MAFL-009272-CD0AC0-V5 Overview

CATV Diplex Filter

MAFL-009272-CD0AC0
CATV Diplex Filter
5 - 1002 / 1125 - 1675 MHz
Features
75 Ohm
SMT unit
RoHS Compliant
M/A-COM Products
V5
Product Image
Description
M/A-COM’s MAFL-009272-CD0AC0 is a surface
mount diplex filter unit designed for MoCA applica-
tions.
Ordering Information
Part Number
MAFL-009272-CD0AC0
Package
200 Piece Reel
Functional Schematic
Pin Configuration
Function
Common Port
Low Pass Port
High Pass Port
Ground
Not connected
Pin Number
2
10
4
1, 3, 5 - 9
-
Electrical Specifications: T
A
= 25° Z
0
= 75Ω
C,
Parameter
Common to Low
Insertion Loss
5 - 42 MHz
42 - 860 MHz
860 -1002 MHz
Rejection
1130 - 1550 MHz
1550 - 1675 MHz
Common to High
Insertion Loss
1125 - 1675 MHz
Rejection
5 - 1002 MHz
2250 - 2400 MHz
2400 - 2600 MHz
2600 - 3000 MHz
Common Port Return Loss
5 - 600 MHz
600 - 950 MHz
950 - 1002 MHz
1125 - 1200 MHz
1200 - 1550 MHz
1550 - 1675 MHz
Common port voltage transient
Units
Min
Typ
Max
dB
dB
dB
dB
dB
-
-
-
37
36
0.05
0.6
1.5
40
40
0.25
1.0
1.7
-
-
Absolute Maximum Ratings
Parameter
Storage Temperature
Operating Temperature
DC Current
Absolute
Maximum
-40ºC to +85ºC
-40ºC to +85ºC
30mA
250mW
dB
dB
dB
dB
dB
dB
dB
dB
dB
dB
dB
V
-
37
30
18
10
12
11
12
12
11
9.5
-
1.7
40
33
20
12
16
12
13
13
12
11
-
2.0
-
-
-
-
-
-
-
-
-
-
200
RF Power
ADVANCED:
Data Sheets contain information regarding a product M/A-COM Technology Solutions
North America
Tel: 800.366.2266 •
Europe
Tel: +353.21.244.6400
is considering for development. Performance is based on target specifications, simulated results,
India
Tel: +91.80.43537383
China
Tel: +86.21.2407.1588
and/or prototype measurements. Commitment to develop is not guaranteed.
Visit www.macomtech.com for additional data sheets and product information.
PRELIMINARY:
Data Sheets contain information regarding a product M/A-COM Technology
Solutions has under development. Performance is based on engineering tests. Specifications are
typical. Mechanical outline has been fixed. Engineering samples and/or test data may be available.
M/A-COM Technology Solutions Inc. and its affiliates reserve the right to make
Commitment to produce in volume is not guaranteed.
changes to the product(s) or information contained herein without notice.
