DG180BA datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Analog mixed-signal IC> The signal circuit> DG180BA

DG180BA: DescriptionDUAL 1-CHANNEL, SGL POLE SGL THROW SWITCH, MBCY10; CategoryAnalog mixed-signal IC The signal circuit; File Size844KB，7 Pages; ManufacturerRochester Electronics; Websitehttps://www.rocelec.com/

Download Datasheet Parametric Compare View All

DG180BA Overview

DUAL 1-CHANNEL, SGL POLE SGL THROW SWITCH, MBCY10

DG180BA Parametric

Parameter Name	Attribute value
Maker	Rochester Electronics
package instruction	,
Reach Compliance Code	unknown
Analog Integrated Circuits - Other Types	SPST
JESD-30 code	O-MBCY-W10
Nominal Negative Supply Voltage (Vsup)	-15 V
Number of channels	1
Number of functions	2
Number of terminals	10
Nominal off-state isolation	55 dB
Maximum on-state resistance (Ron)	15 Ω
Maximum operating temperature	85 °C
Minimum operating temperature	-20 °C
Package body material	METAL
Package shape	ROUND
Package form	CYLINDRICAL
Certification status	COMMERCIAL
Nominal supply voltage (Vsup)	15 V
surface mount	NO
Maximum disconnect time	300 ns
Maximum connection time	350 ns
technology	JFET
Temperature level	OTHER
Terminal surface	NOT SPECIFIED
Terminal form	WIRE
Terminal location	BOTTOM
