SMPB620-C: Description6A, 20V, SILICON, RECTIFIER DIODE, TO-277B,; CategoryDiscrete semiconductor diode; File Size267KB，2 Pages; ManufacturerSECOS; Websitehttp://www.secosgmbh.com/

Download Datasheet Parametric Compare View All

SMPB620-C Overview

6A, 20V, SILICON, RECTIFIER DIODE, TO-277B,

SMPB620-C Parametric

Parameter Name	Attribute value
Maker	SECOS
package instruction	R-PDSO-F3
Reach Compliance Code	compliant
ECCN code	EAR99
application	GENERAL PURPOSE
Shell connection	CATHODE
Configuration	SINGLE
Diode component materials	SILICON
Diode type	RECTIFIER DIODE
Maximum forward voltage (VF)	0.55 V
JEDEC-95 code	TO-277B
JESD-30 code	R-PDSO-F3
Maximum non-repetitive peak forward current	150 A
Number of components	1
Phase	1
Number of terminals	3
Maximum operating temperature	150 °C
Minimum operating temperature	-55 °C
Maximum output current	6 A
Package body material	PLASTIC/EPOXY
Package shape	RECTANGULAR
Package form	SMALL OUTLINE
Maximum repetitive peak reverse voltage	20 V
Maximum reverse current	500 µA
surface mount	YES
technology	SCHOTTKY
Terminal form	FLAT
Terminal location	DUAL

Preview

Download Datasheet

View All

SMPB620 ~ SMPB6100

Elektronische Bauelemente

Voltage 20V ~ 100V

6 Amp Schottky Barrier Rectifiers

RoHS Compliant Product

A suffix of “-C” specifies halogen & lead-free

FEATURES



Super long operating life

Plastic package has Underwriters Laboratory

Flammability Classification 94

TO-277B

MECHANICAL DATA



Case: TO-277B molded plastic body

Polarity: Color band denotes cathode end

Mounting position: ANY

PACKAGE INFORMATION

Package

TO-277B

MPQ

3K

Leader Size

13 inch

REF.

A

B

C

D

E

F

Millimeter

Min.

Max.

6.40

6.60

0.90

1.10

5.70

5.90

1.80

1.95

0.75

0.85

3.45

3.60

REF.

G

H

I

J

K

Millimeter

Min.

Max.

0.85

0.95

3.90

4.10

0.25 REF.

1.75

1.85

2.95

3.05

MAXIMUM RATINGS AND ELECTRICAL CHARACTERISTICS

(Rating 25°C ambient temperature unless otherwise specified. Single phase, half wave, 60Hz, resistive or inductive load.

For capacitive load, de-rate current by 20%.)

Part Number

Parameters

Maximum Repetitive peak Reverse Voltage

Maximum RMS Voltage

Maximum DC Blocking Voltage

Maximum Average Forward Rectified Current@

T

L

=90°C

Peak Forward Surge Current, 8.3ms single half

sine-wave superimposed on rated load

(JEDEC method)

Maximum Forward Voltage @ I

FM

=6A

Maximum DC Reverse Current at

Rated DC Blocking Voltage

Thermal Resistance Junction

Operating and Storage Temperature Range

T

J

=25°C

T

J

=100°C

Symbol

V

RRM

V

RMS

V

DC

I

F(AV)

I

FSM

V

F

I

R

θJC

T

J

,T

STG

0.55

0.5

50

3

-55~150

30

SMPB

620

SMPB

640

SMPB

660

SMPB

6100

Unit

V

A

20

14

20

40

28

40

6

150

60

42

60

100

70

100

0.7

0.85

V

mA

°C / W

°C

http://www.SeCoSGmbH.com/

Any changes of specification will not be informed individually.

29-Jul-2013 Rev. B

Page 1 of 2
