D3S4M4001P20 datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Discrete semiconductor> diode> D3S4M4001P20

D3S4M4001P20: DescriptionRectifier Diode, Schottky, 1 Phase, 1 Element, 2A, Silicon,; CategoryDiscrete semiconductor diode; File Size253KB，2 Pages; ManufacturerSHINDENGEN; Websitehttps://www.shindengen.com

Download Datasheet Parametric Compare View All

D3S4M4001P20 Overview

Rectifier Diode, Schottky, 1 Phase, 1 Element, 2A, Silicon,

D3S4M4001P20 Parametric

Parameter Name	Attribute value
Maker	SHINDENGEN
package instruction	O-XALF-W2
Reach Compliance Code	unknown
ECCN code	EAR99
application	GENERAL PURPOSE
Shell connection	ISOLATED
Configuration	SINGLE
Diode component materials	SILICON
Diode type	RECTIFIER DIODE
Maximum forward voltage (VF)	0.55 V
JESD-30 code	O-XALF-W2
Maximum non-repetitive peak forward current	80 A
Number of components	1
Phase	1
Number of terminals	2
Maximum operating temperature	125 °C
Maximum output current	2 A
Package body material	UNSPECIFIED
Package shape	ROUND
Package form	LONG FORM
Certification status	Not Qualified
Maximum reverse current	3500 µA
surface mount	NO
technology	SCHOTTKY
Terminal form	WIRE
Terminal location	AXIAL

Preview

Download Datasheet

View All

D3S4M4001P20 Related Products

	D3S4M4001P20	D3S4M4001P15	D3S4M4003P15	D3S4M4004P20	D3S4M4003P20	D3S4M4004P15	D3S4M4002P7.5
Description	Rectifier Diode, Schottky, 1 Phase, 1 Element, 2A, Silicon,	Rectifier Diode, Schottky, 1 Phase, 1 Element, 2A, Silicon,	Rectifier Diode, Schottky, 1 Phase, 1 Element, 2A, Silicon,	Rectifier Diode, Schottky, 1 Phase, 1 Element, 2A, Silicon,	Rectifier Diode, Schottky, 1 Phase, 1 Element, 2A, Silicon,	Rectifier Diode, Schottky, 1 Phase, 1 Element, 2A, Silicon,	Rectifier Diode, Schottky, 1 Phase, 1 Element, 2A, Silicon,
Reach Compliance Code	unknown	unknown	unknown	unknown	unknown	unknown	unknown
ECCN code	EAR99	EAR99	EAR99	EAR99	EAR99	EAR99	EAR99
application	GENERAL PURPOSE	GENERAL PURPOSE	GENERAL PURPOSE	GENERAL PURPOSE	GENERAL PURPOSE	GENERAL PURPOSE	GENERAL PURPOSE
Shell connection	ISOLATED	ISOLATED	ISOLATED	ISOLATED	ISOLATED	ISOLATED	ISOLATED
Configuration	SINGLE	SINGLE	SINGLE	SINGLE	SINGLE	SINGLE	SINGLE
Diode component materials	SILICON	SILICON	SILICON	SILICON	SILICON	SILICON	SILICON
Diode type	RECTIFIER DIODE	RECTIFIER DIODE	RECTIFIER DIODE	RECTIFIER DIODE	RECTIFIER DIODE	RECTIFIER DIODE	RECTIFIER DIODE
Maximum forward voltage (VF)	0.55 V	0.55 V	0.55 V	0.55 V	0.55 V	0.55 V	0.55 V
JESD-30 code	O-XALF-W2	O-XALF-W2	O-XALF-W2	O-XALF-W2	O-XALF-W2	O-XALF-W2	O-XALF-W2
Maximum non-repetitive peak forward current	80 A	80 A	80 A	80 A	80 A	80 A	80 A
Number of components	1	1	1	1	1	1	1
Phase	1	1	1	1	1	1	1
Number of terminals	2	2	2	2	2	2	2
Maximum operating temperature	125 °C	125 °C	125 °C	125 °C	125 °C	125 °C	125 °C
Maximum output current	2 A	2 A	2 A	2 A	2 A	2 A	2 A
Package body material	UNSPECIFIED	UNSPECIFIED	UNSPECIFIED	UNSPECIFIED	UNSPECIFIED	UNSPECIFIED	UNSPECIFIED
Package shape	ROUND	ROUND	ROUND	ROUND	ROUND	ROUND	ROUND
Package form	LONG FORM	LONG FORM	LONG FORM	LONG FORM	LONG FORM	LONG FORM	LONG FORM
Certification status	Not Qualified	Not Qualified	Not Qualified	Not Qualified	Not Qualified	Not Qualified	Not Qualified
Maximum reverse current	3500 µA	3500 µA	3500 µA	3500 µA	3500 µA	3500 µA	3500 µA
surface mount	NO	NO	NO	NO	NO	NO	NO
technology	SCHOTTKY	SCHOTTKY	SCHOTTKY	SCHOTTKY	SCHOTTKY	SCHOTTKY	SCHOTTKY
Terminal form	WIRE	WIRE	WIRE	WIRE	WIRE	WIRE	WIRE
Terminal location	AXIAL	AXIAL	AXIAL	AXIAL	AXIAL	AXIAL	AXIAL
