Customer Specification
PART NO. 3515
Construction
Diameters (In)
1) Component 1
a) Conductor
b) Insulation
(1) Color(s)
Cond
1
2
3
4
5
2) Cable Assembly
Color
BROWN
RED
ORANGE
YELLOW
GREEN
Cond
6
7
8
9
10
Color
BLUE
VILOET
SLATE
WHITE
BLACK
Cond
11
12
13
14
15
0.062 +/- 0.002 x
0.930 +/- 0.030
Color
BROWN
RED
ORANGE
YELLOW
GREEN
15 X 1 COND
22 (7/30) AWG TC
0.016" Wall, Nom. PVC
0.030
0.062
15 Components assembled parallel.
Applicable Specifications
1) UL
AWM/STYLE 2555
VW-1
2) Military
a) Component 1
MIL-DTL-16878/2 (Type C)
105°C / 1000 VRMS
80°C / 300 VRMS
Environmental
1) EU Directive 2002/95/EC(RoHS):
All materials used in the manufacture of this part are in compliance with EU Directive
2002/95/EU regarding the restriction of use of certain hazardous substances in electrical and
electronic equipment. Consult Alpha Wire's web site for compliance Date of Manufacture.
2) REACH Regulation (EC 1907/2006):
This product does not contain any of the substances listed on the European Union REACH
Substance of Very High Concern (SVHC) candidate list, dated 30 March 2010, in excess of a
concentration of 0.1% weight/weight.
3) California Proposition 65:
The outer surface materials used in the manufacture of this part meet the requirements of
California Proposition 65.
Properties
Physical & Mechanical Properties
1) Temperature Range
2) Bend Radius
3) Pull Tension
Electrical Properties
1) Voltage Rating
2) Capacitance
3) Inductance
4) Conductor DCR
-55 to 105°C
10X Cable Diameter
82 Lbs, Maximum
(For Engineering purposes only)
1000 VRMS
28 pf/ft @1 kHz, Nominal Conductor to Conductor
0.2 µH/ft, Nominal
16.2 /1000ft @20°C, Nominal
Other
Packaging
a) 100 FT
Flange x Traverse x Barrel (inches)
11 x 1 x 3 Continuous length
[Spool dimensions may vary slightly]
www.alphawire.com
Alpha Wire | 711 Lidgerwood Avenue, Elizabeth, NJ 07207
Tel: 1-800-52 ALPHA (25742)
Although Alpha Wire (“Alpha”) makes every reasonable effort to ensure there accuracy at the time of publication, information and specifications
described herein are subject to errors or omissions and to changes without notice, and the listing of such information and specifications does not
ensure product availability.
Alpha provides the information and specifications herein on an “AS IS” basis, with no representations or warranties, whether express, statutory or
implied. In no event will Alpha be liable for any damages (including consequential, indirect, incidental, special, punitive, or exemplary) whatsoever,
even if Alpha had been advised of the possibility of such damages, whether in an action under contract, negligence or any other theory, arising out
of or in connection with the use, or inability to use, the information or specifications described herein.
Alpha Wire | 711 Lidgerwood Avenue, Elizabeth, NJ 07207
Tel: 1-800-52 ALPHA (25742), Web: www.alphawire.com
RoHS CERTIFICATE OF COMPLIANCE
To Whom It May Concern:
Alpha Wire Part Number:3515
3515 , RoHS-Compliant Commencing With3/1/2005Production
This document certifies that the Alpha part numbers cited above are manufactured in accordancewith Directive 2002/95/EC of the European
Parliament and of the Council of 27 January 2003,better known as the RoHS Directives, with regards to restrictions of the use of certain
hazardoussubstances used in the manufacture of electrical and electronic equipment. The reader is referredto these Directives for the specific
definitions and extents of these Directives.
No Exemptions arerequired for RoHS Compliance on this item.
Substance
Lead
Mercury
Maximum Control Value
0.1% by weight (1000 ppm)
0.1% by weight (1000 ppm)
Cadmium
Hexavalent Chromium
Polybrominated Biphenyls (PBB)
Polybrominated Diphenyl Ethers (PBDE)
Including Deca-BDE
0.01% by weight (100 ppm)
0.1% by weight (1000 ppm)
0.1% by weight (1000 ppm)
0.1% by weight (1000 ppm)
The information provided in this document and disclosure is correct to the best of Alpha Wire'sknowledge, information and belief at the date of its
release. The information provided is designedonly as a general guide for the safe handling, storage, and any other operation of the productitself or
the one that it will become part of. The intent of this document is not to be considered awarranty or quality specification. Regulatory information is
for guidance purposes only. Productusers are responsible for determining the applicability of legislation and regulations based ontheir individual
usage of the product.
Authorized Signatory for the Alpha Wire Company:
Dave Watson, Director of Engineering & QA
11/1/2012
