LEADED • LOW FREQUENCY kHz BAND
CERAMIC RESONATORS
LXZT
FEATURES:
• Excellent Environmental Resistance.
• Standard Frequency Range from 190kHz to 1250 kHz
• Packaging Tape and Reel Option (-T)
• Low Cost
• Low Resonant impedance
APPLICATIONS:
• Microprocessor Clocks.
STANDARD SPECIFICATIONS
PARAMETERS
Frequency Range
Resonant Impedance
Operating Temperature
Frequency Tolerance
@
25°C
Frequency Stability over Temp.
Load Capacitance C
L
(C
1
C
2
)
Aging in 10 Years
NOTE 1:
SPECIFICATIONS
190 kHz - 1250 kHz
(See Table below)
-20°C to + 80° C
(See Options)
±0.5% max.
± 0.3% max.
(See Table below)
± 0.5% max.
Please contact us for higher or lower frequencies.
Environmental and mechanical specifications on page 68, Group 5.
Marking, see page 77.
Test Circuit
ORDERING OPTIONS
LX Z T - Frequency
XXXX k Hz
-
Temperature
-
Packaging
- T for
Tape and
Reel
-D for -40°C to + 85°C
Frequency Stability
± 0.5% max
TABLE 1
FREQUENCY
RANGE
(See Note 1)
C1
C2
RESONANT
LENGTH (L)
WIDTH (W) HEIGHT (H)
LL
(pF)
(pF)
IMPEDANCE
standard
in (mm)
in (mm)
NOTE: Left blank if
± 20% ±
•
20%
specifications and markings subject to
in (mm)
All
change without
in (mm)
notice
in
WW
(mm)
190 kHz ~ 249 kHz
250 kHz ~ 375 kHz
376 kHz ~ 429 kHz
430 kHz ~ 509 kHz
510 kHz ~ 699 kHz
700 kHz ~ 1250 kHz
20
Ω
max.
20
Ω
max.
20
Ω
max.
20
Ω
max.
30
Ω
max.
50
Ω
max.
330
220
120
100
100
100
470
470
470
100
100
100
0.53 (13.5)
0.43 (10.8)
0.32
0.3
0.3
0.2
(8)
(7.5)
(7.5)
(5)
0.15 (3.8)
0.15 (3.8)
0.14 (3.6)
0.13 (3.3)
0.14 (3.5)
0.11 (2.8)
0.57 (14.5)
0.48 (12.2)
0.35 (9.3)
0.33 (9.3)
0.35 (9.0)
0.26 (6.8)
0.75 (9)
0.24 (6)
0.14 (3.5)
0.14 (3.5)
0.14 (3.5)
0.14 (3.5)
0.4 (10.3)
0.3 (7.7)
0.2
0.2
0.2
(5)
(5)
(5)
0.1 (2.5)
