23.25 in
591 mm
USABLE DEPTH
9
7
TOP PANEL REMOVED
1
TOP VIEW
24.50 in
622 mm
21.00 in
533 mm
5
2
O
18.35 in
466 mm
19" MTG
.28 in
7 mm
28.06 in
713 mm
16U
4
17.81 in
452 mm
OPENING
2
Item Number
1
2
3
4
5
6
7
8
9
Title
RCHS - TOP PANEL
RCHS K.D. - SIDE
RCHS - BOTTOM PANEL
RCHS K.D. - PUNCHED COMBO RAILS
BLACK PLASTIC HANDLE
NUT 1/4-20 SPRING
NUT 1/4-20 KEP
SCRW1/4-20 X 1/2
SCREW 1/4-20X1/2 HEX SLOT BOLT
Quantity
1
2
1
4
2
8
8
8
8
30.00 in
762 mm
8
L.S. VIEW
3
FRONT VIEW
R.S. VIEW
PART NUMBERS
RCHS1902824BK1 PAINTED BLACK TEXTURED
RCHS1902824CG1 PAINTED CONT. GRAY TEXTURED
RCHS1902824LG1 PAINTED RAL7035 TEXTURED
NOTES
Shipped knockdown for handling ease & protection.
Data subject to change without notice. Isometric drawing not to scale.
www.hammondmfg.com
BOTTOM VIEW
PART NO. RCHS1902824
