30.00 in
762 mm
USABLE
SPACE
5
SECTION A-A
19.06 in
484 mm
USABLE SPACE
18.35 in
466 mm
19" MTG
31.50 in
800 mm
6
7
8X
8X
9
8X
TOP VIEW
21.33 in
542 mm
1
5
B
35.00 in
889 mm
(20U)
2
Item Number
Title
REFK - TOP PANEL
REFK - SIDES PANEL
REFK - BOTTOM PANEL
REFK - GLAND PLATE
COMBINATION RAILS TAPPED (PAIR)
FLAT NYLON WASHER 1/4" I.D.
SCREW 1/4-20 X 1/2
SCREW 6-32X1/4 SELF TAPPING
NUT 1/4-20 KEP
Quantity
1
2
1
1
2
8
8
6
8
40.19 in
1021 mm
1
2
3
4
5
6
6X
8
7
A
REAR VIEW
4
A
L.S. VIEW
B
FRONT VIEW
3
.00 in
0 mm
1.21 in
31 mm
1.42 in
36 mm
2.09 in
53 mm
2.93 in
74 mm
3.59 in
91 mm
8
9
SECTION B-B
PART NUMBERS
REFK1903531BK1 PAINTED BLACK TEXTURED
REFK1903531CG1 PAINTED CONT. GRAY TEXTURED
REFK1903531LG1 PAINTED RAL7035 TEXTURED
NOTES
Shipped knockdown for handling ease & protection.
DETAIL C
5/16-18 THRU
.00 in
0 mm
1.18 in
30 mm
1.40 in
35 mm
2.06 in
52 mm
2.90 in
74 mm
3.56 in
90 mm
Data subject to change without notice. Isometric drawing not to scale.
O
4X
.28 in
7 mm
www.hammondmfg.com
BOTTOM VIEW
DETAIL C
PART NO. REFK1903531
