Shielded Power Inductors – LPS6235
• Low DCR; high current; shielded construction
• Perfect for backlight applications
Designer’s Kit C345
contains 3 each of all values
Core material
Ferrite
Core and winding loss
See www.coilcraft.com/coreloss
Environmental
RoHS compliant, halogen free
Terminations
RoHS compliant matte tin over nickel over silver.
Other terminations available at additional cost.
Weight
460 – 480 mg
Ambient temperature
–40°C to +85°C with
Irms
current, +85°C to
+125°C with derated current
Storage temperature
Component: –40°C to +125°C.
Tape and reel packaging: –40°C to +80°C
Resistance to soldering heat
Max three 40 second reflows at
+260°C, parts cooled to room temperature between cycles
Moisture Sensitivity Level (MSL)
1 (unlimited floor life at <30°C /
85% relative humidity)
Failures in Time (FIT) / Mean Time Between Failures (MTBF)
38 per billion hours / 26,315,789 hours, calculated per Telcordia SR-332
Packaging
350/7″ reel; 1500/13″ reel Plastic tape: 16 mm wide,
0.3 mm thick, 12 mm pocket spacing, 3.68 mm pocket depth
Recommended pick and place nozzle
OD: 6.2 mm; ID:
≤
3.1 mm
PCB washing
Tested with pure water or alcohol only. For other solvents,
see
Doc787_PCB_Washing.pdf.
Part number
1
Isat
(A)
5
DCR
SRF
Inductance
2
max
3
typ
4
10% 20% 30%
±20% (µH) (Ohms) (MHz) drop drop drop
0.075
0.095
0.100
0.110
0.125
0.140
0.145
0.180
0.245
0.280
0.345
0.315
0.375
0.435
0.535
0.820
1.20
1.60
2.00
2.20
2.70
3.40
4.60
5.42
6.70
9.50
14.5
16.4
21.4
24.5
29.5
55
48
37
29
25
24
24
16
13
12
10.8
10.0
9.0
8.3
7.3
5.6
4.4
3.6
3.1
2.8
2.5
2.2
1.9
1.7
1.5
1.1
0.94
0.86
0.80
0.70
0.61
2.6
2.5
2.3
1.9
1.9
1.7
1.6
1.3
1.1
1.0
0.90
0.46
0.46
0.44
0.37
0.31
0.26
0.22
0.20
0.17
0.16
0.14
0.12
0.11
0.090
0.080
0.070
0.060
0.057
0.052
0.050
2.7
2.6
2.4
2.2
2.0
1.8
1.7
1.4
1.2
1.0
0.94
0.52
0.52
0.48
0.43
0.36
0.29
0.25
0.22
0.19
0.18
0.17
0.13
0.12
0.11
0.090
0.077
0.070
0.065
0.060
0.055
2.8
2.7
2.5
2.3
2.0
1.9
1.7
1.5
1.2
1.1
0.96
0.55
0.54
0.51
0.45
0.37
0.30
0.26
0.23
0.21
0.19
0.18
0.14
0.13
0.11
0.10
0.084
0.080
0.069
0.067
0.060
Irms
(A)
6
20°C 40°C
rise rise
1.30
1.30
1.28
1.25
1.22
1.20
1.10
1.00
0.80
0.75
0.73
0.72
0.70
0.60
0.53
0.45
0.40
0.32
0.29
0.28
0.26
0.24
0.19
0.18
0.16
0.14
0.11
0.10
0.090
0.085
0.075
1.90
1.85
1.80
1.75
1.70
1.65
1.60
1.30
1.15
1.07
1.00
0.95
0.90
0.80
0.73
0.64
0.50
0.43
0.38
0.37
0.33
0.30
0.26
0.23
0.22
0.180
0.150
0.130
0.120
0.115
0.095
1. Please specify
termination
and
packaging
codes:
LPS6235-106MRC
Termination: R
= RoHS compliant matte tin over
nickel over silver.
Special order, added cost:
Q
= RoHS tin-silver-copper (95.5/4/0.5)
or
P
= non-RoHS tin-lead (63/37).
Packaging: C
= 7″ machine-ready reel. EIA-481
embossed plastic tape (350 parts
per full reel).
B
= Less than full reel. In tape, but not
machine ready. To have a leader and
trailer added ($25 charge), use code
letter C instead.
D
= 13″ machine-ready reel. EIA-481
embossed plastic tape. Factory
order only, not stocked (1500 parts
per full reel).
2. Inductance tested at 100 kHz, 0.1 Vrms, 0 Adc using an
Agilent/HP 4192A.
3. DCR measured on a micro-ohmmeter.
4. SRF measured using Agilent/HP 8753ES or equivalent.
5. DC current that causes the specified inductance drop
from its value without current.
6. Current that causes the specified temperature rise from
25°C ambient.
7. Electrical specifications at 25°C.
Refer to Doc 362 “Soldering Surface Mount Components”
before soldering.
LPS6235-682MR_
6.8
LPS6235-822MR_
8.2
LPS6235-103MR_
10.0
LPS6235-123MR_
12.0
LPS6235-153MR_
15.0
LPS6235-183MR_
18.0
LPS6235-223MR_
22.0
LPS6235-333MR_
33.0
LPS6235-473MR_
47.0
LPS6235-563MR_
56.0
LPS6235-683MR_
68.0
LPS6235-823MR_
82.0
LPS6235-104MR_
100.0
LPS6235-124MR_
120.0
LPS6235-154MR_
150.0
LPS6235-224MR_
220.0
LPS6235-334MR_
330.0
LPS6235-474MR_
470.0
LPS6235-564MR_
560.0
LPS6235-684MR_
680.0
LPS6235-824MR_
820.0
LPS6235-105MR_ 1000.0
LPS6235-155MR_ 1500.0
LPS6235-185MR_ 1800.0
LPS6235-225MR_ 2200.0
LPS6235-335MR_ 3300.0
LPS6235-475MR_ 4700.0
LPS6235-565MR_ 5600.0
LPS6235-685MR_ 6800.0
LPS6235-825MR_ 8200.0
LPS6235-106MR_ 10000.0
US
+1-847-639-6400 sales@coilcraft.com
UK
+44-1236-730595 sales@coilcraft-europe.com
Taiwan
+886-2-2264 3646 sales@coilcraft.com.tw
China
+86-21-6218 8074 sales@coilcraft.com.cn
Singapore
+ 65-6484 8412 sales@coilcraft.com.sg
Document 587-1
Revised 08/01/13
© Coilcraft Inc. 2014
This product may not be used in medical or high
risk applications without prior Coilcraft approval.
Specification subject to change without notice.
Please check web site for latest information.
Document 587-2
Shielded Power Inductors – LPS6235 Series
