UNISONIC TECHNOLOGIES CO., LTD
Preliminary
BYC5-600
ULTRAFAST, LOW SWITCHING
LOSS RECTIFIER DIODE
DESCRIPTION
DIODE
The UTC
BYC5-600
is a rectifier diode. It provides the designers
with ultra-fast switching and low switching loss.
The UTC
BYC5-600
is suitable for half-bridge lighting ballasts,
half-bridge/full-bridge switched mode power supplies and active power
factor correction applications.
FEATURES
* Low Reverse Recovery Current
* Ultra-Fast Switching
* Low Switching Loss
* Low Thermal Resistance
SYMBOL
TO-220-2
TO-252
ORDERING INFORMATION
Pin Assignment
1
2
3
K
A
NC
NC
K
A
NC
K
A
Packing
Tube
Tube
Tape Reel
Ordering Number
Package
Lead Free Plating
Halogen Free
BYC5L-600-TA2-T
BYC5G-600-TA2-T
TO-220-2
BYC5L-600-TN3-T
BYC5G-600-TN3-T
TO-252
BYC5L-600-TN3-R
BYC5G-600-TN3-R
TO-252
Note:
Pin Assignment: A: Anode, K: Cathode, Tab: Mounting Base
www.unisonic.com.tw
Copyright © 2013 Unisonic Technologies Co., Ltd
1 of 3
QW-R601-024.c
BYC5-600
ABSOLUTE MAXIMUM RATINGS
Preliminary
DIODE
PARAMETER
SYMBOL
RATINGS
UNIT
Peak Repetitive Reverse Voltage
V
RRM
600
V
Crest Working Reverse Voltage
V
RWM
600
V
Continuous Reverse Voltage
T
Tab
≤
110°C
V
R
500
V
δ
=0.5; with reapplied V
RRM(max)
;
I
F(AV)
Average Forward Current
5
A
T
Tab
≤89°C
Repetitive Peak Forward
δ
=0.5; with reapplied V
RRM(max)
;
I
FRM
10
A
Current
T
Tab
≤
89°C
t = 10ms
40
A
Non-Repetitive Peak Forward t = 8.3ms
I
FSM
Current
sinusoidal; T
J
=150°C prior to
44
A
surge with reapplied V
RWM(max)
Junction Temperature
T
J
150
°C
Storage Temperature
T
STG
-40 ~ +150
°C
Note: Absolute maximum ratings are those values beyond which the device could be permanently damaged.
Absolute maximum ratings are stress ratings only and functional device operation is not implied.
THERMAL CHARACTERISTICS
PARAMETER
SYMBOL
TO-220-2
TO-252
TO-220-2
TO-252
θ
JA
θ
JC
RATINGS
60
80
2.5
3.5
UNIT
°C/W
°C/W
°C/W
°C/W
Junction to Ambient
Junction to Case
ELECTRICAL CHARACTERISTICS
(T
J
=25°C, unless otherwise specified)
PARAMETER
SYMBOL
V
F
I
R
t
RR
I
RRM
V
FR
TEST CONDITIONS
I
F
=5A, T
J
=150°C
I
F
=10A, T
J
=150°C
I
F
=5A
V
R
=600V
V
R
=500V, T
J
=100°C
I
F
=1A, V
R
=30V, dI
F
/dt=50A/μs
I
F
=5A, V
R
=400V,
dI
F
/dt=500A/μs
T
J
=100°C
dI
F
/dt=50A/μs
I
F
=5A, V
R
=400V, T
J
=125°C
dI
F
/dt=500A/μs
I
F
=10A, dI
F
/dt=100A/μs
MIN TYP
1.4
1.75
2.0
9
0.9
30
19
25
0.7
8
9
MAX UNIT
1.75 V
2.2
V
2.9
V
100 µA
3.0 mA
50
ns
ns
30
ns
3
A
11
A
11
V
Forward Voltage
Reverse Current
Reverse Recovery Time
Peak Reverse Recovery Current
Forward Recovery Voltage
UNISONIC TECHNOLOGIES CO., LTD
www.unisonic.com.tw
2 of 3
QW-R601-024.c
BYC5-600
V
IN
150uH typ
I
L
Preliminary
DIODE
TYPICAL CHARACTERISTICS
V
IN
V
IN
=400V d.c.
Output Diode
500V MOSFET
I
D
I
R
I
F
Inductive load
I
L
V
O
=400V d.c.
Fig.1. Typical application, output rectifier in boost
converter power factor correction circuit. Continuous
conduction mode, where the transistor turns on
whilst forward current is still flowing in the diode.
Fig.2. Typical application, freewheeling diode in half
bridge converter. Continuous conduction mode, where
each transistor turns on whilst forward current is still
flowing in the other bridge leg diode.
UTC assumes no responsibility for equipment failures that result from using products at values that
exceed, even momentarily, rated values (such as maximum ratings, operating condition ranges, or
other parameters) listed in products specifications of any and all UTC products described or contained
herein. UTC products are not designed for use in life support appliances, devices or systems where
malfunction of these products can be reasonably expected to result in personal injury. Reproduction in
whole or in part is prohibited without the prior written consent of the copyright owner. The information
presented in this document does not form part of any quotation or contract, is believed to be accurate
and reliable and may be changed without notice.
UNISONIC TECHNOLOGIES CO., LTD
www.unisonic.com.tw
3 of 3
QW-R601-024.c
