8843
Line Filter • AC Inlet • Interchangeable Fusedrawer for / x 1 / " or 5 x 20mm Fuses
1
4
1
4
•
•
•
•
•
•
For cold connections 70° C, Protection Class I
Quick-connect terminals 250 x .032" (6.3 x 0.8mm)
For attenuation graphs, see pages 66-71
For general information on filters, see page 50
For materials, options and accessories, see page 30
For further description see unfiltered 8843, see page 37
recognition
certification
(standard filter only)
UL
CSA
VDE
SEV
1A-10A/250V
1A-10A/250V
1A-10A/250V
1A-10A/250V
File #E72928
File #LR97784
File #32561
File number on request
approval
approval
Standard or
Medical Filter
Standards: UL 1283; CSA C22.2/8; DIN/VDE 0565; IEC 320/C14; EN 60320
Order Number (type)
Note: Casing and fuseholders must be ordered separately. To order fuses, please see page 102.
Casing with standard RFI filter
8843
2-pole fusing
8843.8123.1
8843.8323.1
8843.8623.1
8843.8923.1
In (A)
Ta 40˚C
1A
3A
6A
10A
Un (V)
up to
250V
max.
50/60 Hz
Max. leakage curr.
@ 250V / 50Hz
< 0.5 mA
< 0.5 mA
< 0.5 mA
< 0.5 mA
Cx2
(nF)
47
47
47
47
Cy
(nF)
2.2
2.2
2.2
2.2
L
(mH)
11
1.6
0.8
0.4
Test voltage
L,N E
L N
2700V
DC
2 sec.
1075V
DC
2 sec.
Fuseholder inserts (2 inserts must be
ordered for 2-pole fusing)
8843.0901
for 1/4 x 1 1/4"
(8843-901.60)
(6.3x32mm)
8843.0902
for 5 x 20mm
(8843-902.60)
(8843.N1.140.60)
(8843.N3.140.60)
(8843.N6.140.60)
(8843.N10.140.60)
Values of fuses (time-lag): Isi
≤
In : Operable at 400 Hz (increase leakage current by factor 8 at 250V and 4 at 125V)
Casing with medical RFI filter (low leakage)
8843
2-pole fusing
8843.8123.3
8843.8323.3
8843.8623.3
8843.8923.3
In (A)
Ta 40˚C
1A
3A
6A
10A
Un (V)
up to
250V
max.
50/60 Hz
Max. leakage curr.
@ 250V / 50Hz
< 5
µA
< 5
µA
< 5
µA
< 5
µA
Cx2
(nF)
47
47
47
47
L
(mH)
11
1.6
0.8
0.4
Test voltage
L,N E
L N
2700V
DC
2 sec.
1075V
DC
2 sec.
Fuseholder inserts (2 inserts must be
ordered for each casing)
8843.0901
for 1/4 x 1 1/4"
(6.3x32mm)
(8843-901.60)
8843.0902
for 5 x 20mm
(8843-902.60)
(8843.N1.144.60)
(8843.N3.144.60)
(8843.N6.144.60)
(8843.N10.144.60)
Schurter, Inc. • Phone 707-778-6311 • Fax 707-778-6401 • E-mail info@schurterinc.com • Website http://www.schurterinc.com
59
