3
1
4
2
23.69 in
602 mm
17.00 in
432 mm
.70 in
18 mm
5
Item Number
Title
MODIFIED PLEXI/VENTED DOOR
WING KNOB LOCK W/ LOC13390 CAM
PLEXI WINDOW - 18.00 X 18.00
DOOR HINGE BODY
BUMPER FEET-RUBBER STICK ON
Quantity
1
1
1
2
2
17.00 in
432 mm
A
23.28 in
591 mm
1
2
3
4
5
WINDOW
AREA
FRONT VIEW
R.S. VIEW
PART NUMBERS
RCSC19021WDBK1 PAINTED BLACK TEXTURED
NOTES
DETAIL A
0.28 X 1.00
VENTILATION SLOTS
TYP AS SHOWN
Data subject to change without notice. Isometric drawing not to scale.
BOTTOM VIEW
www.hammondmfg.com
PART NO.
RCSC19021WD
