IB946
Socket P Half-Size PISA CPU Card w/
Intel
®
GM45 Express chipset
Intel
®
Core™2 Quad-Based
ATX Power
+12V power
connector
Socket P
Digital I/O
COM1~4
LPT
IrDA
SATA II
KB/Mouse
External
Keyboard
USB
VGA
Socket M Half-Size PISA CPU Card w/ Mobile
Intel
®
945GME Chipset
Intel
®
Core™2 Duo-Based
LPT
BIOS
Serial
Ports
Digital I/O
LVDS
Panel Inverter Power
SATA
IDE
Audio
External
Keyboard
KB/Mouse
USB
Mini PCI
VGA
DC-In
IB930
ATX Power
Power from
Backplane
DDR2
SO-DIMM
RJ-45
RJ-45
Intel
®
GM45
Chipset
Audio
LVDS
ICH9EM
Socket M
Intel
®
945GME
Chipset
DDR2
DIMM Socket
ICH7M
USB
6
USB
4
COM
2
1
SATA II Gbe LAN
5
USB
4
COM
2
SATA
1
Gbe LAN
● Supports Intel
®
Core™2 Quad / Core™2 Duo / Celeron
®
processors,
667/800/1066MHz FSB
● 2x DDR2 SO-DIMM, Max. 4GB
● Supports dual display (CRT / LVDS)
● Intel
®
82567LM Gigabit LAN
● 5.1CH HD Audio, CF socket, LAN Wakeup
● Watchdog timer, Digital I/O, PCI to ISA bridge
● 2x SATA II, 5x USB 2.0, 4x COM,1x ISA, 1x LPT, 1x Mini PCI-E
Features
● Supports Intel
®
Core™2 Duo processors Up to 2.33GHz, 667MHz FSB
● 1x DDR2 DIMM, Max. 2GB
● Integrated Intel
®
945GME VGA controller supports CRT and LVDS
● Marvell 88E8053 PCI-E Gigabit LAN
● 5x USB 2.0, 4x COM, 2x SATA, 1x Mini PCI
● Watchdog timer, Digital I/O, PCI to ISA bridge
Features
Specifications
CPU Socket
System Memory
System Chipset
BIOS
Watchdog Timer
SSD
H/W Monitor
Expansion Slot
VGA Controller
VGA Memory
LCD Interface
LAN Controller
Connector
I/O Chipset
USB
Audio
Others
Dimensions
Max. Power
Requirement
Operating
Temperature
Relative Humidity
Socket P for Intel
®
Core™2 Quad /Core™2 Duo / Celeron
®
processors
2x DDR2 SO-DIMM, Max. 4GB
Intel
®
GM45 + ICH9M, 667/800/1066MHz FSB
Award
256 levels
Type II CF socket
Yes
1x Mini PCI-E
Intel
®
GM45 integrated GMA4500 MHD
Supports DVMT 5.0; Max. shared memory - 1GB
Supports CRT & 18-bit/24-bit dual channel LVDS
Intel
®
82567LM Gigabit LAN
RJ-45 on board
Winbond W83627EHG + Fintek F81216AD
1x LPT, 1x IrDA, 1x KB, 1x mouse,
3x RS232, 1x RS-232/422/485, 2x SATA II (3.0Gb/sec.)
1 port on board
Pin header for 4 ports (USB 2.0)
Intel built-in HD audio w/ Realtek ALC662 codec for 5.1CH
®
Specifications
CPU Socket
System Memory
System Chipset
BIOS
Watchdog Timer
SSD
H/W Monitor
Expansion Slot
VGA Controller
VGA Memory
LCD Interface
LAN Controller
Connector
I/O Chipset
USB
Audio
Others
Dimensions
Max. Power
Requirement
Operating
Temperature
Socket M Intel
®
Core™2 Duo / Core™ Duo / Celeron
®
,
up to 2.33GHz
1x DDR2 DIMM, Max. 2GB
Mobile Intel
®
945GME + ICH7M, 533MHz/667MHz FSB
Award
256 levels
CF socket
Yes
1x Mini PCI
Intel
®
Graphics Media Accelerator (GMA) 950,
supports CRT, LVDS
Max shared memory - 224MB
Supports 24-bit single or dual channel LVDS
Marvell 88E8053 PCI-E Gigabit LAN
RJ-45 on board
ICH7M, Winbond W83627EHG, Fintek F81216
1x IDE, 1x LPT, 1x KB, 1x mouse,
3x RS232, 1x RS-232/422/485, 2x SATA
1 port on board and 4 ports via pin header (USB 2.0)
Built-in audio + Realtek ALC662 codec for 5.1CH
ITE IT8888G PCI to ISA bridge (w/o ISA master), IrDA,
Digital I/O (4-in/4-out)
186mm x 129mm (7.32“ x 5“)
Core Duo™ 2.33GHz, 667MHz FSB, 1GB DDR2
+5V: 3.85A
+12V: 2.15A
0°C~60°C (32°F~140°F)
ITE IT8888G PCI to ISA bridge (w/o ISA master), IrDA,
Digital I/O (4-in/4-out)
186mm x 129mm (7.32“ x 5.08“)
Intel Core™2 Duo T9400 2.53GHz
w/ 2x 2GB DDR2-800
+3.3V:0.24A
+5V: 3.30A
+12V: 1.92A
®
0°C~60°C (32°F~140°F)
Storage Temperature
-20°C~80°C (-4°F~176°F)
10%~90% (non-condensing)
Ordering Information
IB946
Socket P GM45 Half-Size CPU card with VGA, LVDS, CF, Mini
PCI-E and 1x Gigabit LAN
Storage Temperature
-20°C~80°C (-4°F~176°F)
Relative Humidity
10%~90% (non-condensing)
Ordering Information
IB930H
Socket M Intel
®
945GME Half-Size CPU Card w/ VGA and PCI-E
Gigabit LAN
5-12
Remarks: 1. Specifications are subject to change without prior notice.
2. ODM/OEM is available
