Bridgelux RS Array Series

Product Data Sheet DS25

BXRA-27x4000, BXRA-27x7000, BXRA-30x4000, BXRA-30x7000, BXRA-35x4000,

BXRA-35x7000, BXRA-40E4500, BXRA-40E7500, BXRA-5xC5300, BXRA-5xC9000

Introduction

The Bridgelux family of LED Array products delivers high performance, compact and cost-effective solid-

state lighting solutions to serve the general lighting market. These products combine the higher efficacy,

lifetime, and reliability benefits of LEDs with the light output levels of many conventional lighting sources.

The Bridgelux RS Array Series has been specified to enable lamp and luminaire designs with comparable

performance to existing high wattage CFL and HID conventional light sources for retail, commercial,

industrial and outdoor/street lighting applications. Bridgelux Arrays are extremely well equipped for all

types of light-on-demand applications, where they can be instantaneously and smoothly dimmed up or

down without any effect on lifetime, unlike traditional CFL and HID light sources.

The Bridgelux RS Array series provides a high performance alternative to conventional solid state

solutions, delivering between 3400 and 9000 lumens under application conditions in warm, neutral and

cool white color temperatures. These compact high flux density light sources deliver uniform high quality

illumination without pixilation or the multiple shadow effect caused by LED component based solutions,

enabling excellent beam control for precision lighting. To simplify system design for appropriate light

output, Bridgelux LED Arrays are specified to deliver performance under typical use conditions.

These integrated plug and play solutions reduce system complexity and enable miniaturized cost-

effective lamp and luminaire designs. Luminaire designs incorporating these LED Arrays deliver system

level performance comparable to that of 42-55 Watt CFL, 35-90 Watt low pressure sodium, 70-150 Watt

high pressure sodium or 70-200 Watt metal halide based luminaires and feature increased system level

and service life. Typical applications include retail lighting, commercial down lights, high bay, outdoor and

street lights, and entertainment lighting.

Features

•

Compact high flux density light source

Uniform high quality illumination

Minimum 70, 80 and 90 CRI options

Streamlined thermal path

Energy Star / ANSI compliant color

binning structure with 3SDCM options

More energy efficient than incandescent,

halogen and fluorescent lamps

Low voltage DC operation

Instant light with unlimited dimming

5-Year warranty

RoHS compliant and Pb free

Benefits

•

Enhanced optical control

Clean white light without pixilation

High quality true color reproduction

Significantly reduced thermal resistance

and increased operating temperatures

Uniform consistent white light

Lower operating costs

Increased safety

Easy to use with daylight and motion

detectors to enable increased energy

savings

Reduced maintenance costs

Environmentally friendly, no disposal issue

•

1 0 1 P o rt o l a A v e n u e , L i v e rm o re , C A 9 4 5 5 1 • T e l : (9 2 5 ) 5 8 3 -8 4 0 0 • Fa x: (9 2 5 ) 5 8 3 -8 4 0 1 • ww w. b ri d g e l u x. c o m

Product Nomenclature

The part number designation for Bridgelux LED Arrays is explained as follows:

BXRA – AB C DEFG – H – IJ - KLM

Where:

BXRA – Designates product family

AB – Designates the nominal ANSI color temperature; 27 = 2700K; 30 = 3000K, etc.

C - Designates minimum CRI; C = 70, E = 80, G = 90

DEFG - Designates Nominal Flux; 4000 = 4000lm, 7000 = 7000lm, 9000 = 9000lm, etc.

H – Designates configuration

IJ – Designates CCT Bin options

3000K as an example:

00 = Full ANSI: Q3, Q4, R3, R4

03 = 3 SDCM

KLM – Designates wire option

Average Lumen Maintenance Characteristics

Bridgelux projects that its family of LED Array products will deliver, on average, greater than 70% lumen

maintenance after 50,000 hours of operation at the rated forward test current. This performance

assumes constant current operation with case temperature maintained at or below 85°C. For use beyond

these typical operating conditions please consult your Bridgelux sales representative for further

assistance.

These projections are based on a combination of package test data, semiconductor chip reliability data, a

fundamental understanding of package related degradation mechanisms, and performance observed

from products installed in the field using Bridgelux die technology. Bridgelux conducts lumen

maintenance tests per LM80. Observation of design limits is required in order to achieve this projected

lumen maintenance.

Environmental Compliance

Bridgelux is committed to providing environmentally friendly products to the solid-state lighting market.

Bridgelux LED Arrays are compliant to the European Union directives on the restriction of hazardous

substances in electronic equipment, namely the RoHS directive. Bridgelux does not intentionally add the

following restricted materials to LED Array products: lead, mercury, cadmium, hexavalent chromium,

polybrominated biphenyls (PBB) or polybrominated diphenyl ethers (PBDE).

Bridgelux RS Array Series Product Data Sheet DS25 (12/3/11)

Page 3 of 24

UL Recognition

Bridgelux secures UL Recognition for all the LED Array products. We continue to add arrays as they are

recognized by UL. Please refer to the UL file E333389 for the latest list of UL Recognized Arrays.

Bridgelux uses UL Recognized materials with suitable flammability ratings in the LED Array to streamline

the process for customers to secure UL listing of the final luminaire product. Bridgelux recommends that

luminaires are designed with a Class 2 Driver to facilitate the UL listing process.

Minor Product Change Policy

The rigorous qualification testing on products offered by Bridgelux provides performance assurance.

Slight cosmetic changes that do not affect form, fit, or function may occur as Bridgelux continues product

optimization.

Cautionary Statements

CAUTION: CONTACT WITH OPTICAL AREA

Do not touch the optical area of the LED Array. Avoid any contact with the optical area. Applying stress

to the yellow phosphor resin area can result in damage to the LED Array.

Optics and reflectors must not be mounted in contact with the white phosphor resin area or the white ring

that surrounds the yellow phosphor area. Using the white ring to secure optics can result in damage to

the LED Array as the ring is not designed to act as a mechanical locating feature. Optical devices may be

mounted on the top surface of the LED Array substrate outside of the white ring maximum OD as

specified in the product data sheet. Use the mechanical features of the LED Array substrate edges

and/or mounting holes to locate and secure the optical device as needed.

CAUTION: EYE SAFETY

Eye safety classification for the use of Bridgelux LED Arrays is in accordance with IEC specification

EN62471; Photobiological Safety of Lamps and Lamp Systems. Bridgelux LED Arrays are classified as

Risk Group 1 (Low Risk) when operated at or below their rated test current. Please use appropriate

precautions. It is important that employees working with LEDs are trained to use them safely.

CAUTION: RISK OF BURN

Do not touch the LED Array or resin area during operation. Allow the LED Array to cool for a sufficient

period of time before handling. The LED Array may reach elevated temperatures such that it can burn

skin when touched.

CAUTION: CHEMICAL EXPOSURE HAZARD

Exposure to some chemicals commonly used in luminaire manufacturing and assembly can cause

damage to the LED Array. Please consult Application Note AN11 for additional information.

Bridgelux RS Array Series Product Data Sheet DS25 (12/3/11)

Page 4 of 24
