A Business Partner of Renesas Electronics Corporation.

PS9351L,PS9351L2

DESCRIPTION

PHOTOCOUPLER NEPOC Series

Preliminary Datasheet

HIGH NOISE REDUCTION, 15 Mbps CMOS OUTPUT TYPE

8mm CREEPAGE 6-PIN SDIP PHOTOCOUPLER

CMOS output IC on the output side.

The PS9351L and PS9351L2 are optically coupled isolator containing a GaAlAs LED on the input side and a

creepage distance. The mount area of 6-pin plastic SDIP is half size of 8-pin DIP.

designed for high-speed logic interface circuits.

The PS9351L and PS9351L2 are in 6-pin plastic SDIP (Shrink Dual In-line Package). The PS9351L2 has 8 mm

This photocoupler is high common mode transient immunity (CMR), a high-speed CMOS output type device

The PS9351L2 is lead bending type for long creepage distance (Gull-wing) for surface mount.

The PS9351L is lead bending type (Gull-wing) for surface mounting.

FEATURES

• High-speed response (15 Mbps)

• Long creepage distance (8mm MIN. : PS9351L2)

• High common mode transient immunity (CM

, CM

±20

kV/

s TYP.)

• Operable at high temperature (−40 to +100°C)

• Pulse width distortion (⏐t

PHL

−t

PLH

⏐

= 5 ns TYP.)

• High isolation voltage (BV = 5000 Vr.m.s.)

PIN CONNECTION

(Top View)

• Ordering number of tape product : PS9351L-E3: 2 000 pcs/reel

APPLICATIONS

• FA Network

• PDP

• Measurement equipment

TRUTH TABLE

LED

OFF

Output

SHIELD

• Pb-Free product

: PS9351L2-E3: 2 000 pcs/reel

1. Anode

2. NC

3. Cathode

4. GND

5. V

6. V
