 mm	24.2062 mm	22.86 mm	24.2062 mm	24.2062 mm	24.2062 mm	24.2062 mm
Maker	Fairchild	Fairchild	-	-	Fairchild	Fairchild	-	-	Fairchild	Fairchild
Base Number Matches	-	1	1	1	1	1	1	1	-	-
length	-	-	-	24.2062 mm	24.2062 mm	-	24.2062 mm	24.2062 mm	24.2062 mm	24.2062 mm
