PRELIMINARY DATA SHEET
NEC's HIGH NOISE REDUCTION
25 Mbps CMOS OUTPUT TYPE
8-PIN DIP OPTOCOUPLER
DESCRIPTION
PS9661, PS9661L
NEC’s PS9661 and PS9661L are optically coupled isolators containing a GaAlAs LED on the input side and a CMOS
output IC on the output side.
These photocouplers are high common mode transient immunity (CMR), high-speed CMOS output type devices,
making them ideal for high-speed logic interface circuits.
The PS9661 is in a plastic DIP (Dual In-line Package) and the PS9661L is lead bending type (Gull-wing) for surface
mounting.
FEATURES
• High-speed response (25 Mbps)
• High common mode transient immunity (CM
H
, CM
L
=
±20
kV/
µ
s TYP.)
• High isolation voltage (BV = 3 750 Vr.m.s.)
• Pulse width distortion ( | t
PHL
−
t
PLH
| = 3 ns TYP.)
• Ordering number of tape product: PS9661L-E3, E4: 1 000 pcs/reel
APPLICATIONS
• Factory Automation Network
• Measurement equipment
• PDP
The information in this document is subject to change without notice. Before using this document, please confirm that
this is the latest version.
Date Published: August 2005
PS9661, PS9661L
ORDERING INFORMATION (Solder Contains Lead)
Part Number
PS9661
PS9661L
PS9661L-E3
PS9661L-E4
Embossed Tape 1 000 pcs/reel
Package
8-pin DIP
Packing Style
Magazine case 50 pcs
ORDERING INFORMATION (Pb-Free)
Part Number
PS9661-A
PS9661L-A
PS9661L-E3-A
PS9661L-E4-A
Embossed Tape 1 000 pcs/reel
Package
8-pin DIP
Packing Style
Magazine case 50 pcs
ABSOLUTE MAXIMUM RATINGS (T
A
= 25°C, unless otherwise specified)
Parameter
Diode
Detector
Input Voltage
Supply Voltage
Output Voltage
Output Current
Isolation Voltage
*1
Symbol
V
I
V
DD1
,
V
DD2
V
O
I
O
BV
P
T
T
A
T
stg
Ratings
−0.5
to V
DD1
+0.5
0 to 5.5
−0.5
to V
DD2
+0.5
10
3 750
150
−40
to +85
−40
to +125
Unit
V
V
V
mA
Vr.m.s.
mW
°C
°C
Total Power Dissipation
Operating Ambient Temperature
Storage Temperature
*1
AC voltage for 1 minute at T
A
= 25°C, RH = 60% between input and output.
RECOMMENDED OPERATING CONDITIONS (T
A
= 25°C)
Parameter
High Level Input Voltage
Low Level Input Voltage
Supply Voltage
Rise Time
Fall Time
Symbol
V
IH
V
IL
V
DD1
,
V
DD2
t
r
t
f
MIN.
2.0
0
4.5
5.0
TYP.
MAX.
V
DD1
0.8
5.5
100
Unit
V
V
V
ns
Preliminary Data Sheet
PS9661, PS9661L
ELECTRICAL CHARACTERISTICS (Recommended Operating Conditions Unless Otherwise
Specified. Note That V
DD1
= V
DD2
= 5 V.)
Parameter
Diode
Low Level Supply Current
High Level Supply Current
Input Current
Detector
Output Supply Current
Symbol
I
DD1L
I
DD1H
I
I
I
DD2H
I
DD2L
High Level Output Voltage
V
OH
V
I
= 0 V
V
I
= V
DD1
V
I
= 0 V or V
I
= V
DD1
V
I
= V
DD1
V
I
= 0 V
I
O
=
−20
µ
A, V
I
= V
IH
I
O
=
−4
mA, V
I
= V
IH
Low Level Output Voltage
V
OL
I
O
= 20
µ
A, V
I
= V
IL
I
O
= 4 mA, V
I
= V
IL
Coupled
Isolation Resistance
Isolation Capacitance
Propagation Delay Time
(H
→
L)
Propagation Delay Time
(L
→
H)
Pulse Width
Pulse Width Distortion
(PWD)
Propagation Delay Skew
Rise Time
Fall Time
Common Mode
Transient Immunity at
High Level Output
Common Mode
Transient Immunity at
Low Level Output
CM
L
t
PSK
t
r
t
f
CM
H
V
I
= V
DD1
= V
DD2
= 5V,
V
O
>
0.8 V
DD1
, V
CM
= 1 kV, T
A
= 25
°C
V
I
= V
DD1
= V
DD2
= 5V, V
I
=0V
V
O
<
0.8 V
DD1
, V
CM
= 1 kV
10
20
kV/
µ
s
10
9
8
20
10
20
PW
|
t
PHL-
t
PLH
|
40
3
8
ns
t
PLH
23
40
R
I-O
C
I-O
t
PHL
V
I-O
= 1 kV
DC
, RH = 40 to 60%,
T
A
= 25
°C
V = 0 V, f = 1 MHz, T
A
= 25
°C
C
L
= 15 pF, CMOS Signal Levels
10
11
Conditions
MIN.
TYP.
7.5
*1
MAX.
10.0
3.0
10
Unit
mA
Fig.
1
2
3, 4
5
6
7
0.15
−10
7
5
4.4
4.0
5.0
4.8
0.01
0.32
µ
A
mA
9
9
0.1
1.0
V
8
Ω
1.3
20
40
pF
9
*1
Typical values at T
A
= 25
°C
Preliminary Data Sheet
