Standard Products
Advanced
RadHard-by-Design
RHD5904 Quad Operational Amplifier
Instrumentation Amplifier with Enables
www.aeroflex.com/RHDseries
September 26, 2012
FEATURES
❑
❑
❑
❑
❑
❑
❑
❑
❑
Single power supply operation (3.3V to 5.0V) or dual power supply operation (±1.65 to ±2.5V)
Radiation performance
- Total dose:
>1Mrad(Si); Dose rate = 50 - 300 rads(Si)/s
- ELDRS Immune
- SEL Immune
>100 MeV-cm
2
/mg
- Neutron Displacement Damage >10
14
neutrons/cm
2
High Speed
Rail-to-Rail input and output range
Enable pin to Enable/Disable amplifiers in pairs.
Short Circuit Tolerant
Full military temperature range
Designed for aerospace and high reliability space applications
Packaging – Hermetic ceramic SOIC
- 16-pin, .417"L x .300"W x 0.105"Ht SOIC
- Typical Weight 0.8 grams
GENERAL DESCRIPTION
Aeroflex’s RHD5904 is a radiation hardened, single supply, high speed, quad operational amplifier with
enable in a 16-pin SOIC package. The RHD5904 design uses specific circuit topology and layout methods
to mitigate total ionizing dose effects and single event latchup. These characteristics make the RHD5904
especially suited for the harsh environment encountered in Deep Space missions. It is guaranteed
operational from -55°C to +125°C. Available screened in accordance with MIL-PRF-38534 Class K, the
RHD5904 is ideal for demanding military and space applications.
The RHD5904 amplifiers are capable of rail-to-rail input and outputs. Performance characteristics listed
are for general purpose operational 5V CMOS amplifier applications. The amplifiers will drive substantial
resistive or capacitive loads and are unity gain stable under normal conditions. Resistive loads in the low
kohm range can be handled without gain derating and capacitive loads of several nF can be tolerated.
CMOS device drive has a negative temperature coefficient and the devices are therefore inherently tolerant
to momentary shorts, although on chip thermal shutdown is not provided. All inputs and outputs are diode
protected.
The devices will not latch with SEU events to above 100 MeV-cm
2
/mg. Total dose degradation is minimal
to above 1Mrad(Si). Displacement damage environments to neutron fluence equivalents in the mid 10
14
neutrons per cm
2
range are readily tolerated. There is no sensitivity to low-dose rate (ELDRS) effects. SEU
effects are application dependant.
The RHD5904 is configured with enable/disable control. Pairs of amplifiers are put in a power-down
condition with their outputs in a high impedance state. Several useful operational amplifier configurations
are supported where more than one amplifier can feed an output with others disabled.
SCD5904 Rev A
ORGANIZATION AND APPLICATION
ABSOLUTE MAXIMUM RATINGS
Parameter
Case Operating Temperature Range
Storage Temperature Range
Junction Temperature
Supply Voltage
V
CC
- V
EE
Input Voltage
Lead Temperature (soldering, 10 seconds)
Thermal Resistance, Junction to Case,jc
ESD Rating
Power @ 25°C
Range
-55 to +125
-65 to +150
+150
+6.0
V
CC
+0.4
V
EE
-0.4
300
7
2.0
200
Units
°C
°C
°C
V
V
°C
°C/W
KV
mW
NOTICE: Stresses above those listed under “Absolute Maximums Rating” may cause permanent damage to the device. These are stress rating only;
functional operation beyond the “Operation Conditions” is not recommended and extended exposure beyond the “Operation Conditions” may affect
device reliability.
RECOMMENDED OPERATING CONDITIONS
Symbol
+V
CC
V
CM
Power Supply Voltage
Input Common Mode Range
Parameter
Typical
3.3 to 5.0
V
CC
to V
EE
Units
V
V
ELECTRICAL PERFORMANCE CHARACTERISTICS
(T
C
= -55°C
TO
+125°C, +V
CC
= +5.0V -- U
NLESS OTHERWISE SPECIFIED
)
Symbol
V
OS
I
OS
I
B
V
IOST
CMRR
PSRR
V
OH
V
OL
I
O
(
SINK
)
I
O
(
SOURCE
)
SR
A
OL
UGBW
R
OUT
= 3.6 Kohms to GND
R
OUT
= 3.6 Kohms to V
CC
V
OUT
to V
CC
V
OUT
to V
EE
R
L
= 8K
No Load
R
L
= 10K
2.5
100
5
-63
45
70
70
4.9
0.1
Conditions
Min
-2
-10
-20
Parameter
Input Offset Voltage
Input Offset Current
Input Bias Current
Input Offset TempCo 2/
Common Mode Rejection Ratio
Power Supply Rejection Ratio
Output Voltage High
Output Voltage Low
Short Circuit
Output Current 2/
Slew Rate
Open Loop Gain 2/
Unity Gain Bandwidth
Typ
Max
2
10
20
10
Units
mV
pA
pA
uV/C
dB
dB
V
V
mA
mA
V/uS
dB
MHz
SCD5904 Rev A
Advanced
9/26/12
3
Aeroflex Plainview
ELECTRICAL PERFORMANCE CHARACTERISTICS (continued)
(T
C
= -55°C
TO
+125°C, +V
CC
= +5.0V -- U
NLESS OTHERWISE SPECIFIED
)
Symbol
V
HI
V
LO
I
EN
All Amplifiers Enabled, No Load
All Amplifier Disabled
R
L
= 2K, f = 1.0KHz
e
n
m
F = 1 kHz
TBD
90
TBD
Conditions
High (Enabled)
Low (Disabled)
Min
70%
V
CC
- V
EE
30%
V
CC
- V
EE
100
5.5
1
Parameter
Typ
Max
Units
V
V
nA
mA
uA
dB
V/
Hz
Deg
Input Voltage - Enable (EN_AB,
EN_CD)
Input Current - Enable
(EN_AB, EN_CD)
Quiescent Supply Current
Channel Separation 2/
Input-Referred Voltage Noise 2/
Phase Margin 2/
I
CCQ
Notes:
1/ Specification derated to reflect Total Dose exposure to 1 Mrad(Si) @ +25°C.
2/ Not tested. Shall be guaranteed by design, characterization, or correlation to other test parameters.
(T
C
= -55°C
TO
+125°C, +V
CC
= +5.0V -- U
NLESS OTHERWISE SPECIFIED
)
Parameter
Output Delay (Enabled)
Output Delay (Disabled)
SWITCHING CHARACTERISTICS
Symbol
t
ON
EN
t
OFF
EN
Conditions
Min
Max
100
100
Units
ns
ns
ENABLES
(EN_AB or EN_CD)
V
CC
50%
GND
t
ON
EN
V
CC
VOUT
(V
OUT
_A&B or V
OUT
_C&D)
HI Z
HI Z
GND
t
OFF
EN
FIGURE 3: RHD5904 SWITCHING DIAGRAM
SCD5904 Rev A
Advanced
9/26/12
4
Aeroflex Plainview
