8-1437562-0 datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Mechanical and electronic products> switch> 8-1437562-0

8-1437562-0: DescriptionToggle Switch, TOGGLE SWITCH, 4PDT, LATCHED, 3A, PANEL MOUNT-THREADED; CategoryMechanical and electronic products switch; File Size114KB，1 Pages; ManufacturerTE Connectivity; Websitehttp://www.te.com

Download Datasheet Parametric Compare View All

8-1437562-0 Overview

Toggle Switch, TOGGLE SWITCH, 4PDT, LATCHED, 3A, PANEL MOUNT-THREADED

8-1437562-0 Parametric

Parameter Name	Attribute value
Brand Name	Alcoswitch
Is it Rohs certified?	incompatible
Objectid	1668093609
Reach Compliance Code	unknown
ECCN code	EAR99
YTEOL	0
Actuator type	BATON LONG TYPE
Body length or diameter	9.4 mm
Maximum contact current (AC)	3 A
Maximum contact current (DC)	3 A
Installation features	PANEL MOUNT-THREADED
seal	EPOXY TERMINAL SEALED
surface mount	NO
Switch action	LATCHED
switch function	4PDT
Switch type	TOGGLE SWITCH
Termination type	WIRE

Preview

Download Datasheet

View All

My Account

Tyco Electronics

(C hange)

Se a rch by Ke yword or Pa rt #

Products

Documentation

Resources

My Account

Customer Support

Home

Products

By Type

Switches

Product Feature Selector

> Product Details

TT43P3T Product Details

Live Product Chat

Toggle Switches

Not EU R oHS or ELV C om plia nt

Quick Links

C heck Pricing & Availability

Search for Tooling

Product Feature Selector

C ontact Us About This Product

TT43P3T

(8-1437562-0)

T E I nternal N umber: 8 - 1 4 3 7 5 6 2 - 0

Product Highlights:

TT (Tiny) Series

Four Pole - Double Throw C onfiguration (Pole-Throw)

C urrent Rating = 3 Amps.

Mount Style = Panel

Termination Type = Vertical, Wire Lugs

View all Features

Obsolete

Search for Replacement Parts

A dd to M y P art L is t

Reques t Sample

Find Similar P roduc ts

Buy P roduc t

Documentation & Additional Information

Product Drawings:

None Available

Catalog Pages/Data Sheets:

ALC OSWITC H PRODUC TS

(PDF, English)

Product Specifications:

None Available

Application Specifications:

None Available

Instruction Sheets:

None Available

CAD Files:

None Available

List all Documents

Product Features

(Please use the Product Drawing for all design activity)

Product Type Features:

C onfiguration (Pole-Throw) = Four Pole - Double Throw

Termination Type = Vertical, Wire Lugs

C omment = Wire lug terminals accept two No. 20 AWG wires.

Electrical Characteristics:

C urrent Rating (Amps.) = 3

Termination Related Features:

Seal Type = Terminal Seal (epoxy)

Body Related Features:

Series = TT (Tiny)

Mount Style = Panel

Flammability Rating = UL 94V-0

UL Rating = Qualified

Contact Related Features:

C ontact Plating = Silver

Housing Related Features:

Toggle Style = Baton Long

Toggle Length (mm [in]) = 9.40 [0.370]

Process Sealed = No

Bushing Style = Threaded

Bushing Type = 10-48

Configuration Related Features:

Operating Function

= On Off On

Industry Standards:

RoHS/ELV C ompliance

= Not ELV/RoHS compliant

Lead Free Solder Processes

= Wave solder capable to 240?C , Wave

solder capable to 260?C , Wave solder capable to 265?C

Other:

Brand = Alcoswitch

Additional Information:

Product Line Information

Additional Product Images:

Dimensional Drawing

8-1437562-0 Related Products

	8-1437562-0	TT43P3T
Description	Toggle Switch, TOGGLE SWITCH, 4PDT, LATCHED, 3A, PANEL MOUNT-THREADED	TOGGLE SWITCH,STRAIGHT,4PDT,ON-OFF-ON,SOLDER TERMINAL,TOGGLE BAT
Brand Name	Alcoswitch	Alcoswitch
Reach Compliance Code	unknown	unknown
Actuator type	BATON LONG TYPE	TOGGLE BAT
Body length or diameter	9.4 mm	15.748 mm
Maximum contact current (AC)	3 A	3 A
Maximum contact current (DC)	3 A	2 A
Installation features	PANEL MOUNT-THREADED	PANEL MOUNT
surface mount	NO	NO
Switch action	LATCHED	LATCHED
switch function	4PDT	4PDT
Switch type	TOGGLE SWITCH	TOGGLE SWITCH
Termination type	WIRE	SOLDER LUG
