SCK240N
Elektronische Bauelemente
RoHS Compliant Product
A suffix of “-C” specifies halogen-free and RoHS Compliant
40 V, 1.5A
Low VF Schottky Barrier Rectifiers
FEATURES
Batch process design, excellent power dissipation offers
Better reverse leakage current and thermal resistance.
Guardring for overvoltage protection.
Very tiny plastic SMD package.
Super Low Forward Voltage
Silicon epitaxial planar chip, metal silicon junction.
Lead-free parts meet environmental standards of
MIL-STD-19500/228
SOD-323N
A
B
F
D
C
E
E
PACKAGING INFORMATION
Epoxy: UL94-V0 rated flame retardant
Case: Molded plastic, SOD323N
Terminals: Plated terminals,
solderable per MIL-STD-750, method 2026.
REF.
A
B
C
Millimeter
Min.
Max.
2.30
2.70
1.05
1.45
0.80
1.20
REF.
D
E
F
Millimeter
Min.
Max.
1.7
2.1
0.4 TYP
0.30 TYP
Anode
MARKING CODE
L4
Cathode
PACKAGE INFORMATION
Package
SOD-323N
MPQ
3K
Leader Size
7 inch
MAXIMUM RATINGS
(T
a
= 25°C unless otherwise specified.)
Parameter
Repetitive Peak Reverse Voltage
Maximum RMS Voltage
Maximum Reverse Voltage@ I
R
=1mA
Maximum Forward Rectified Current
Peak Forward Surge Current, 8.3ms single half sine-wave
superimposed on rated load (JEDEC method)
Typical Thermal Resistance
Storage and Operating Temperature Range
Symbol
V
RRM
V
RMS
V
R
I
O
I
FSM
R
JA
T
STG
, T
J
Rating
40
28
40
1.5
30
80
-55~100, -65~175
Unit
V
V
V
A
A
°C/W
°C
ELECTRICAL CHARACTERISTICS
Parameter
Maximum Instantaneous Forward Voltage
Maximum DC Reverse Current
at Rated DC Blocking Voltage
Typical Junction Capacitance
1
Note:
1. f=1MHz and applied 4V DC reverse voltage
Symbol
V
F
I
R
C
J
Typ.
240
300
430
65
130
Max.
250
350
450
100
-
Unit
mV
Test Condition
I
F
=100mA
I
F
=500mA
I
F
=2A
T
J
=25°C
μA
pF
23-Oct-2013 Rev. A
Page 1 of 2
