MAFL-011026
MoCA Triplex Filter
5 - 85 / 105 - 1002 / 1125 - 1675 MHz
Description
MACOM Technology Solution’s MAFL-011026 is
a surface mount triplex filter designed for MoCA
applications
Rev. V1
Block Diagram
Features
75 Ohm
SMT unit
RoHS compliant
Electrical specifications:T
A
= 25°C, Z
0
75Ω
Parameter
Reverse Path
Insertion loss
5-85 MHz
Rejection
105-126 MHz
126-860 MHz
860-1002 MHz
1125-1675 MHz
1675-3000 MHz
Forward path
Insertion loss
105-126 MHz
126-860 MHz
860-1002 MHz
Rejection
5-38 MHz
38-85 MHz
1125 -1675 MHz
1675-3000 MHz
MoCA Path
Insertion Loss
1125-1150 MHz
1150-1650 MHz
1650-1675 MHz
Rejection
5-85 MHz
85-1002 MHz
2300-3000 MHz
Units
dB
dB
dB
dB
dB
dB
Min
-
62
64
64
60
30
Typ
1.2
70
70
70
64
50
Max
1.5
-
-
-
-
-
Parameter
Input Return Loss
5-85 MHz
105-860MHz
860-1002MHz
1125-1675 MHz
Isolation
Forward to Reverse
5-38 MHz
38-85 MHz
105-126 MHz
126-860 MHz
860-1002 MHz
Forward to MoCA
5-85 MHz
105-126 MHz
126-860 MHz
860-1002 MHz
1125-1150 MHz
1150-1650 MHz
1650-1675 MHz
Units
dB
dB
dB
dB
Min
16
16
12
12
Typ
18
18
16
16
Max
-
-
-
dB
dB
dB
dB
dB
dB
dB
-
-
-
50
43
43
20
1.5
0.75
2.5
55
45
45
30
2.0
1.5
2.75
-
-
-
dB
dB
dB
dB
dB
dB
dB
dB
dB
dB
dB
dB
55
43
60
60
60
49
49
49
49
43
43
43
58
45
65
65
65
70
70
53
55
45
50
50
-
-
-
-
-
-
-
-
-
-
-
dB
dB
dB
dB
dB
dB
-
-
-
49
49
25
2.8
2.5
2.5
70
55
35
3.0
2.7
3.0
-
-
-
Pin Configuration
MoCA Port
Forward Port
Reverse Port
1
4
7
14
2, 3, 5, 6, 8-13, 15-20
Recommended Maximum Ratings
RF power
DC current
Operating temperature
250mW
30mA
-40°C to +85°C
Common Port
Ground
Storage temperature
-40°C to +85°C
M/A-COM
Hazardous Substances, European Union Directive 2002/95/EC.
* Restrictions on
Technology Solutions Inc. (MACOM) and its affiliates reserve the right to make changes to the product(s) or information contained herein without notice.
Visit www.macomtech.com for additional data sheets and product information.
•
North America
Tel: 800.366.2266 / Fax: 978.366.2266
•
Europe
Tel: 44.1908.574.200 / Fax: 44.1908.574.300
•
Asia/Pacific
Tel: 81.44.844.8296 / Fax: 81.44.844.8298
MAFL-011026
MoCA Triplex Filter
5 - 85 / 105 - 1002 / 1125 - 1675 MHz
Filter Dimensions
Rev. V1
Side View
Castellated
Contacts
Orientation
Dot
Top View
Bottom View
Dimensions in mm. Tolerance: .x
0.1 unless otherwise noted
Solder Resist Colour: Black
PCB Pad Finish: ENIG
Application Schematic
Common Port
DNF
DNF
MoCA
Port
DNF
DNF
DNF
Reverse
Port
DNF
Forward
Port
DNF: Do Not Fit
M/A-COM Technology Solutions Inc. (MACOM) and its affiliates reserve the right to make changes to the product(s) or information contained herein without notice.
Visit www.macomtech.com for additional data sheets and product information.
•
North America
Tel: 800.366.2266 / Fax: 978.366.2266
•
Europe
Tel: 44.1908.574.200 / Fax: 44.1908.574.300
•
Asia/Pacific
Tel: 81.44.844.8296 / Fax: 81.44.844.8298
MAFL-011026
MoCA Triplex Filter
5 - 85 / 105 - 1002 / 1125 - 1675 MHz
Recommended Application Layout
Dimensions are millimetres.
Tolerance: .x ± 0.1mm, except where specified.
Rev. V1
Ground plane
Clearance area - no metal
NOTE:
Any deviation from recommended footprint will compromise the filter performance
For optimal filter performance the 4 transmission lines need to be at 75 Ω impedance
Substrate is 1.6mm thick FR4
Track dimension = 1.15mm
Gap dimension = 1.3mm
Recommended Component Values
Description Ref
RES,SMT,0603,Zero Ohm
Do Not Fit (DNF)
CAP,SMT,0402,2.7pF, +/-.25%, 50V,C0G
CAP,SMT,0402,1.3pF +/-0.1pF, 50V, C0G
CAP,SMT,0402,0.6pF,+/-0.1pF,50V,C0G
CAP,SMT,0402,2.0pF,+/-0.1pF,50V,COG
CAP,SMT,0402,7.5pF,+/-0.25pF,50V,C0G
RES,SMT,0402,Zero Ohm
CAP,SMT,0402,3.9pF,+/-2%,50V,C0G
IND, SMT, 0603, 82nH (Coil Craft Wire Ind)
IND, SMT, 0603, 5.6nH (Coil Craft Wire Ind)
IND, SMT, 0603, 6.8nH (Coil Craft Wire Ind)
IND,SMT,0603,12nH
IND,SMT,0603,22nH
Des
C1,L3
C2,C3,C4,C5,
C6,C7,C11,L1
C8
C9
C10
C12
C13
C14,C16
C15
L2
L4
L5
L6
L7
Qty
2
8
1
1
1
1
1
2
1
1
1
1
1
1
It is not recommended to run tracks under the filter.
RF shield should be kept a minimum of 10mm above the filter
A ground is required on the top layer of the application PCB.
Recommended ground pattern shown. A clearance area in the
centre of the application ground is required as shown.
This ground plane is connected to the filter ground plane and
forms a 75 Ω co-planar wave guide for the input and output RF
transmission lines.
M/A-COM Technology Solutions Inc. (MACOM) and its affiliates reserve the right to make changes to the product(s) or information contained herein without notice.
Visit www.macomtech.com for additional data sheets and product information.
•
North America
Tel: 800.366.2266 / Fax: 978.366.2266
•
Europe
Tel: 44.1908.574.200 / Fax: 44.1908.574.300
•
Asia/Pacific
Tel: 81.44.844.8296 / Fax: 81.44.844.8298
MAFL-011026
MoCA Triplex Filter
5 - 85 / 105 - 1002 / 1125 - 1675 MHz
Common Port Return Loss
Reverse Path
Rev. V1
Forward Path
MoCA Path
Reverse to Forward Path Isolation
Forward to MoCA Path Isolation
M/A-COM Technology Solutions Inc. (MACOM) and its affiliates reserve the right to make changes to the product(s) or information contained herein without notice.
Visit www.macomtech.com for additional data sheets and product information.
•
North America
Tel: 800.366.2266 / Fax: 978.366.2266
•
Europe
Tel: 44.1908.574.200 / Fax: 44.1908.574.300
•
Asia/Pacific
Tel: 81.44.844.8296 / Fax: 81.44.844.8298
