Components
Temperature compensated chip attenuators
■
P＊V series
Features
●
For simplifying temperature drift compensation of GaAs high frequency
amplifiers
●
Excellent high frequency characteristics
Applications
※ Except for
Chinese RoHS
●
Base station and others
Specifications
Dimensions
＊All made to order.
0.65 0.70 0.65
±0.35 ±0.2 ±0.35
0.35±0.2
Equivalent circuits
0.9±0.2
PXV1220S
1.25±0.2
0.55±0.2
0.35±0.2
2.0±0.2
0.55±0.25
1.0±0.2
0.4±0.2
1.5max
PBV1632S
1.60±0.2
0.4±0.2
3.2±0.2
0.4±0.2
3.2±0.2
0.4±0.1
（unit mm）
：
Front side
Back side
High frequency surface
mount components
Electrical characteristics
Series name
Attenuation
Attenuation tolerance
Impedance
VSWR
Temperature
coefficient of
attenuation
Operating frequency
Rated power
Operating temperature
Packaging
・Refer to the data book for details.
63mW
−40 ℃∼＋100℃
100pcs/bag 200pcs/reel 1,000pcs/reel
min.20pcs/bag 1,000pcs/reel
N1 ∼ N8
（1 ∼ 3dB : N1 ∼ N9）
ex :
N1
N2
N3
N4
PXV1220S
（0805）
1, 2, 3, 4, 5, 6, 7, 8, 9, 10dB
50Ω
1.3max.
6dB
0.0119dB/dB*℃
0.0088dB/dB*℃
0.0062dB/dB*℃
0.0047dB/dB*℃
DC∼3GHz
±0.5dB
（@25 ℃, no load）
PBV1632S
(1206)
1, 2, 3, 4, 5, 6, 7, 8, 9, 10, 16dB
＊
P V series
N5
N6
N7
N8
0.0041dB/dB*℃
0.0035dB/dB*℃
0.0026dB/dB*℃
0.0019dB/dB*℃
100mW
Part numbering system
PXV 1220S - 6dB N1 - T
Packaging（T02=200, T1=1,000, B=Bulk）
Temperature coefficient of attenuation
Attenuation
Size
Product code
26
