HIN211EIBZ datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Analog mixed-signal IC> Drivers and interfaces> HIN211EIBZ

HIN211EIBZ: Description±15kV, ESD-Protected, +5V Powered, RS-232 Transmitters/Receivers; SOIC28, SSOP28; Temp Range: See Datasheet; CategoryAnalog mixed-signal IC Drivers and interfaces; File Size1MB，23 Pages; ManufacturerRenesas Electronics Corporation; Websitehttps://www.renesas.com/

Download Datasheet Parametric View All

HIN211EIBZ Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	HIN211EIBZ	-	-	View	Buy Now

HIN211EIBZ Overview

±15kV, ESD-Protected, +5V Powered, RS-232 Transmitters/Receivers; SOIC28, SSOP28; Temp Range: See Datasheet

HIN211EIBZ Parametric

Parameter Name	Attribute value
Brand Name	Intersil
Maker	Renesas Electronics Corporation
Parts packaging code	SOIC, SSOP
package instruction	SOP, SOP28,.4
Contacts	28, 28
Reach Compliance Code	compliant
ECCN code	EAR99
Factory Lead Time	19 weeks
Differential output	NO
Number of drives	4
Input properties	SCHMITT TRIGGER
Interface integrated circuit type	LINE TRANSCEIVER
Interface standards	EIA-232-E; V.28
JESD-30 code	R-PDSO-G28
JESD-609 code	e3
length	17.9 mm
Humidity sensitivity level	3
Number of functions	4
Number of terminals	28
Maximum operating temperature	85 °C
Minimum operating temperature	-40 °C
Minimum output swing	10 V
Maximum output low current	0.0016 A
Package body material	PLASTIC/EPOXY
encapsulated code	SOP
Encapsulate equivalent code	SOP28,.4
Package shape	RECTANGULAR
Package form	SMALL OUTLINE
Peak Reflow Temperature (Celsius)	260
power supply	5 V
Certification status	Not Qualified
Maximum receive delay	10000 ns
Number of receiver bits	5
Maximum seat height	2.65 mm
Maximum slew rate	20 mA
Maximum supply voltage	5.5 V
Minimum supply voltage	4.5 V
Nominal supply voltage	5 V
surface mount	YES
technology	CMOS
Temperature level	INDUSTRIAL
Terminal surface	Matte Tin (Sn) - annealed
Terminal form	GULL WING
Terminal pitch	1.27 mm
Terminal location	DUAL
Maximum time at peak reflow temperature	30
maximum transmission delay	10000 ns
width	7.5 mm

Preview

Download Datasheet

View All

DATASHEET

HIN202E, HIN206E, HIN207E, HIN208E, HIN211E, HIN213E, HIN232E

±15kV, ESD-Protected, +5V Powered, RS-232 Transmitters/Receivers

FN4315

Rev 17.00

September 14, 2015

The HIN202E, HIN206E, HIN207E, HIN208E, HIN211E,

HIN213E, HIN232E family of RS-232 transmitters/receivers

interface circuits meet all ElA high-speed RS-232E and V.28

specifications, and are particularly suited for those

applications where

12V

is not available. A redesigned

transmitter circuit improves data rate and slew rate, which

makes this suitable for ISDN and high speed modems. The

transmitter outputs and receiver inputs are protected to

15kV

ESD (Electrostatic Discharge). They require a single

+5V power supply and feature onboard charge pump voltage

converters which generate +10V and -10V supplies from the

5V supply. The family of devices offers a wide variety of

high-speed RS-232 transmitter/receiver combinations to

accommodate various applications (see Selection Table).

The HIN206E, HIN211E and HIN213E feature a low power

shutdown mode to conserve energy in battery powered

applications. In addition, the HIN213E provides two active

receivers in shutdown mode allowing for easy “wakeup”

capability.

The drivers feature true TTL/CMOS input compatibility, slew

rate-limited output, and 300 power-off source impedance.

The receivers can handle up to

30V

input, and have a 3k

to 7k input impedance. The receivers also feature

hysteresis to greatly improve noise rejection.

Features

• Pb-Free Plus Anneal Available (RoHS Compliant)

• High Speed ISDN Compatible . . . . . . . . . . . . . 230kbits/s

• ESD Protection for RS-232 I/O Pins to

15kV

(IEC61000)

• Meets All RS-232E and V.28 Specifications

• Requires Only 0.1F or Greater External Capacitors

• Two Receivers Active in Shutdown Mode (HIN213E)

• Requires Only Single +5V Power Supply

• Onboard Voltage Doubler/Inverter

• Low Power Consumption (Typ) . . . . . . . . . . . . . . . . . 5mA

• Low Power Shutdown Function (Typ) . . . . . . . . . . . . .1A

• Three-State TTL/CMOS Receiver Outputs

• Multiple Drivers

10V

Output Swing for +5V Input

- 300 Power-Off Source Impedance

- Output Current Limiting

- TTL/CMOS Compatible

• Multiple Receivers

30V

Input Voltage Range

- 3k to 7k Input Impedance

- 0.5V Hysteresis to Improve Noise Rejection

Applications

• Any System Requiring High-Speed RS-232

Communications Port

- Computer - Portable, Mainframe, Laptop

- Peripheral - Printers and Terminals

- Instrumentation, UPS

- Modems, ISDN Terminal Adaptors

Selection Table

PART

NUMBER

HIN202E

HIN206E

HIN207E

HIN208E

HIN211E

HIN213E

HIN232E

POWER SUPPLY

VOLTAGE

+5V

NUMBER OF

RS-232

DRIVERS

NUMBER OF

RS-232

RECEIVERS

NUMBER OF

0.1F

EXTERNAL

CAPACITORS

4 Capacitors

LOW POWER

SHUTDOWN/TTL

THREE-STATE

No/No

Yes/Yes

No/No

Yes/Yes

No/No

NUMBER OF

RECEIVERS

ACTIVE IN

SHUTDOWN

FN4315 Rev 17.00

September 14, 2015

Page 1 of 23
