IRFR130ATM

Description
Avalanche Rugged Technology
CategoryDiscrete semiconductor    The transistor
File Size260KB,7 Pages
ManufacturerFairchild
Websitehttp://www.fairchildsemi.com/
Environmental Compliance
Download Datasheet Parametric View All

IRFR130ATM Online Shopping

Suppliers Part Number Price MOQ In stock
IRFR130ATM - - View Buy Now

IRFR130ATM Overview

Avalanche Rugged Technology

IRFR130ATM Parametric

Parameter NameAttribute value
Is it Rohs certified?conform to
MakerFairchild
Parts packaging codeTO-252
package instructionDPAK-3
Contacts3
Reach Compliance Code_compli
ECCN codeEAR99
Avalanche Energy Efficiency Rating (Eas)225 mJ
Shell connectionDRAIN
ConfigurationSINGLE WITH BUILT-IN DIODE
Minimum drain-source breakdown voltage100 V
Maximum drain current (Abs) (ID)13 A
Maximum drain current (ID)13 A
Maximum drain-source on-resistance0.11 Ω
FET technologyMETAL-OXIDE SEMICONDUCTOR
JEDEC-95 codeTO-252
JESD-30 codeR-PSSO-G2
JESD-609 codee3
Humidity sensitivity level1
Number of components1
Number of terminals2
Operating modeENHANCEMENT MODE
Maximum operating temperature150 °C
Package body materialPLASTIC/EPOXY
Package shapeRECTANGULAR
Package formSMALL OUTLINE
Peak Reflow Temperature (Celsius)260
Polarity/channel typeN-CHANNEL
Maximum power dissipation(Abs)41 W
Maximum pulsed drain current (IDM)52 A
Certification statusNot Qualified
surface mountYES
Terminal surfaceMatte Tin (Sn)
Terminal formGULL WING
Terminal locationSINGLE
Maximum time at peak reflow temperatureNOT SPECIFIED
transistor applicationsSWITCHING
Transistor component materialsSILICON
Advanced Power MOSFET
FEATURES
Avalanche Rugged Technology
Rugged Gate Oxide Technology
Lower Input Capacitance
Improved Gate Charge
Extended Safe Operating Area
Lower Leakage Current : 10
µ
A (Max.) @ V
DS
= 100V
Lower R
DS(ON)
: 0.092
(Typ.)
IRFR/U130A
BV
DSS
= 100 V
R
DS(on)
= 0.11
I
D
= 13 A
D-PAK
2
1
3
1
I-PAK
2
3
1. Gate 2. Drain 3. Source
Absolute Maximum Ratings
Symbol
V
DSS
I
D
I
DM
V
GS
E
AS
I
AR
E
AR
dv/dt
P
D
Characteristic
Drain-to-Source Voltage
Continuous Drain Current (T
C
=25
C
)
Continuous Drain Current (T
C
=100
C
)
Drain Current-Pulsed
Gate-to-Source Voltage
Single Pulsed Avalanche Energy
Avalanche Current
Repetitive Avalanche Energy
Peak Diode Recovery dv/dt
Total Power Dissipation (T
A
=25
C
) *
Ο
Ο
Ο
Value
100
13
8.2
1
O
2
O
1
O
1
O
3
O
Units
V
A
A
V
mJ
A
mJ
V/ns
W
W
W/
C
Ο
52
+
20
_
225
13
4.1
6.5
2.5
41
0.32
- 55 to +150
Total Power Dissipation (T
C
=25
C
)
Linear Derating Factor
Operating Junction and
Storage Temperature Range
Maximum Lead Temp. for Soldering
Purposes, 1/8” from case for 5-seconds
Ο
T
J
, T
STG
T
L
Ο
C
300
Thermal Resistance
Symbol
R
θ
JC
R
θ
JA
R
θ
JA
Characteristic
Junction-to-Case
Junction-to-Ambient *
Junction-to-Ambient
Typ.
--
--
--
Max.
3.08
50
110
Ο
Units
C
/W
*
When mounted on the minimum pad size recommended (PCB Mount).
Rev. B
©1999 Fairchild Semiconductor Corporation
